0.6/1kV Low Voltage PVC Insulation and HDPE Outher Sheath Aluminum Underground Cable E-AY2Y
E-AY2Y Cable Application
Power distribution cables in power stations, industrial installations and switchgears, as well as in local mains.
For fixed installation undergroud, in interior premises, cable ducts, in open air, in water – as permited by the local building regulations – under severe mechanical stressing during installation and operation.
E-AY2Y Cable Standard
HD 603 S1, IEC 60502-1, ÖVE E8200-603
E-AY2Y Cable Construction
2.Insulation – Core insulation of polyvinylchloride (PVC)
3.Filling – PVC core covering (FM) or taping (BD)
4.Outher sheath – Polyethylene (HDPE), Black, UV resistant
|
Number of cores x Cross-section |
Overall diameter [mm] |
Weight [kg/km] |
Maximum electrical resistanceat 20ºC |
|
1×120 RM |
19 |
520 |
0.253 |
|
1×150 RM |
22 |
630 |
0.206 |
|
1×185 RM |
25 |
750 |
0.164 |
|
1×240 RM |
27 |
980 |
0.125 |
|
1×300 RM |
29 |
1200 |
0.1 |
|
3×240 SM + 120 SM |
55 |
3900 |
0.125 / 0.253 |
|
4×16 RM |
21 |
550 |
1.91 |
|
4×25 RM |
24 |
780 |
1.2 |
|
4×25 RE |
22 |
720 |
1.2 |
|
4×35 RM |
26 |
790 |
0.868 |
|
4×35 SM |
25 |
730 |
0.868 |
|
4×50 SM |
28 |
1100 |
0.641 |
|
4×50 SE |
26 |
1000 |
0.641 |
|
4×70 SM |
31 |
1350 |
0.443 |
|
4×70 SE |
30 |
1210 |
0.443 |
|
4×95 SM |
36 |
1800 |
0.32 |
|
4×95 SE |
34 |
1720 |
0.32 |
|
4×150 SM |
43 |
2700 |
0.206 |
|
4×150 SE |
41 |
2580 |
0.206 |
|
4×185 SM |
47 |
3080 |
0.164 |
|
4×185 SE |
46 |
2930 |
0.164 |
|
4×240 SE |
53 |
4140 |
0.125 |
|
4×240 SM |
54 |
4200 |
0.125 |
|
4×300 SM |
60 |
4630 |
0.1 |
Packing
Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.
Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Shipping Port:
Tianjin, Qingdao, or other ports as per your requireents.
Sea freight:
FOB/C&F/CIF quotation are all available.
*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency.
