CSA 1 Kv Aluminum/Copper 500 Mcm XLPE RW90 Rwu90 Cable

CSA 1 Kv Aluminum/Copper 500 Mcm XLPE RW90 Rwu90 Cable image

Get Latest Price Request a quote

Product Details

Model NO.

RWU90 Cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

Crosslinking

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, SGS

Model

Rwu90 / RW90

Brand

Hongda

Insulation Level

100% Insulation Level

Transport Package

500m Per Drum

Specification

14AWG to 1500MCM

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

600km/Month

Product Description

CSA 1 kV Aluminum/Copper 500 mcm XLPE RW90 RWU90 Cable

CSA RWU90 | Single Conductor (1000V)

For use in open wiring and raceways (with the exception of cable troughs and ventilated flexible cableways) in dry or wet locations. For open wiring exposed to the weather. Maximum conductor temperature 90°C.

VOLTAGE

1000V

Optional: 600 / 2000V

PRODUCT CONSTRUCTION

Insulation:
- XLPE (RW90 rated) rated: 90°C wet / dry
Available in:
- All colours

CERTIFICATIONS/COMPLIANCES

CSA C22.2 #38, Thermoset Insulated Wires & Cables (XLPE)
-40°C cold bend / impact rated
Direct burial rated
UV sunlight resistant SUN RES (black only)

COLOUR CODING

Black conductor (standard)

Size	Insulation		Nominal		Approximate Net
AWG or	Thickness		Diameter		Cable Weight
kcmil	mm	in	mm	in	kg/km	lbs/kft
14 (1) (Note 5)	0.76	0.03	3.2	0.13	24	16
12 (1) (Note 5)	0.76	0.03	3.6	0.14	35	24
10 (1) (Note 5)	0.76	0.03	4.1	0.16	54	36
14 (7) (Note 5)	0.76	0.03	3.3	0.13	25	17
12 (7) (Note 5)	0.76	0.03	3.8	0.15	37	25
10 (7) (Note 5)	0.76	0.03	4.6	0.18	57	38
8 (7)	1.14	0.045	5.9	0.23	92	62
6 (7)	1.14	0.045	6.8	0.27	141	95
6 (7)	1.14	0.045	6.8	0.27	141	95
4 (7)	1.14	0.045	8	0.32	217	146
3 (7)	1.14	0.045	8.7	0.34	269	181
2 (7)	1.14	0.045	9.5	0.37	336	226
1 (19)	1.4	0.055	11	0.43	429	288
1/0 (19)	1.4	0.055	11.8	0.47	532	358
2/0 (19)	1.4	0.055	12.9	0.51	672	452
2/0 (19)	1.4	0.055	12.9	0.51	672	452
3/0 (19)	1.4	0.055	14.2	0.56	833	560
4/0 (19)	1.4	0.055	15.6	0.61	1040	699
250 (37)	1.65	0.065	17.2	0.68	1238	832
300 (37)	1.65	0.065	18.8	0.74	1454	977
350 (37)	1.65	0.065	19.9	0.78	1713	1151
400 (37)	1.65	0.065	21.2	0.84	1924	1293
500 (37)	1.65	0.065	23.3	0.92	2387	1604
600 (61)	2.03	0.08	26	1.03	2883	1937
750 (61)	2.03	0.08	28.9	1.13	3582	2407
1000 (61)	2.03	0.08	32.4	1.28	4438	3184

*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

We are looking forward to your inquiry and nice cooperation.

We are China CSA 1 Kv Aluminum/Copper 500 Mcm XLPE RW90 Rwu90 Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
