China Suppliers Price 25 35 50 70 95mm Copper Electrical Cable
China Suppliers Price 25 35 50 70 95mm Copper Electrical Cable image
Get Latest Price Request a quote
You May Like
Product Details
Model NO.
VV YJV
Current
DC & AC
Insulation Material
PVC / XLPE
Sheath Material
PVC
Material Shape
Round Wire
Wire Core Material
Red Copper Wire
Certification
ISO, CCC, SGS
Model
YJV
Brand
Hongda
Standard
IEC 60502
No. of Cores
1 Core, 2 Cores, 3 Cores, 4 Cores, 5 Cores
Armour
Aluminum/Galvanized Steel/Steel Wires
Transport Package
Steel & Wooden Drum or Customer Requirement
Specification
10 sqmm to 240 sqmm
Trademark
Hongda, accept OEM
Origin
China
HS Code
8544492100
Production Capacity
300km/Month
Product Description
China suppliers price 25 35 50 70 95mm copper electrical cable
Application:
These cables are used for electricity supply in low voltage installation system, They are suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage.
Construction:
| Conductor: | annealed copper or of plain aluminium or aluminium alloy | |
| Insulation: | XLPE / PVC material | |
Armour: |
Aluminum/galvanized steel/steel wires applied helically over the Inner Covering as per IEC 60502-1, or double aluminum/steel tapes and copper/tinned copper wire can also be manufactured upon request. | |
| Sheath: | PVC compound | |
| sheath colour: | black | |
Technical data:
| Temperature range: | |
| during installation: | -5 °C up to +50 °C |
| fixed installed: | -30 °C up to +70 °C |
| at short circuit of max. 5 s: | up to 160 °C |
| Nominal voltage: | Uο/U = 0,6/1 kV |
| Test voltage: | 4 kV |
| Max. operating voltage in three-phase systems: | 1,2 kV |
| Maximal tensile strength: | 50 N/mm² |
| Behaviour in fire: | IEC 60332-1 |
| Minimal inner bending radius: | |
| single core: | 15D |
| multi core: | 12D |
Dimensions:
Single core(unarmoured)
| Nominal Cross Section | Diameter of Conductor (Approx.) | Nominal Insulation Thickness | Nominal Sheath Thickness | Overall Diameter (Approx.) |
|---|---|---|---|---|
| mm^2 | mm | mm | mm | mm |
| 1×1.5 | 1.4 | 0.7 | 1.4 | 5.6 |
| 1×2.5 | 1.8 | 0.7 | 1.4 | 6.0 |
| 1×4 | 2.3 | 0.7 | 1.4 | 6.5 |
| 1×6 | 2.8 | 0.7 | 1.4 | 7.0 |
| 1×10 | 3.6 | 0.7 | 1.4 | 7.8 |
| 1×16 | 4.5 | 0.7 | 1.4 | 8.7 |
| 1×25 | 5.6 | 0.9 | 1.4 | 10.2 |
| 1×35 | 6.7 | 0.9 | 1.4 | 11.3 |
| 1×50 | 8.0 | 1 | 1.4 | 12.8 |
| 1×70 | 9.4 | 1.1 | 1.4 | 14.4 |
| 1×95 | 11.0 | 1.1 | 1.5 | 16.1 |
