Copper Conductor Material and PVC Jacket AC Cables 3 Core

Copper Conductor Material and PVC Jacket AC Cables 3 Core image

Get Latest Price Request a quote

Product Details

Model NO.

IEC 60227

Application

Hous Building

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Hous Building

Certification

ISO9001, CE, CCC, Copper Conductor Material and PVC Jacket AC Cables

Brand

Henan Hongda

Insulation Color(S)

Natural / Red / Yellow / Blue / Green etc.

Outer Sheath Color

Black etc.

No. of Cores

Single

Cross Section

16 Sqmm

Packing Length

According to Your Request

Long‐term Working Temperature

Max. Temperature in Short Circuit

160°c /250°c

Rated Voltage

300/500V

Design Standard

IEC 60227

Certificate

ISO 14001 / ISO 9001 / Ohasa 18001 / CCC

Warranty

3 Years

Transport Package

by Sea

Specification

PVC Insulation Material and Copper Conductor Mater

Trademark

HENAN HONGDA

Origin

China

HS Code

85444929

Production Capacity

5000

Product Description

Copper Conductor Material and PVC Jacket AC Cables 3 Core

Polyvinyl chloride insulated cables and cords of rated voltages up to and including 450/750V

Application

Wiring for electrical appliances, smaller size electric tools, instruments of various meters, and motorized lighting system.

Standard

IEC 60227,IEC 60228,IEC 60332,GB/T 5023,BS 6500,BS 6004,VDE 0281,0282 , EN 50525-1, AS/NZS 5000.2 etc.

Type and description

Serial number	Type	Description
1	60227 IEC 01(BV) (H07V-U or H07V-R)	Single core solid or stranded conductor unsheathed cable for general purposes
2	60227 IEC 02(RV) (H07V-K)	Single core flexible conductor unsheathed cable for general purposes
3	60227 IEC 05(BV) (H05V-U or H05V-R)	Single core 70ºC solid or stranded conductor unsheathed cable for internal wiring
4	60227 IEC 06(RV) (H05V-K)	Single core 70ºC flexible conductor unsheathed cable for internal wiring
5	60227 IEC 07(BV-90) (H07V2-U or H07V2-R)	Single core 90ºC solid conductor unsheathed cable for internal wiring
6	60227 IEC 08(RV-90) (H07V2-K)	Single core 90ºC flexible conductor unsheathed cable for internal wiring
7	60227 IEC 10(BVV) (NYY or NYM)	Light PVC sheathed cable
8	60227 IEC 42(RVB)	Flat unsheathed flexible wire
9	60227 IEC 52(RVV) (H03VV-F,H03VV2-F)	Light PVC sheathed flexible wire
10	60227 IEC 53(RVV) (H05VV-F,H05VV2-F)	Common PVC sheathed flexible wire
11	BV (H07V-U or H07V-R)	Copper conductor PVC insulated wire
12	BLV	Aluminum conductor PVC insulated wire
13	BVR	Copper conductor PVC insulated flexible cable
14	BVV (NYY or NYM)	Copper conductor PVC insulated sheathed circular cable
15	BLVV	Aluminum conductor PVC insulated and sheathed round cable
16	BVVB (H05VVH2-F)	Copper conductor PVC insulated and sheathed flat cable
17	BLVVB	Aluminum conductor PVC insulated sheathed flat cable
18	NMD-90	Copper conductor PVC/Nylon Insulated PVC Jacked flat cable
19	RVS	Twisted copper conductor PVC insulated flexible cable for conection
20	AVP	Copper conductor PVC insulated wire with shied for installation
21	RVP	Copper conductor PVC insulated flexible wire with shield
22	RVVP	Copper conductor PVC insulated, shielded, PVC sheathed flexible cable

NOTE:1) Cores number series ar,1,2 ,3,4and 5.

2) KAIQI Power can produce “Flame-Retardant Series”, “Fire-Resistant Series”, “Low Smoke Halogen Free (LSHF/LSOH) Series”,

“Low Smoke Low Halogen (LSLH) Series”, etc.

Performance in line with IEC60332,IEC 61034,IEC60754 requirements.

