Covered Copper Nylon Jacket Field Telephone Cable Double Wire Twisted

Covered Copper Nylon Jacket Field Telephone Cable Double Wire Twisted image

Get Latest Price Request a quote

Product Details

Model NO.

Field Telephone Cable

Cover Material

Type

Covered Copper Nylon Jacket Field Telephone Cable

Material Shape

Round Wire

Conductor Type

Stranded

Wire Core Material

Tinned Wire

Certification

ISO, CCC, SGS

Model

Covered Copper Nylon Jacket Field Telephone Cable

Brand

Hongda

Insulation

UV Resistant PE

Working Temperature Range

-10 C to +80 C

Transport Package

500m/Roll, Other Customer Requirements

Specification

0.5mm2 to 0.8mm2

Trademark

Hongda

Origin

China

HS Code

8544491100

Production Capacity

500 Kilometer/Month

Product Description

Covered copper Nylon Jacket Field Telephone Cable Double wire Twisted

The PE Drop Wire is used in telephone connectivity. The drop wire is available in oval shape to add in conductor field separation. These are two round solid copper covered steel wires that serve dually as conductors and strength members. It comes with good tensile strength, conductivity and elongation property.

The bonding of insulation with the conductor is controlled to assure that the full conductor strength is transferred to the wire support clamp. These wires are conductor resistant, insulation resistant and minimal breakage possibility. It does not get any burn in the first 60 seconds and lasts longer than usual drop wires.

Construction

7X0.28MM(3 Number of Zinc Covered Steel+4 Number of Tin Covered copper Strands)x2+2.3mmPolyethylene+Nylon+Double Wire (Twisted)

1.	Thickness of insulation (Polyethylene)	Minimum 0.35 mm
2.	Thickness of Polumide Jacket (Nylon)	0.15 mm (Average)
3.	Overall diameter of single conductor	Maximum 2.30 mm
4.	Breaking load for two wires conductor	Minimum 72 Kg
5.	Cutting load test	55 lb (Average)/25 Kg (Average)
6.	DC Loop Resistance	151 Ohm/Km (at 20°C)
7.	Insulation Resistance	2000 M Ohm/Km
8.	Dielectric Strength Test	1000 V AC (Minimum)
9.	Weight of Zinc Cover for each steel Strands	Minimum 25 gm/Kg
10.	Weight of Tin Covered for each steel Strands	8.75 – 24.8 gm/Kg
11.	No. Of Twist/M	14 – 16 Nos. (Average)
12	Apparent Shape	Double Wire (Twisted)
13	Color	Black
14	Conductors (Physical Characteristics)
	(a) Number of Strands	07 Nos
	(b) Number of Tin Covered copper Strands	04 Nos
	(c) Number of Zinc Covered Steel Strands	03 Nos
	(d) Diameter of each Stands	0.28 mm ± 0.01 mm

7X0.25MM(4 Number of Zinc Covered Steel+3 Number of copper Strands)x2+2.15mm Polyethylene Double Wire (Twisted)

1	Single wire diameter	0.25mm
2	Number of copper Strands	3 Nos
3	Number of steel Strands	4 Nos
4	Thickness of insulation (Polyethylene)	≥ 0.35 mm
5	Overall diameter of single conductor	≤ 2.15 mm
6	Temperature	-15ºC~55ºC
7	Cable length (roll)	500±5m
8	Breaking load for two wires conductor	≤ 490N
9	DC Loop Resistance	≤230 Ω/Km (at 20°C)
10	Insulation Resistance	≥50 M Ω/Km
11	Attenuation constant	≤1.9dB/km
12	Characteristic resistance	840Ω
13	Dielectric Strength Test	1000 V AC (Minimum)
14	Weight of TWISTED WIRE	≤14KG
15	No. Of Twist/M	14 – 16 Nos. (Average)
16	Apparent Shape	Double Wire (Twisted)
17	Color	Black

7X0.25MM(7 Number of Copper Covered Steel Strands)x2+1.95mm Polyethylene Double Wire (Twisted)

1	Single wire diameter	0.25mm
2	Number of copper covered steel Strands	7 Nos
3	Thickness of insulation (Polyethylene)	≥ 0.35 mm
4	Overall diameter of single conductor	≤ 1.95 mm
5	Cable wire diameter twisted	≤ 3.9mm
6	Temperature	-45ºC~55ºC
7	Cable length (roll)	500±5m
8	Breaking load for two wires conductor	≤ 490N
9	DC Loop Resistance	≤300 Ω/Km (at 20°C)
10	Insulation Resistance	≥3000 M Ω/Km
11	Attenuation constant	≤1.8dB/km
12	Dielectric Strength Test	1000 V AC (Minimum)
13	Weight of TWISTED WIRE	≤ 10KG
14	No. Of Twist/M	14 – 16 Nos. (Average)
15	Apparent Shape	Double Wire (Twisted)
16	Color	Black

4X0.25MM(Aramid covered 4 Number of Tinned Copper Strands)x2+2.1mm Polyethylene Double Wire (Twisted)

1	Single wire diameter	0.25mm
2	Number of tinned copper Strands	4 Nos
3	Thickness of insulation (Polyethylene)	≥ 0.35 mm
4	Overall diameter of single conductor	≤ 2.1 mm
5	Cable wire diameter twisted	≤ 4.2 mm
6	Temperature	-45ºC~55ºC
7	Cable length (roll)	500±5m
8	Breaking load for two wires conductor	≤ 490N
9	DC Loop Resistance	≤85 Ω/Km (at 20°C)
10	Insulation Resistance	≥3000 M Ω/Km
11	Attenuation constant	≤1.8dB/km
12	Dielectric Strength Test	1000 V AC (Minimum)
13	Weight of TWISTED WIRE	≤ 10KG
14	No. Of Twist/M	14 – 16 Nos. (Average)
15	Apparent Shape	Double Wire (Twisted)
16	Color	Black

Packing

100m/roll,200m/roll,305m/roll,100yard/roll,200yard/roll,305yard/roll,other lengths according clinets requires
Inner packing:wooden reel,plastic drum,paper stool
Outer packing:carton box,pull out box pallet available
Other packing is available according to the client’s requirements

OUR SERVICE:

1. Any inquiries will be replied within 24 hours.

2. Professional manufacturer, 12 years manufacturing experience.

3. OEM/ODM available

4. High quality, reasonable and competitive price, fast lead time.

5. Good after-Sale Service.

1) All products will have been strictly Quality Checked in house before packing
2) All products will be well packed before shipping.

6. Faster delivery:
Sample order in stock, and 5-7 days for bulk production.

Please contact us for technical support with the right cable selection for your power distribution projects and to discuss your maintenance or project specific requirements. We provide tailored solutions for this cable range which include storage, cutting to length, and 2 days collection as standard.

Any problem and inquiry pls contact with Vivian Yuan.

We are China Covered Copper Nylon Jacket Field Telephone Cable Double Wire Twisted manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
