Flexible Copper Conductor Flame Retardant Insulated N07V-K Nyaf Cable

Flexible Copper Conductor Flame Retardant Insulated N07V-K Nyaf Cable image

Get Latest Price Request a quote

Product Details

Model NO.

N07V-K

Application

Construction

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CE, CCC

Brand

Hongda

Color

Black, White, Red, Blue, Yellow, Yellow&Green

Warranty

One Year

Transport Package

Plastic Film & Wooden Pallet

Specification

1.5~630sqmm

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

2000km/Month

Product Description

Flexible Copper Conductor Flame Retardant Insulated N07V-K Flexible Cable

POWER FLEXIBLE CABLES INSULATED IN REDUCE FLAME PROPAGATION POLYVINYL CHLORIDE. SINGLE CORE NOT-SHEATHED CABLE WITH FLEXIBLE CONDUCTOR.

Normative references
Italian standard: CEI 20-22 CEI-UNEL 35752 CEI 20-20
International standard: IEC 332-3

Technical Data
Voltage Rating: 450/750 V
Temperature Rating: 70 °C
Max Tensile Strength: 50 N/mm²
Minimum Bend Radius: 4 times outside cable diameter

Constructive data
Flexible conductors of not tinned annealed copper;
Insulation: quality R2 of polyvinyl chloride.

Colouring
Black, blue, brown, grey, orange, pink, red, violet, white, green, yellow and turquoise.
Colours combinations aren’t allow, except the yellow and green one.

Type	Cross-sectional area Nom.	Diameter of wire Max.	Diameter of conductor Nom.	Insulation thickness Nom.	Outside cable diameter Max.	Insulation resistance at 70°C Min.
N07V-K	mm²	mm	mm	mm	mm	MohmKm
	1	0,21	1,3	0,7	3,2	0,095
	1,5	0,26	1,6	0,7	3,5	0,082
	2,5	0,26	2,0	0,8	4,2	0,077
	4	0,31	2,6	0,8	4,8	0,062
	6	0,31	3,4	0,8	6,3	0,050
	10	0,41	4,4	1,0	7,6	0,049
	16	0,41	5,7	1,0	8,8	0,039
	25	0,41	6,9	1,2	11,0	0,039
	35	0,41	8,1	1,2	12,5	0,034
	50	0,41	9,8	1,4	14,5	0,033
	70	0,51	11,6	1,4	17,0	0,029
	95	0,51	13,3	1,4	19,0	0,028

We are China Flexible Copper Conductor Flame Retardant Insulated N07V-K Nyaf Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