Technical parameter

Table 1 IEC 60227 Standard

Type	Nom. cross section mm²	No ./Dia. of Strand mm	Nom. Thickness of insulation mm	Average OD (Max.) mm	Max. DC conductor resistance at 20ºC Ω/km		Min. Insulating resistance at 70ºC MΩ·km
Type	Nom. cross section mm²	No ./Dia. of Strand mm	Nom. Thickness of insulation mm	Average OD (Max.) mm	Copper core	Tinned copper core	Min. Insulating resistance at 70ºC MΩ·km
60227 IEC 01(BV) 450/750V	1.5	1/1.37	0.7	3.3	12.1	12.2	0.011
	1.5	7/0.52	0.7	3.4	12.1	12.2	0.010
	2.5	1/1.76	0.8	3.9	7.41	7.56	0.010
	2.5	7/0.68	0.8	4.2	7.41	7.56	0.009
	4	1/2.24	0.8	4.4	4.61	4.70	0.0085
	4	7/0.85	0.8	4.8	4.61	4.70	0.0077
	6	1/2.73	0.8	4.9	3.08	3.11	0.0070
	6	7/1.04	0.8	5.4	3.08	3.11	0.0065
	10	7/1.33	1.0	6.8	1.83	1.84	0.0065
	16	7/1.70	1.0	8.0	1.15	1.16	0.0050
	25	7/2.12	1.2	9.8	0.727	0.734	0.0050
	35	7/2.50	1.2	11.0	0.524	0.529	0.0040
	50	19/1.78	1.4	13.0	0.387	0.391	0.0045
	70	18/2.12	1.4	15.0	0.268	0.270	0.0035
	95	19/2.50	1.6	17.0	0.193	0.195	0.0035
	120	37/2.00	1.6	19.0	0.153	0.154	0.0032
60227 IEC 01(BV) 450/750V	150	37/2.24	1.8	21.0	0.124	0.126	0.0032
	185	37/2.50	2.0	23.5	0.0991	0.100	0.0032
	240	61/2.24	2.2	26.5	0.0754	0.0762	0.0032
	300	61/2.50	2.4	29.5	0.0601	0.0607	0.0030
	400	61/2.85	2.6	33.5	0.0470	0.0475	0.0028
60227 IEC 02(RV) 450/750V	1.5	30/0.25	0.7	3.5	13.3	13.7	0.010
	2.5	50/0.25	0.8	4.2	7.98	8.21	0.009
	4	77/0.26	0.8	4.8	4.95	5.09	0.007
	6	78/0.31	0.8	6.3	3.30	3.39	0.006
	10	84/0.39	1.0	7.6	1.91	1.95	0.0056
	16	133/0.39	1.0	8.8	1.21	1.24	0.0046
	25	189/0.41	1.2	11.0	0.780	0.795	0.0044
	35	259/0.41	1.2	12.5	0.554	0.565	0.0038
	50	361/0.41	1.4	14.5	0.386	0.393	0.0037
	70	337/0.51	1.4	17.0	0.272	0.277	0.0032
60227 IEC 05(BV) 300/500V	0.5	1/0.80	0.6	2.4	36.0	36.7	0.015
	0.75	1/0.97	0.6	2.6	24.5	24.8	0.012
	1.0	1/1.13	0.6	2.8	18.1	18.2	0.011
60227 IEC 06(RV) 300/500V	0.5	16/0.20	0.6	2.6	39.0	40.1	0.013
	0.75	24/0.20	0.6	2.8	26.0	26.7	0.011
	1.0	32/0.20	0.6	3.0	19.5	20.0	0.010
60227 IEC 07(BV-90) 300/500V	0.5	1/0.80	0.6	2.4	36.0	36.7	0.015
	0.75	1/0.97	0.6	2.6	24.5	24.8	0.013
	1.0	1/1.13	0.6	2.8	18.1	18.2	0.012
	1.5	1/1.37	0.7	3.3	12.1	12.2	0.011
	2.5	1/1.76	0.8	3.9	7.41	7.56	0.009
60227 IEC 08(RV-90) 300/500V	0.5	16/0.20	0.6	2.6	39.0	40.1	0.013
	0.75	24/0.20	0.6	2.8	26.0	26.7	0.012
	1.0	32/0.20	0.6	3.0	19.5	20.0	0.010
	1.5	30/0.25	0.7	3.5	13.3	13.7	0.009
	2	50/0.25	0.8	4.2	7.98	8.21	0.009

