H07V-U 1.5mm2 Single Core Copper Conductor PVC Insulated Cable BV Cu/PVC (NYA) - 450/750 Volt

H07V-U 1.5mm2 Single Core Copper Conductor PVC Insulated Cable BV Cu/PVC (NYA) - 450/750 Volt image

Get Latest Price Request a quote

Product Details

Model NO.

H07V-U

Application

Underground

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC

Brand

Hongda Cable

General Application

Grounding Cable or Internal Wiring

Standard Delivery Length

100/Coil

Operating Voltage, Uo/U

450/750V

Min. Bending Radius (mm)

6 X Cable Overall Diameter

Transport Package

Rolls, or Drum

Specification

cu/pvc

Trademark

N/A

Origin

China

HS Code

8544492100

Production Capacity

5000km/Week

Product Description

Cu/PVC (NYA) – 450/750 VOLT SNI 04-6629.3

SINGLE CORE, COPPER CONDUCTOR AND PVC INSULATED CABLE

General Application : Used for grounding cable or internal wiring in dry location

PVC, CU / PVC, Single Core, PVC Insulated, Non-Sheathed, 450/750V Cable – Compliant With SS358-3 / BS EN50525-2-31 / IEC60227-3

CONSTRUCTION

Conductor: Plain annealed copper, Class 2 stranded circular or compacted

Insulation: Polyvinyl Chloride (PVC) Compound Type PVC/C

Insulation colour: Black, Green/Yellow, Blue, White, Brown, Grey or Others

ELECTRICAL CHARACTERISTICS

Operating voltage, U0/U: 450/750V

Operating temperature: -15°C to +70°C

Final short circuit temperature: 160°C (for cables ≤ 300mm²), 140°C (for cables > 300mm²)

Test Voltage: 2.5kV for 5 minutes

REFERENCE STANDARDS

Design Specification: SS358-3, BS EN50525-2-31, IEC60227-3

Conductor: IEC60228, BS EN60228

Flame retardancy: IEC60332-1, BS EN60332-1

INSTALLATION REFERENCE

Minimum bending radius (mm): 6 x cable overall diameter

Maximum pulling tension: 50N/mm²

Nominal Conductor Area	No. and diameter of Wires	Radial Thickness of Insulation	Mean Overall Diameter (Upper Limit)	Approximate Weight
mm2	No./mm	mm	mm	kg/km
1×1.5	7/0.53	0.7	3.0	21.9
1×2.5	7/0.67	0.8	3.6	33.4
1×4	7/0.85	0.8	4.2	50.1
1×6	7/1.04	0.8	4.7	70.1
1×10	7/1.35	1.0	5.9	113.4
1×16	7/1.70	1.0	6.7	170.1
1×25	7/2.14	1.2	8.3	267.1
1×35	7/2.52	1.2	9.4	362.2
1×50	19/1.83	1.4	11.0	490.0
1×70	19/2.14	1.4	12.7	692.9
1×95	19/2.52	1.6	14.7	954.8
1×120	37/2.03	1.6	16.2	1192.3
1×150	37/2.25	1.8	18	1466.8
1×185	37/2.52	2.0	20.2	1839.2
1×240	61/2.25	2.2	23.2	2409.8
1×300	61/2.52	2.4	25.8	3014.7
1×400	61/2.85	2.6	29.2	3843.8
1×500	61/3.20	2.8	33.6	4841.4
1×630	127/2.52	2.8	38.4	6249.7

1- The performance of the products is in line with the national standards and the relevant standards of superior products.
2- After the arrival of the products, in the process of customer acceptance, if there is no conformity with the requirements of the contract or a small number of missing parts, wrong parts, damaged parts, The company after receiving the notice within 2 hours to make a reply, processing and supplement.

3- According to the requirements, the company can provide technical guidance and assistance free of charge, the company has after-sales service, to each user to telephone, letter, visit and other forms of consultation after the use of cable quality situation and opinions and suggestions, after receiving customer complaints, Reply within 2 hours, and as soon as possible to the user site for processing.

4- Under correct installation and use conditions, after the cable is put into operation, All kinds of quality problems such as the quality of the company’s products, the company will be responsible for the end and free replacement or repair.

5- Beyond the warranty period, the company still guarantees to do a good job of customer service work, if required to provide technical services, will arrive at the site within 24 hours upon receipt of notice, and provide free service; Need to change the product, The company will organize production in time and provide customers with the most favorable prices.

Our company solemnly promises that the quality, time and service of the supply shall fully respond to the relevant requirements of the tendering unit: 1- The products provided by us shall fully comply with the quality and technical standards stipulated in the contract of the tendering document. 2- We shall provide after-sales maintenance services strictly in accordance with the contract provisions of the bidding documents.

After-sales Contact: Ms Vivian

We are China H07V-U 1.5mm2 Single Core Copper Conductor PVC Insulated Cable BV Cu/PVC (NYA) - 450/750 Volt manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
