DC Cable 1 Core 6mm2 Cu/PVC/Sta/PVC Steel Tape Armoured Cable 0.6/1kv

DC Cable 1 Core 6mm2 Cu/PVC/Sta/PVC Steel Tape Armoured Cable 0.6/1kv image

Get Latest Price Request a quote

Product Details

Model NO.

DC Cable 1 Core 6mm2

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC

Model

Cu/XLPE/Sta/PVC

Brand

OEM

Transport Package

Wooden Drum

Specification

4 x 95mm

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

50 Kilometer/Month

Product Description

1. Standard:
According to Chinese national standard GB 12706 and GB12666.6(Equal to IEC60502 and IEC60331),
also can do by standard of ASTM,BS,GB,DIN and AS/NZS or other standards as request.

2. Rated Voltage
0.6/1KV

3. Construction:

Conductor:Copper or Aluminium

Insulation:XLPE

Inner sheath:PVC

Armoured:Galvanized steel wire

Outer Sheath:PVC

4. Characters:

a.Max Long-time operating temperature of PVC insulated cable is 70°C XLPE insulated cable is 90°C

b.Installing temperature of cable should not be less than 0°C

c.Max short-circuit temperature is not exceed 160°C(XLPE Cable is 250°C),Not more than5 Sec.

d.Permitting bending radius cable: Not less than 10 D times (D:external diameter of cable)

5. Advantages:

a. Excellent electric and mechanical characteristics

b. Best Resistance chemical corrosion and heat-ageing,environment stress and flame-retardant

c. Simple in structure

d. Convenient to use

e. Light weight,perfect bending properties

Core NO. & Nominal Cross-section Area as reference:

No. of Core

3+1

3+2

4+1

Section

Area

(mm2)

4~500

2.5~500

2.5~300

4~300

2.5~300

4~300

NO. Of Cores
Rated voltage
Nominal thickness of insulation
Thickness of sheath
Diameter of conductor
Approx. Overall diameter
Max cable weight
Nominal cross sectional area of conductor etc.

All above can do as every different standards OR as your special request

Packing shipping

Any problem and inquiry pls contact with Tina

We are China DC Cable 1 Core 6mm2 Cu/PVC/Sta/PVC Steel Tape Armoured Cable 0.6/1kv manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
