Construction Underground power cable 240 sq mm cable 3×240
Structure
Standard for Construction Underground power cable 240 sq mm cable 3×240
Hongda Construction Underground power cable 240 sq mm cable 3×240 is manufactured according to the standard of GB12706 or IEC,BS,DIN and ICEA upon request.
Applications for Construction Underground power cable 240 sq mm cable 3×240
XLPE cable is suitable for dynamic line transmission and distribution lines of shielding performance requirements more stringent,especially applies to the rated voltage 0.6/1kV and below frequency inverter control system for power supply or connectiing cables.Frequency conversion cable is actually a shield-type power cable,the difference is that ground wires are divided into third part placed in the three main line between core to uniform electric field and improve levels of electromagnetic radiation of cable.Mostly used in high-power inverter power supply and frequency conversion motor connection
Operating characteristics for Construction Underground power cable 240 sq mm cable 3×240
1.Rated power-frequency voltage Uo/U of electrical cable : 0.6/1kV
2.Max.permissible continuous operating temperature of electrical cable conductor: 90°C
3.Max.short-circuit temperature of electrical cable conductor shall not exceed 250°C.(5s maximum)
4.The ambient temperature under installation should not below 0°C
5.The bending radius of electrical cable should not less than 15 times of electrical cable diameter.
The type of Construction Underground power cable 240 sq mm cable 3×240
|
Chinese Type |
Description of xlpe insulated cable |
Core qty |
Conductors range |
|
YJV |
Copper conductor, xlpe insulated cable, PVC outer sheath Power Cable |
1, 2, 3, 4, 3+1, 5, 4+1, 3+2 |
1.5~800mm2 |
|
YJY |
Copper conductor, XLPE insulated cable, PE outer sheath Power Cable |
1, 2, 3, 4, 3+1, 5, 4+1, 3+2 |
1.5~800mm2 |
|
ZA-YJV ZB-YJV ZC-YJV |
Copper conductor, XLPE insulated flame-retardant Power Cable |
1, 2, 3, 4, 3+1, 5, 4+1, 3+2 |
1.5~800mm2 |
|
WDZA-YJY WDZB-YJY WDZC-YJY |
Copper conductor, XLPE insulated cable of Low Smoke Halogen Free or Zero Halogen (LSHF or LSZH) flame-retardant Power Cable |
1, 2, 3, 4, 3+1, 5, 4+1, 3+2 |
1.5~800mm2 |
|
NH-YJV |
Copper conductor, XLPE insulated cable of fire-resistant Power Cable |
1, 2, 3, 4, 3+1, 5, 4+1, 3+2 |
1.5~800m |
| DIMENSIONS | |||||||||
| Cores number N° |
Cross section mm² |
