Fil Souple U500sv Wire 1.5 2.5 4 6
Fil Souple U500sv Wire 1.5 2.5 4 6 image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
Application
House wiring Electric wire 1.5mm 2.5mm etc is suitable for household electrical appliances, small electric power tools,instruments and apparatuses and lighting devices, AC rated voltage up to and including 300/500V 450/700V, which is used for connecting power line.
Specification
Type: Solid Type, Stranded Type, Flexible Type are available.
Size: 0.5-630mm2 , BV BVV BVR RV
Length: 100M 200M 300M 500M/roll, Can make as your request.
| Type | Cross Section(mm2) | Conductor Size(No. of Cores/Diameter) | Rated Voltage | Nominal Insulation Thickness(mm) | Reference Weight(kg/km) | Application |
| Solid Type | 0.5 | 1/0.80 | 300/500V 450/750V |
0.6 | 8.0 | Solid, Hard,Suitable for fixed installation |
| 0.75 | 1/0.97 | 0.6 | 11.4 | |||
| 1 | 1/1.13 | 0.6 | 15.2 | |||
| 1.5 | 1/1.38 | 0.7 | 21 | |||
| 2.5 | 1/1.78 | 0.7 | 32 | |||
| 4 | 1/2.25 | 0.8 | 47 | |||
| 6 | 1/2.76 | 0.8 | 67 | |||
| Stranded Type | 1.5 | 7/0.52 | 0.7 | 22 | Stranded, Flexible house wiring, Suitable for indoor applicant. | |
| 2.5 | 7/0.68 | 0.7 | 35 | |||
| 2.5 | 19/0.40 | 0.8 | 34 | |||
| 4 | 7/0.85 | 0.8 | 50 | |||
| 4 | 19/0.52 | 0.8 | 51 | |||
| 6 | 7/1.04 | 0.8 | 71 | |||
| 6 | 19/0.64 | 0.8 | 72 | |||
| 10 | 7/1.35 | 1.0 | 118 | |||
| 10 | 49/0.52 | 1.0 | 127 | |||
| 16 | 7/1.70 | 1.0 | 177 | |||
| 16 | 49/0.64 | 1.0 | 184 | |||
| Flexible Type | 1.5 | 30/0.25 | 0.7 | 22 | Ultra Flexible, Soft Conductor, Suitable for small power equipment instrument. | |
| 2.5 | 49/0.25 | 0.8 | 34 | |||
| 4 | 56/0.30 | 0.8 | 49 | |||
| 6 | 84/0.30 | 0.8 | 70 | |||
| 10 | 77/0.40 | 1.0 | 117 | |||
| 16 | 119/0.40 | 1.0 | 168 | |||
| 25 | 189/0.40 | 1.2 | 265 | |||
| … |
The cable can be of flame retardance, fire resistance, environment friendly or other property. OEM Available.
We are China Fil Souple U500sv Wire 1.5 2.5 4 6 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