| 1×120 | 12.4 | 1.2 | 1.5 | 17.8 |
| 1×150 | 13.8 | 1.4 | 1.6 | 19.8 |
| 1×185 | 15.3 | 1.6 | 1.6 | 21.8 |
| 1×240 | 17.5 | 1.7 | 1.7 | 24.4 |
| 1×300 | 19.5 | 1.8 | 1.8 | 26.7 |
| 1×400 | 22.6 | 2 | 1.9 | 30.5 |
| 1×500 | 25.2 | 2.2 | 2.0 | 33.7 |
| 1×630 | 28.3 | 2.4 | 2.2 | 37.4 |
| 1×800 | 31.9 | 2.6 | 2.3 | 41.7 |
| 1×1000 | 35.7 | 2.8 | 2.4 | 46.2 |
Two cores(unarmoured)
| Nominal Cross Section | Diameter of Conductor (Approx.) | Nominal Insulation Thickness | Nominal Sheath Thickness | Overall Diameter (Approx.) |
|---|---|---|---|---|
| mm^2 | mm | mm | mm | mm |
| 2×1.5 | 1.4 | 0.7 | 1.8 | 9.2 |
| 2×2.5 | 1.8 | 0.7 | 1.8 | 10.0 |
| 2×4 | 2.3 | 0.7 | 1.8 | 11.0 |
| 2×6 | 2.8 | 0.7 | 1.8 | 12.0 |
| 2×10 | 3.6 | 0.7 | 1.8 | 13.6 |
| 2×16 | 4.5 | 0.7 | 1.8 | 15.4 |
| 2×25 | 5.6 | 0.9 | 1.8 | 18.4 |
| 2×35 | 6.7 | 0.9 | 1.8 | 20.6 |
| 2×50 | 8.0 | 1 | 1.8 | 23.6 |
| 2×70 | 9.4 | 1.1 | 1.8 | 26.8 |
| 2×95 | 11.0 | 1.1 | 1.9 | 30.2 |
| 2×120 | 12.4 | 1.2 | 2.0 | 33.7 |
| 2×150 | 13.8 | 1.4 | 2.2 | 37.5 |
| 2×185 | 15.3 | 1.6 | 2.3 | 41.6 |
| 2×240 | 17.5 | 1.7 | 2.5 | 46.7 |
| 2×300 | 19.5 | 1.8 | 2.6 | 51.4 |
| 2×400 | 22.6 | 2 | 2.9 | 58.9 |
Three cores(unarmoured)
| Nominal Cross Section | Diameter of Conductor (Approx.) | Nominal Insulation Thickness | Nominal Sheath Thickness | Overall Diameter (Approx.) |
|---|---|---|---|---|
| mm^2 | mm | mm | mm | mm |
| 3×1.5 | 1.4 | 0.7 | 1.8 | 9.6 |
| 3×2.5 | 1.8 | 0.7 | 1.8 | 10.5 |
| 3×4 | 2.3 | 0.7 | 1.8 | 11.6 |
| 3×6 | 2.8 | 0.7 | 1.8 | 12.6 |
| 3×10 | 3.6 | 0.7 | 1.8 | 14.4 |
| 3×16 | 4.5 | 0.7 | 1.8 | 16.3 |
| 3×25 | 5.6 | 0.9 | 1.8 | 19.5 |
| 3×35 | 6.7 | 0.9 | 1.8 | 21.9 |
| 3×50 | 8.0 | 1 | 1.8 | 25.1 |
| 3×70 | 9.4 | 1.1 | 1.9 | 28.7 |
| 3×95 | 11.0 | 1.1 | 2.0 | 32.4 |
| 3×120 | 12.4 | 1.2 | 2.1 | 36.1 |
| 3×150 | 13.8 | 1.4 | 2.3 | 40.3 |
| 3×185 | 15.3 | 1.6 | 2.4 | 44.6 |
| 3×240 | 17.5 | 1.7 | 2.6 | 50.2 |
| 3×300 | 19.5 | 1.8 | 2.7 | 55.2 |
| 3×400 | 22.6 | 2 | 3.0 | 63.3 |
Three cores+1(unarmoured)
| Nominal Cross Section | Diameter of Conductor (Approx.) | Nominal Insulation Thickness | Nominal Sheath Thickness | Overall Diameter (Approx.) | ||
|---|---|---|---|---|---|---|
| mm^2 | (3)mm | (1)mm | (3)mm | (1)mm | mm | mm |
| 3x 16/10 | 4.5 | 3.6 | 0.7 | 0.7 | 1.8 | 17.5 |
| 3x 25/16 | 5.6 | 4.5 | 0.9 | 0.7 | 1.8 | 21.2 |
| 3x 35/16 | 6.7 | 4.5 | 0.9 | 0.7 | 1.8 | 23.8 |
| 3x 50/25 | 8 | 5.6 | 1 | 0.9 | 1.8 | 27.5 |