Approx conductor diameter mm |
Insulation medium thickness mm |
Min. sheath thickness mm |
Max. external diameter mm |
Electric resistance at 20°C ohm/km |
Approx cable weight kg/km |
Current carrying air free A |
Current carrying burried A |
| Single core | |||||||||
| 1x | 1.5 | 1.4 | 0.7 | 1.09 | 6.6 | 12.1 | 45 | 24 | 31 |
| 1x | 2.5 | 1.8 | 0.7 | 1.09 | 7 | 7.41 | 55 | 33 | 41 |
| 1x | 4 | 2.25 | 0.7 | 1.09 | 7.6 | 4.61 | 75 | 45 | 59 |
| 1x | 6 | 3.05 | 0.7 | 1.09 | 8.2 | 3.08 | 100 | 58 | 74 |
| 1x | 10 | 3.8 | 0.7 | 1.09 | 9.2 | 1.83 | 140 | 80 | 101 |
| 1x | 16 | 4.7 | 0.7 | 1.09 | 10.5 | 1.15 | 205 | 107 | 128 |
| 1x | 25 | 5.9 | 0.9 | 1.09 | 12.5 | 0.727 | 315 | 138 | 144 |
| 1x | 35 | 7.1 | 0.9 | 1.09 | 13.5 | 0.524 | 400 | 169 | 174 |
| 1x | 50 | 8 | 1 | 1.09 | 15 | 0.387 | 530 | 207 | 206 |
| 1x | 70 | 9.6 | 1.1 | 1.09 | 17 | 0.268 | 725 | 268 | 254 |
| 1x | 95 | 11.4 | 1.1 | 1.18 | 19 | 0.193 | 985 | 328 | 301 |
| 1x | 120 | 13.1 | 1.2 | 1.18 | 21 | 0.153 | 1260 | 382 | 343 |
| 1x | 150 | 14.6 | 1.4 | 1.26 | 23 | 0.124 | 1520 | 441 | 387 |
| 1x | 185 | 16.5 | 1.6 | 1.26 | 25.5 | 0.0991 | 1940 | 506 | 434 |
| 1x | 240 | 18.4 | 1.7 | 1.35 | 28.5 | 0.0754 | 2310 | 599 | 501 |
| 1x | 300 | 21.1 | 1.8 | 1.43 | 31 | 0.0601 | 3200 | 693 | 565 |
| 1x | 400 | 23.5 | 2 | 1.52 | 34.2 | 0.047 | 3931 | – | 639 |
| 1x | 500 | 26.5 | 2.2 | 1.6 | 38 | 0.0366 | 5020 | – | 713 |
| 1x | 630 | 30.1 | 2.4 | 1.69 | 44 | 0.0286 | 5324 | – | 785 |
| Two cores | |||||||||
| 2x | 1.5 | 1.4 | 0.7 | 1.43 | 10.5 | 12.1 | 115 | 26 | 37 |
| 2x | 2.5 | 1.8 | 0.7 | 1.43 | 11.5 | 7.41 | 145 | 36 | 48 |
| 2x | 4 | 2.25 | 0.7 | 1.43 | 13 | 4.61 | 195 | 49 | 63 |
| 2x | 6 | 3.05 | 0.7 | 1.43 | 14 | 3.08 | 265 | 63 | 80 |
| 2x | 10 | 3.8 | 0.7 | 1.43 | 16 | 1.83 | 390 | 86 | 104 |
| 2x | 16 | 4.7 | 0.7 | 1.43 | 18.5 | 1.15 | 560 | 115 | 136 |
| 2x | 25 | 5.9 | 0.9 | 1.43 | 22 | 0.727 | 850 | 149 | 173 |
| 2x | 35 | 7.1 | 0.9 | 1.43 | 24.5 | 0.524 | 1080 | 185 | 208 |
| Three cores | |||||||||
| 3x | 1.5 | 1.4 | 0.7 | 1.43 | 11 | 12.1 | 130 | 23 | 31 |
| 3x | 2.5 | 1.8 | 0.7 | 1.43 | 12.5 | 7.41 | 170 | 31 | 41 |
| 3x | 4 | 2.25 | 0.7 | 1.43 | 13.5 | 4.61 | 230 | 42 | 53 |
| 3x | 6 | 3.05 | 0.7 | 1.43 | 15 | 3.08 | 325 | 54 | 66 |
| 3x | 10 | 3.8 | 0.7 | 1.43 | 17 | 1.83 | 485 | 75 | 87 |
| 3x | 16 | 4.7 | 0.7 | 1.43 | 19.5 | 1.15 | 705 | 100 | 113 |
| 3x | 25 | 5.9 | 0.9 | 1.43 | 23.5 | 0.727 | 1080 | 127 | 144 |
