Cu/XLPE/PE 4*185mm2 Power Cable Low Voltage

Cu/XLPE/PE 4*185mm2 Power Cable Low Voltage image

Get Latest Price Request a quote

Product Details

Model NO.

CU/XLPE/PE 4*185mm2

Current

DC Cable

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Copper or Aluminum

Certification

ISO, CCC, CE, RoHS

Model

Cu/XLPE/PE

Brand

Hongda

Overall Diameter

22.7mm

Core

Single

Conductor Material

Standard

IEC60502-1

Insulated Color

Black

Sheath Color

Black

Kg/Km

1818

Manufacture

Yes

Sample

Yes

HS Code

8544492100, 8544492100

Transport Package

Wooden Drum

Specification

1.5-1000mm2

Trademark

Hongda

Origin

China, Henan

Production Capacity

3000km/Per Months

Product Description

600/1000V 1X185mm2 Single Core XLPE INSULATED PE SHEATH CABLE

Item	DESCRIPTION	UNIT	TENDERED
1	TYPE:		CU/XLPE/PE *1185mm2**
	a) Manufacturer’s name	Name	ZHENGZHOU HONGDA CABLE CO., LTD
	b) Country of origin	Name	China
	c) Rated voltage	KV	0.6/1
2	Applies Standard		·IEC60502
3	Conductor:
	a) Material	–	Plain annealed soft copper
	b) Normal section area	mm²	185
	c) Conductor shape	–	Stranded compacted circular (Class 2)
	d) Number of core	each	1
	e) Number and diameter of individual wire	No./mm	37/2.52
	f) Conductor diameter	mm	15.3
4	Insulation:
	a) Material	–	XLPE
	b) Color	–	Natural
	c) Nominal Thickness	mm	1.6
5	Out Sheath:
	a) Material		PE
	b) Color		Black
	c) Nominal Thickness		1.6
6	Approx. weight of cable	kg/km	1818
7	Approx. Diameter of cable	mm	22.7
8	Permitted temperature on core:
	a) Long-term working temperature	ºC	–15~90
	b) Max. temperature in short circuit	ºC	250
9	Max. DC. Conductor resistance at 20ºC	ohm/km	0.0991

Standards
GB/12706-2008, IEC60502-1,IEC 60228,IEC60332 BS 5467,IS 1554 , IS 7098 ect.
Hongda cable can also design and produce for special application requirement.

Main products

^{Packaging&Delivery}

Packaging Details:Wooden drums,steel wooden drums or as your requirement
Delivery Time:Normally within 7 days(detailly depend on the order quantity)