No . of cores ×Nom. Cross Section mm²	Min. No. of wires	Thickness of insulation	Thickness of sheath	Approx. overall diameter	Approx. net weight of cables	Max. DC resistance of conductor at 20ºC	Min. insulation resistance at 70ºC



(n x mm²)	(n)	(mm)	(mm)	(mm)	(kg/km)	Ω/km	(MΩ.km)
1×1.5	1	0.6	1.4	5.2	43	12.1	0.010
1×2.5	1	0.7	1.4	5.7	57	7.41	0.0094
1×4	1	0.8	1.4	6.4	77	4.61	0.0087
1×6	1	0.8	1.4	6.9	99	3.08	0.0074
1×10	1	1.0	1.4	8.1	148	1.83	0.0072
1×16	6	1.0	1.4	9.2	212	1.15	0.0053
1×25	6	1.2	1.4	10.7	312	0.727	0.0051
2×1.5	1	0.6	1.4	7.9	103	12.10	0.010
2×2.5	1	0.7	1.4	9.1	142	7.41	0.0094
2×4	1	0.8	1.4	10.2	191	4.61	0.0087
2×6	1	0.8	1.4	11.2	247	3.08	0.0074
2×10	1	1.0	1.4	14	395	1.83	0.0072
2×16	6	1.0	1.4	16.6	584	1.15	0.0053
2×25	6	1.2	1.4	20	877	0.73	0.0051
2×35	6	1.2	1.8	22.5	1152	0.524	0.0045
3×1.5	1	0.6	1.4	8.3	120	12.10	0.010
3×2.5	1	0.7	1.4	9.5	169	7.41	0.0094
3×4	1	0.8	1.4	11	238	4.61	0.0087
3×6	1	0.8	1.6	12.2	315	3.08	0.0074
3×10	1	1.0	1.6	14.8	489	1.83	0.0072
3×16	6	1.0	1.8	17.6	730	1.15	0.0053
3×25	6	1.2	1.8	21.7	1123	0.73	0.0051
3×35	6	1.2	1.8	23.9	1461	0.524	0.0045
4×1.5	1	0.6	1.4	8.9	142	12.10	0.010
4×2.5	1	0.7	1.4	10.3	203	7.41	0.0094
4×4	1	0.8	1.6	12.3	300	4.61	0.0087
4×6	1	0.8	1.6	13.5	393	3.08	0.0074
4×10	1	1.0	1.6	16.2	604	1.83	0.0072
4×16	6	1.0	1.6	19.3	907	1.15	0.0053
4×25	6	1.2	1.8	23.8	1398	0.73	0.0051
4×35	6	1.2	1.8	26.4	1828	0.524	0.0045
5×1.5	1	0.6	1.4	9.6	169	12.10	0.010
5×2.5	1	0.7	1.4	11.1	244	7.41	0.0094
5×4	1	0.8	1.6	13.3	362	4.61	0.0087
5×6	1	0.8	1.6	14.6	478	3.08	0.0074
5×10	1	1.0	1.6	17.9	751	1.83	0.0072
5×16	6	1.0	1.8	21.6	1138	1.15	0.0053
5×25	6	1.2	1.8	26.2	1727	0.73	0.0051
5×35	6	1.2	1.8	29.1	2263	0.524	0.0045
7×1.5	1	0.6	1.4	10.7	219	12.10	0.010
7×2.5	1	0.7	1.6	12.6	322	7.41	0.0094
10×1.5	1	0.6	1.4	12.4	282	12.10	0.010
10×2.5	1	0.7	1.6	15.2	433	7.41	0.0094
12×1.5	1	0.6	1.4	12.8	317	12.10	0.01
12×2.5	1	0.7	1.6	15.6	489	7.41	0.0094

We are China Copper Conductor Material and PVC Jacket AC Cables 3 Core manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