| 3x | 35 | 7.1 | 0.9 | 1.43 | 26 | 0.524 | 1390 | 158 | 174 |
| 3x | 50 | 8 | 1 | 1.43 | 29 | 0.387 | 1840 | 192 | 206 |
| 3x | 70 | 9.6 | 1.1 | 1.52 | 34 | 0.268 | 2540 | 246 | 254 |
| 3x | 95 | 11.4 | 1.1 | 1.6 | 38.5 | 0.193 | 3430 | 298 | 301 |
| 3x | 120 | 13.1 | 1.2 | 1.69 | 42.5 | 0.153 | 4440 | 346 | 343 |
| 3x | 150 | 14.6 | 1.4 | 1.86 | 47.5 | 0.124 | 5380 | 395 | 395 |
| 3x | 185 | 16.5 | 1.6 | 1.94 | 53 | 9.91 | 6920 | 450 | 434 |
| 3x | 240 | 18.4 | 1.7 | 2.11 | 59.5 | 7.54 | 8420 | 538 | 501 |
| 3x | 300 | 21.1 | 1.8 | 2.28 | 66 | 6.01 | 11300 | 621 | 565 |
| DIMENSIONS | |||||||||
| Cores number N° |
Cross section mm² |
Approx conductor diameter mm |
Insulation medium thickness mm |
Min. sheath thickness mm |
Max. external diameter mm |
Electric resistance at 20°C ohm/km |
Approx cable weight kg/km |
Current carrying air free A |
Current carrying burried A |
| Four cores | |||||||||
| 4x | 1.5 | 1.4 | 0.7 | 1.43 | 12 | 12.1 | 150 | 23 | 31 |
| 4x | 2.5 | 1.8 | 0.7 | 1.43 | 13 | 7.41 | 205 | 31 | 41 |
| 4x | 4 | 2.25 | 0.7 | 1.43 | 14.5 | 4.61 | 280 | 42 | 53 |
| 4x | 6 | 3.05 | 0.7 | 1.43 | 16 | 3.08 | 390 | 54 | 66 |
| 4x | 10 | 3.8 | 0.7 | 1.43 | 18.5 | 1.83 | 590 | 75 | 87 |
| 4x | 16 | 4.7 | 0.7 | 1.43 | 21 | 1.15 | 870 | 100 | 113 |
| 4x | 25 | 5.9 | 0.9 | 1.43 | 25.5 | 0.727 | 1365 | 127 | 144 |
| 4x | 35 | 7.1 | 0.9 | 1.43 | 28.5 | 0.524 | 1760 | 158 | 174 |
| 4x | 50 | 8.1 | 1 | 1.52 | 32.5 | 0.387 | 2466 | 192 | 206 |
| 4x | 70 | 9.7 | 1.1 | 1.6 | 37.5 | 0.268 | 3442 | 246 | 254 |
| 4x | 95 | 11.4 | 1.1 | 1.69 | 42.5 | 0.193 | 4690 | 298 | 301 |
| 4x | 120 | 13.1 | 1.2 | 1.86 | 47.5 | 0.153 | 6119 | 346 | 343 |
| 4x | 150 | 14.6 | 1.4 | 1.94 | 52.5 | 0.124 | 7405 | 395 | 387 |
| 4x | 185 | 16.5 | 1.6 | 2.11 | 59 | 9.91 | 8820 | 450 | 434 |
| 4x | 240 | 18.5 | 1.7 | 2.28 | 66.5 | 7.54 | 11865 | 538 | 501 |
| 4x | 300 | 21 | 1.8 | 2.45 | 73.5 | 6.01 | 14716 | 621 | 565 |
| 3×50 + 1×35 | 8 | 1 | 1.52 | 31.1 | 0.387 | 2160 | 192 | 206 | |
| 3×70 + 1×50 | 9.6 | 1.1 | 1.6 | 36.2 | 0.268 | 3010 | 246 | 254 | |
| 3×95 + 1×50 | 11.4 | 1.1 | 1.69 | 40.6 | 0.193 | 3960 | 298 | 301 | |
| 3×120 + 1×70 | 13.1 | 1.2 | 1.86 | 45.4 | 0.153 | 5160 | 346 | 343 | |
| 3×150 + 1×70 | 14.6 | 1.4 | 1.94 | 49.5 | 0.124 | 6150 | 395 | 387 | |
| 3×185 + 1×70 | 16.5 | 1.6 | 2.11 | 54.4 | 9.91 | 7780 | 450 | 434 | |
| 3×240 + 1×95 | 18.4 | 1.7 | 2.28 | 61.5 | 7.54 | 9550 | 538 | 501 | |
