Earth Ground Wire Cable 35mm2 50mm2 70mm2 Bare Copper Conductor

Earth Ground Wire Cable 35mm2 50mm2 70mm2 Bare Copper Conductor image

Get Latest Price Request a quote

Product Details

Application

Overhead, Heating, Underground

Conductor Material

Copper

Sheath Material

Bare

Insulation Material

Bare

Material Shape

Round Wire

Certification

ISO9001, CCC

Brand

OEM

Transport Package

Wooden Drum

Specification

2.5~400sqmm

Trademark

OEM

Origin

China(Mainland)

HS Code

74081900

Production Capacity

500 Kilometer/Month

Product Description

APPLICATIONS
Solid and stranded bare copper are suitable for overhead transmission and distribution applications.
Stranded conductor of greater flexibility are suitable for uninsulated hook up, jumpers, and grounds in electrical construction. Soft Drawn copper is unilay construction.

SPECIFICATIONS
AS 1746: Conductors-Bare overhead-Hard-drawn copper

CONSTRUCTION
Bare copper, solid or stranded. Available in tempers hard, medium-hard, or soft. Stranded conductors are concentrically stranded in hard and medium-hard tempers and are Combination Unilay stranded in the soft-drawn temper.

Stranding and wire diameter	Approx. overall diameter	Cross-sectional area	Mass per	Calculated breaking laod (CBL)	Equivalent aluminium area	D.C. resistance per km at 20°C
mm	mm	mm2	kg	kN	mm2	Ω
7/1.00	3.00	5.498	49.3	2.32	8.68	3.25
7/1.25	3.75	8.589	76.9	3.59	13.6	2.09
7/1.75	5.25	16.84	151	6.89	26.6	1.06
7/2.00	6.00	21.99	197	8.89	34.7	0.815
7/2.75	8.25	41.58	375	16.2	65.3	0.433
19/1.75	8.75	45.70	413	18.3	71.7	0.395
19/2.00	10.0	59.70	538	23.6	93.6	0.303
7/3.50	10.5	67.35	607	25.4	106	0.268
7/3.75	11.3	77.28	696	28.8	121	0.233
37/1.75	12.3	88.99	806	35.6	139	0.203
19/2.75	13.8	112.9	1020	43.1	177	0.160
19/3.00	15.0	134.3	1210	50.8	211	0.134
37/2.50	17.5	181.6	1640	70.3	284	0.099 6
37/2.75	19.3	219.8	1990	83.9	344	0.082 3
37/3.00	21.0	261.6	2370	98.9	409	0.069 1
61/2.75	24.8	362.3	3290	138.0	566	0.050 0

acking shipping

Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas

If you have another question, pls feel free to contact us below

We are China Earth Ground Wire Cable 35mm2 50mm2 70mm2 Bare Copper Conductor manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
