Cable de cobre TTU 250 MCM 2000V General Cable
Applications.
For use in building and industrial instalations, especially in subterraneas line mainly for underground service.
Voltage of operation : 600 V
Specifications.
The copper conductors type TTU-2kV meets the following specifications and standards:
ASTM B-3 :Copper Annealed or Soft Wires.
ASTM B-8 :Copper Stranded Conductors in Concentric Layers, Hard, Semi-hard or Soft.
NEMA WC-5 : Wires and Cables Insulated with Thermoplastic Material (ICEA S-61-402) for Transmission and Distribution of Electric Power.
Construction.
The conductors type TTU-2 kV are stranded and they are built with soft temper copper, they are also insulated with an uniform layer of Polyethylene (PE) thermoplastic material resistant to the moisture and the heat, over which is applied a protector coating of Chloride of Polyvinyl (PVC). They are always supplied in black color and with different packaging.
1. Copper conductor
2. Insulation of Thermoplastic material PE… 75ºC
3. Jacket of Thermoplastic material PVC
CONDUCTOR MANUFACTURED UNDER STANDARDS:
NEMA WC-5 • ICEA S-61-402 • ASTM B3, B8 • INEN
PACKAGING:
A: Roll of 100 m.
B: Reel of 1500 m.
C: Reel of 1000 m.
D: Reel of 500 m.
E: Multiple reel of 1000 m.
Z – Length to the client’s requirement.
AVAILABLE COLORS:
Cables (Sizes from 8 AWG to 1000 MCM): Black.
HIGHER SIZES (FROM 750 MCM UNTIL 1.000 MCM), UNDER REQUIREMENT.
| CONDUCTOR | ESPESOR DE AISLAMIENTO | DIAMETRO SOBRE AISLAMIENTO | ESPESOR CHAQUETA | DIAMETRO EXTERIOR APROX | PESO TOTAL APROX | CAPACIDAD DE CONDUCCION | |||||
| CALIBRE | NUMERO DE HILOS | Section Approx. | DIAMETRO APROX | PESO APROX | (1) | (2) | |||||
| AWG O MCM | mm2 | mm | kg/km | mm | mm | mm | mm | kg/km | A | A | |
| 8 | 7 | 8.37 | 3.70 | 75.90 | 1.14 | 5.98 | 0.38 | 6.74 | 105.33 | 50 | 70 |
| 6 | 7 | 13.30 | 4.65 | 120.60 | 1.40 | 7.45 | 0.76 | 8.97 | 176.73 | 65 | 95 |
| 4 | 7 | 21.12 | 5.88 | 191.51 | 1.40 | 8.68 | 0.76 | 10.20 | 257.61 | 85 | 125 |
| 2 | 7 | 33.54 | 7.41 | 304.13 | 1.40 | 10.21 | 0.76 | 11.73 | 382.63 | 115 | 170 |
| 1/0 | 19 | 53.52 | 9.45 | 485.31 | 1.65 | 12.75 | 1.14 | 15.03 | 613.68 | 150 | 230 |
| 2/0 | 19 | 67.35 | 10.65 | 610.72 | 1.65 | 13.95 | 1.14 | 16.23 | 751.48 | 175 | 265 |
| 3/0 | 19 | 84.91 | 11.95 | 769.95 | 1.65 | 15.25 | 1.14 | 17.53 | 924.24 | 200 | 310 |
| 4/0 | 19 | 107.41 | 13.40 | 973.97 | 1.65 | 16.70 | 1.14 | 18.98 | 1143.12 | 230 | 360 |
| 250 | 37 | 126.37 | 14.55 | 1157.13 | 1.90 | 18.35 | 1.65 | 21.65 | 1399.94 | 255 | 405 |
| 300 | 37 | 151.85 | 15.95 | 1390.44 | 1.90 | 19.75 | 1.65 | 23.05 | 1651.75 | 285 | 445 |
| 350 | 37 | 177.28 | 17.23 | 1623.30 | 1.90 | 21.03 | 1.65 | 24.33 | 1901.53 | 310 | 505 |
| 500 | 37 | 252.89 | 20.65 | 2315.64 | 1.90 | 24.45 | 1.65 | 27.75 | 2639.07 | 380 | 620 |
| 750 | 61 | 380.81 | 25.34 | 3453.11 | 2.29 | 29.92 | 1.65 | 33.22 | 3878.44 | 475 | 785 |
| 1000 | 61 | 507.74 | 29.26 | 4604.08 | 2.29 | 33.84 | 1.65 | 37.14 | 5085.75 | 545 | 935 |