| 3x 70/35 | 9.4 | 6.7 | 1.1 | 0.9 | 2.0 | 31.7 |
| 3x 95/50 | 11 | 8 | 1.1 | 1 | 2.1 | 35.8 |
| 3×120/70 | 12.4 | 9.4 | 1.2 | 1.1 | 2.3 | 39.9 |
| 3×150/70 | 13.8 | 9.4 | 1.4 | 1.1 | 2.4 | 44.6 |
| 3×185/95 | 15.3 | 11 | 1.6 | 1.1 | 2.6 | 49.5 |
| 3×240/120 | 17.5 | 12.4 | 1.7 | 1.2 | 2.8 | 55.7 |
| 3×300/150 | 19.5 | 13.8 | 1.8 | 1.4 | 3.0 | 61.4 |
| 3×400/185 | 22.6 | 15.3 | 2 | 1.6 | 3.2 | 70.4 |
Four cores(unarmoured)
| Nominal Cross Section | Diameter of Conductor (Approx.) | Nominal Insulation Thickness | Nominal Sheath Thickness | Overall Diameter (Approx.) |
|---|---|---|---|---|
| mm^2 | mm | mm | mm | mm |
| 4×1.5 | 1.4 | 0.7 | 1.8 | 10.4 |
| 4×2.5 | 1.8 | 0.7 | 1.8 | 11.3 |
| 4×4 | 2.3 | 0.7 | 1.8 | 12.5 |
| 4×6 | 2.8 | 0.7 | 1.8 | 13.7 |
| 4×10 | 3.6 | 0.7 | 1.8 | 15.7 |
| 4×16 | 4.5 | 0.7 | 1.8 | 17.8 |
| 4×25 | 5.6 | 0.9 | 1.8 | 21.5 |
| 4×35 | 6.7 | 0.9 | 1.8 | 24.1 |
| 4×50 | 8.0 | 1 | 1.8 | 27.8 |
| 4×70 | 9.4 | 1.1 | 2.0 | 32.0 |
| 4×95 | 11.0 | 1.1 | 2.1 | 36.1 |
| 4×120 | 12.4 | 1.2 | 2.3 | 40.2 |
| 4×150 | 13.8 | 1.4 | 2.4 | 44.9 |
| 4×185 | 15.3 | 1.6 | 2.6 | 49.8 |
| 4×240 | 17.5 | 1.7 | 2.8 | 56.0 |
| 4×300 | 19.5 | 1.8 | 3.0 | 61.7 |
| 4×400 | 22.6 | 2 | 3.2 | 70.7 |
Multi-cores(unarmoured)
| Nominal Cross Section | Diameter of Conductor (Approx.) | Nominal Insulation Thickness | Nominal Sheath Thickness | Overall Diameter (Approx.) |
|---|---|---|---|---|
| mm^2 | mm | mm | mm | mm |
| 5×1.5 | 1.4 | 0.7 | 1.8 | 11.2 |
| 7×1.5 | 1.4 | 0.7 | 1.8 | 12.0 |
| 10×1.5 | 1.4 | 0.7 | 1.8 | 14.8 |
| 12×1.5 | 1.4 | 0.7 | 1.8 | 15.2 |
| 14×1.5 | 1.4 | 0.7 | 1.8 | 16.0 |
| 19×1.5 | 1.4 | 0.7 | 1.8 | 17.6 |
| 21×1.5 | 1.4 | 0.7 | 1.8 | 18.4 |
| 24×1.5 | 1.4 | 0.7 | 1.8 | 20.4 |
| 30×1.5 | 1.4 | 0.7 | 1.8 | 21.6 |
| 40×1.5 | 1.4 | 0.7 | 1.8 | 26.0 |
| 48×1.5 | 1.4 | 0.7 | 1.8 | 26.4 |
| 61×1.5 | 1.4 | 0.7 | 1.9 | 29.0 |
| 5×2.5 | 1.8 | 0.7 | 1.8 | 12.2 |
| 7×2.5 | 1.8 | 0.7 | 1.8 | 13.2 |
| 10×2.5 | 1.8 | 0.7 | 1.8 | 16.4 |
| 12×2.5 | 1.8 | 0.7 | 1.8 | 16.9 |
| 14×2.5 | 1.8 | 0.7 | 1.8 | 17.7 |
| 19×2.5 | 1.8 | 0.7 | 1.8 | 19.6 |
| 21×2.5 | 1.8 | 0.7 | 1.8 | 20.6 |
| 24×2.5 | 1.8 | 0.7 | 1.8 | 22.8 |
| 30×2.5 | 1.8 | 0.7 | 1.8 | 24.1 |
| 40×2.5 | 1.8 | 0.7 | 1.9 | 29.4 |
| 48×2.5 | 1.8 | 0.7 | 1.9 | 29.9 |
| 61×2.5 | 1.8 | 0.7 | 2.0 | 32.8 |
*) Packing: CUT = cable in different lengths on drum or reel, possible cutting at required length.
