H07V-R Single Core 50 mm2 PVC Insulated Yellow / Green Cable

H07V-R Single Core 50 mm2 PVC Insulated Yellow / Green Cable image

Get Latest Price Request a quote

Product Details

Model NO.

h07v-r

Application

Overhead, Underground

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

Bare

Material Shape

Round Wire

Range of Application

Power and Lighting Circuits and Building Wiring

Certification

ISO9001, CCC, SGS

Brand

Hongda

Colour Required

Black, Red, Blue, Yellow, Green/Yellow, White, etc

Transport Package

100m Per Roll/Reel, or Customer Requirement

Specification

1.5sqm to 630sqmm

Trademark

Hongda, accept OEM

Origin

China

HS Code

8544492900

Production Capacity

40km/Day

Product Description

H07V-R Single Core 50 mm2 PVC Insulated Yellow / Green Cable
h07v-r single core pvc insulated building wire

Application

The cables are suitable for power and lighting circuits and building wiring suitable for use in semi flush exposed conduits, embedded conduits and in closed installation ducts.

Standard

BS EN 50525-2-31:2011. SABS 1507-2, SS 358 Part-3.

Specifications

Temperature Range : -15°C to 70°C Minimum Bending Radius

Upto 10 mm2 : 3 X Overall Diameter.

16 & 25 mm2 : 4 X Overall Diameter.

Above 25 mm2 : 5 X Overall Diameter.

Conductor : Plain annealed copper conductor 1.5 mm2 to 630 mm2 stranded class 2 complying with BS EN 60228, HD 383, IEC 60228

Insulation : PVC (Polyvinyl Chloride ) compound type TI 1 complying with EN 50363-3, HD 21.1, IEC 60227-1, SABS 1411-2

Cable Design Parameters

Kindly complete the part numbers for these cables by adding the suffix (in place of ‘xx’) for the colour required:

02 – black, 03 – red, 04 – blue, 05 – yellow, 06 – green / yellow, 07 – white, 08 – violet, 09 – brown, 10 – orange, 11 – pink, 12 – grey.

Dimension:

Nominal Cross Sectional Area (Sq. mm)	Nominal Insulation Thickness (mm)	Overall Diameter Lower Limit (mm)	Overall Diameter Upper Limit (mm)	Approx. Net Weight (kg/km)
1.5	0.70	2.70	3.30	19
2.5	0.80	3.30	4.00	33
4	0.80	3.80	4.60	50
6	0.80	4.30	5.20	74
10	1.00	5.60	6.70	126
16	1.00	6.40	7.80	184
25	1.20	8.10	9.70	295
35	1.20	9.00	10.90	375
50	1.40	10.60	12.80	510
70	1.40	12.10	14.60	710
95	1.60	14.10	17.10	950
120	1.60	15.60	18.80	1240
150	1.80	17.30	20.90	1530
185	2.00	19.30	23.30	1800
240	2.20	22.00	26.60	2500
300	2.40	24.50	29.60	2990
400	2.60	27.50	33.20	3860
500	2.80	30.50	36.90	4900
630	2.80	34.00	41.10	6370