| Five cores | |||||||||
| 5x | 1.5 | 1.4 | 0.7 | 1.43 | 13 | 12.1 | 180 | 23 | 31 |
| 5x | 2.5 | 1.8 | 0.7 | 1.43 | 14.5 | 7.41 | 240 | 31 | 41 |
| 5x | 4 | 2.25 | 0.7 | 1.43 | 16 | 4.61 | 335 | 42 | 53 |
| 5x | 6 | 3.05 | 0.7 | 1.43 | 17.5 | 3.08 | 475 | 54 | 66 |
| 5x | 10 | 3.8 | 0.7 | 1.43 | 20 | 1.83 | 720 | 75 | 87 |
| 5x | 16 | 4.7 | 0.7 | 1.43 | 23 | 1.15 | 1060 | 100 | 113 |
| 5x | 25 | 5.9 | 0.9 | 1.43 | 28 | 0.727 | 1645 | 127 | 144 |
| Multicores | |||||||||
| 7x | 1.5 | 1.4 | 0.7 | 1.43 | 13.5 | 12.1 | 220 | 15 | 22 |
| 7x | 2.5 | 1.8 | 0.7 | 1.43 | 15 | 7.41 | 310 | 20.5 | 28 |
| 10x | 1.5 | 1.4 | 0.7 | 1.43 | 16.5 | 12.1 | 310 | 13 | 18.5 |
| 10x | 2.5 | 1.8 | 0.7 | 1.43 | 19 | 7.41 | 440 | 18 | 24.5 |
| 12x | 1.5 | 1.4 | 0.7 | 1.43 | 17 | 12.1 | 370 | 12.5 | 18 |
| 12x | 2.5 | 1.8 | 0.7 | 1.43 | 19.5 | 7.41 | 525 | 17 | 24 |
| 14x | 1.5 | 1.4 | 0.7 | 1.43 | 18 | 12.1 | 430 | 12 | 17 |
| 14x | 2.5 | 1.8 | 0.7 | 1.43 | 20.5 | 7.41 | 610 | 16 | 22 |
| 19x | 1.5 | 1.4 | 0.7 | 1.43 | 19.5 | 12.1 | 560 | 10.5 | 15 |
| 19x | 2.5 | 1.8 | 0.7 | 1.43 | 22.5 | 7.41 | 745 | 14.5 | 19.5 |
| 24x | 1.5 | 1.4 | 0.7 | 1.43 | 22.5 | 12.1 | 710 | 10 | 14 |
| 24x | 2.5 | 1.8 | 0.7 | 1.43 | 25.5 | 7.41 | 1000 | 13 | 18 |
| 30x | 1.5 | 1.4 | 0.7 | 1.43 | 24 | 12.1 | 806 | 9 | 12.5 |
| 30x | 2.5 | 1.8 | 0.7 | 1.43 | 27.5 | 7.41 | 1135 | 12 | 16.5 |
| 37x | 1.5 | 1.4 | 0.7 | 1.43 | 25.5 | 12.1 | 972 | 8 | 12 |
| 37x | 2.5 | 1.8 | 0.7 | 1.43 | 29.5 | 7.41 | 1350 | 11 | 15.5 |
Packing
A: Reel of 1500 m.
B: Reel of 1000 m.
C: Reel of 500 m.
D: Multiple Reels of 1000 m.
E – Length to the client’s requirement.
Steel wooden drum (fumigation)
Cable length in each drum: 500m/1000m or as per actual cable length requirements.
Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Shipping Port:
Shanghai, Qingdao, Tianjin or other ports as per your requirements.
Sea freight:
FOB/C&F/CIF/DAP quotation are all available.
Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 10-20 days if the goods are not in stock,
it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: 30% T/T in advance,70% T/T balance before shipment
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
We are looking forward to your inquiry and nice cooperation.
We are China Construction Underground Power Cable 240 Sq mm Cable 3X240 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
