EAY2Y Power cable 0,6/1kV with Al conductors PVC insulated HDPE sheathed
DESIGN
1 | Aluminum conductor, round solid (RE), round stranded (RM), resp. sector-shaped stranded (SM)
2 | Core insulation (PVC)
3 | PVC core covering or taping
4 | outer sheath of HDPE (High Density Polyethylene)
APPLICATION
Power distribution cables in power stations, industrial installations and switchgears, as well as in local mains. For fi xed installation underground, in interior premises, cable ducts, in the open air, in water – as permitted by the local building regulations – if no risk of any mechanical damage is to be expected.
TECHNICAL DATA
Standard: IEC 60502-1
Rated voltage: 0.6/1 kV
Test voltage: 3.5 kV/50 Hz
Temperature range: laying temperature: min. -5 °C operating temperature: -30 °C up to +70 °C conductor temperature: max. +70 °C short-circuit temperature: max. +160 °C/5 s
Bending radius (min.): 15 x ? of cable (single core) 12 x ? of cable (multi-core)
Core identifi cation: HD 308 S2
Fire properties: flame retardant: EN 60332-1-2
E-AY2Y
PVC Insulated Cable with Aluminium Conductor
| Number of cores and nominal cross section mm2 |
Aluminium figure kg/km |
Overall diameter appr. mm |
Weight
appr. |
Current carrying capacity ground A |
Current carrying capacity air A |
|---|---|---|---|---|---|
| 1 x 25 RM | 74,0 | 11 | 174,0 | 106 | 87 |
| 1 x 35 RM | 103,0 | 12 | 209,0 | 127 | 107 |
| 1 x 50 RM | 147,0 | 14 | 282,0 | 151 | 131 |
| 1 x 70 RM | 206,0 | 16 | 363,0 | 185 | 166 |
| 1 x 95 RM | 279,0 | 18 | 520,0 | 222 | 205 |
| 1 x 120 RM | 353,0 | 19 | 557,0 | 253 | 239 |
| 1 x 150 RM | 441,0 | 21 | 674,0 | 284 | 273 |
| 1 x 185 RM | 544,0 | 24 | 826,0 | 322 | 314 |
| 1 x 240 RM | 706,0 | 26 | 1052,0 | 375 | 378 |
| 1 x 300 RM | 882,0 | 29 | 1282,0 | 425 | 437 |
| 1 x 400 RM | 1.200,0 | 32 | 1598,0 | 487 | 513 |
| 1 x 500 RM | 1.510,0 | 36 | 2022,0 | 558 | 600 |
| 1 x 630 RM | 1.900,0 | 40 | 2200,0 | 635 | 701 |
| 3 x 240/120 SM | 2.470,0 | 55 | 4215.0 | 364 | 338 |
| 4 x 25 RM | 294,0 | 25 | 887,0 | 102 | 82 |
| 4 x 35 SM | 412,0 | 26 | 796,0 | 123 | 100 |
| 4 x 50 SM | 588,0 | 27 | 1017,0 | 144 | 119 |
| 4 x 70 SM | 823,0 | 30 | 1312,0 | 179 | 152 |
| 4 x 95 SM | 1.117,0 | 34 | 1698,0 | 215 | 186 |
| 4 x 120 SM | 1.411,0 | 40 | 2459,0 | 245 | 216 |
| 4 x 150 SM | 1.764,0 | 43 | 2594,0 | 275 | 246 |
| 4 x 185 SM | 2.176,0 | 50 | 3777,0 | 313 | 285 |
| 4 x 240 SM | 2.822,0 | 54 | 4106,0 | 364 | 338 |
| 4 x 150 SE | 1.764,0 | 45 | 2594,0 | 275 | 246 |
| 5 x 25 RM | 368,0 | 26 | 1018,0 | 102 | 81 |
| 5 x 35 RM | 515,0 | 30 | 1316,0 | 121 | 99 |
| 5 x 50 SM | 781,0 | 32 | 1549,0 | 144 | 119 |
| 5 x 70 SM | 1.071,0 | 37 | 2021,0 | 179 | 152 |
| 5 x 95 SM | 1.484,0 | 41 | 2598,0 | 215 | 186 |
| 5 x 120 SM | 1.875,0 | 47 | 3201,0 | 245 | 216 |
In earth, ducts, on support brackets, in dry and wet conditions etc., where one does not expect mechanical damages and the cables are not exposed to the mechanical tensile strain. In urban networks, industrial plants, electric power plants and other electricity consumers and for connection of control devices in industry, traffic etc.
Construction:
Conductors: Al, class 1 or 2 according to EN 60228
Insulation: PVC compound DIV 1
Bedding: Extruded elastomere or plastomere compound or plastic tape
Sheath: HDPE compound DMP 1
Technical characteristics:
Voltage rating (Uo/U): 0,6/1 kV
Min. temp. for cable laying: -5°C
Max. working temperature: 70°C
Max. short-circuit temperature: 160°C
Min. bending radius: single-core – 15D; multicore – 12D
CPR class: Fca
