Conductor applications:
Stranded 1350 aluminum conductors shown in this section of data are classified as follows:
Class AA For bare conductors usually used in overhead lines.
Class A For conductors to be covered with weather-resistant materials and for bare conductors where greater flexibility is required.
Compact strand conductor for use in bare overhead applications or for use with weather-resistant coverings or insulation is also available.
Classes refer to stranding and are an indication of relative conductor flexibility, AA being the least flexible, C the most flexible.
All Aluminum Stranded Conductor ASC CSA C49 Standard
All Aluminum Stranded Conductor ASC CSA C49 Construction
Bare AAC wire is a concentric-lay-stranded conductor consisting of hard drawn aluminum wires available in both single layer and multi-layer constructions. Huatong AAC conductor ensuring purity of min.99.55% 1350-H19 Aluminum. Temperature for continuous use is up to 75ºC.Aluminum 1350 wires are concentrically stranded and wrapped helically around a central wire. Each successive layer has six wires more than the previous underlying layer.
| Code Word | Sectional Area |
Stranding Wire Diameter |
Overall Diameter |
Approximate Weight |
Breaking Load |
D.A. Resistance |
Current Rating Capacity |
|
| AWG&MCM | mm² | mm | mm | kg/km | kN | ohm /km | A | |
| Rose | 4 | 21.16 | 7/1.96 | 5.89 | 58 | 4.1 | 1.351 | 104 |
| Lily | 3 | 26.65 | 7/2.20 | 6.61 | 73 | 5 | 1.072 | 124 |
| Iris | 2 | 33.61 | 7/2.47 | 7.42 | 92 | 6.2 | 0.8497 | 136 |
| Pansy | 1 | 42.39 | 7/2.77 | 8.33 | 116 | 7.6 | 0.6739 | 157 |
| Poppy | 1/0 | 53.48 | 7/3.12 | 9.36 | 146 | 9.2 | 0.5341 | 180 |
| Aster | 2/0 | 67.42 | 7/3.50 | 10.51 | 184 | 11.6 | 0.4236 | 207 |
| Phlox | 3/0 | 85.03 | 7/3.93 | 11.8 | 232 | 14.1 | 0.336 | 237 |
| Oxlip | 4/0 | 107.23 | 7/4.41 | 13.25 | 293 | 17.7 | 0.2664 | 273 |
| Valerian | 250 | 126.71 | 19/2.91 | 14.57 | 348 | 22.3 | 0.2274 | 305 |
| Daisy | 266.8 | 135.16 | 7/4.96 | 14.9 | 369 | 22.4 | 0.2113 | 313 |
| Laurel | 266.8 | 135.16 | 19/3.01 | 15.05 | 372 | 23.8 | 0.2129 | 317 |
| Peony | 300 | 152 | 19/3.19 | 15.97 | 417 | 26.2 | 0.188 | 340 |
| Tulip | 336.4 | 170.45 | 19/3.38 | 16.91 | 467 | 29.4 | 0.1638 | 364 |
| Daffodil | 350 | 177.35 | 19/3.44 | 17.24 | 488 | 30.6 | 0.1624 | 373 |
| Canna | 397.5 | 201.42 | 19/3.67 | 18.36 | 554 | 34 | 0.1427 | 401 |
| – | 400 | 202.71 | 19/3.68 | 18.43 | 558 | 34.2 | 0.1421 | 402 |
| Goldentuft | 450 | 228 | 19/3.90 | 19.55 | 626 | 37.7 | 0.1263 | 432 |
| Cosmos | 477 | 241.68 | 19/4.02 | 20.12 | 664 | 40 | 0.1188 | 447 |
| Zinnia | 500 | 253.35 | 19/4.12 | 20.6 | 695 | 41.9 | 0.1132 | 459 |
| – | 550 | 278.71 | 37/3.09 | 21.67 | 768 | 48 | 0.1033 | 485 |
| Dahlia | 556.5 | 282 | 19/4.34 | 21.73 | 774 | 46.7 | 0.1018 | 489 |
| Meadowsweet | 600 | 304 | 37/3.23 | 22.63 | 838 | 52.4 | 0.0948 | 513 |
| Orchid | 636 | 322.26 | 37/3.33 | 23.31 | 888 | 55.6 | 0.0896 | 531 |
| Heuchera | 650 | 329.35 | 37/3.36 | 23.56 | 908 | 56.8 | 0.0876 | 538 |
| Varbena | 700 | 354.71 | 37/3.49 | 24.45 | 978 | 61.1 | 0.0814 | 562 |
| Violet | 715.5 | 362.58 | 37/3.53 | 24.74 | 1000 | 62.5 | 0.0797 | 570 |
| Patunia | 750 | 380 | 37/3.61 | 25.32 | 1048 | 64.2 | 0.0758 | 585 |
| Arbutus | 795 | 402.84 | 37/3.72 | 26.06 | 1112 | 68.1 | 0.0715 | 605 |
| – | 800 | 405.35 | 37/3.73 | 26.14 | 1118 | 68.5 | 0.0712 | 608 |
| Anemone | 874.5 | 443.1 | 37/3.90 | 27.33 | 1222 | 73.3 | 0.0653 | 641 |
| Cockscomb | 900 | 456.06 | 37/3.96 | 27.73 | 1257 | 75.4 | 0.0633 | 657 |
| Magnolia | 954 | 483.42 | 37/4.07 | 28.55 | 1333 | 80 | 0.0597 | 675 |
| Hawkweed | 1000 | 506.71 | 37/4.17 | 29.23 | 1396 | 83.8 | 0.0568 | 693 |
| Bluebell | 1033.5 | 523.68 | 37/4.24 | 29.72 | 1445 | 86.6 | 0.0551 | 706 |
| – | 1100 | 557.35 | 61/3.41 | 30.7 | 1539 | 96.1 | 0.0518 | 733 |
| Marigold | 1113 | 563.93 | 61/3.43 | 30.89 | 1559 | 97.2 | 0.0512 | 738 |
| Hawthorn | 1192.5 | 604.26 | 61/3.55 | 31.95 | 1670 | 104.1 | 0.0479 | 767 |
| – | 1200 | 608.06 | 61/3.56 | 32.08 | 1679 | 102.7 | 0.0476 | 771 |
| Narcissus | 1272 | 644.51 | 61/3.66 | 33.02 | 1781 | 108.8 | 0.045 | 797 |
| – | 1300 | 658.71 | 61/3.70 | 33.37 | 1818 | 111.2 | 0.044 | 807 |
| Columbine | 1351.5 | 684.84 | 61/3.78 | 34.01 | 1893 | 115.6 | 0.0423 | 825 |
| – | 1400 | 709.42 | 61/3.84 | 34.63 | 1958 | 117.4 | 0.0407 | 842 |
| Carnation | 1431 | 725.1 | 61/3.89 | 35.03 | 2004 | 119.9 | 0.04 | 854 |
| – | 1500 | 760.06 | 61/3.98 | 35.85 | 2098 | 125.7 | 0.0381 | 877 |
| Gladiolus | 1510.5 | 765.35 | 61/3.99 | 35.99 | 2116 | 126.5 | 0.0377 | 881 |
| Corepsis | 1590.5 | 805.68 | 61/4.09 | 36.91 | 2226 | 133.2 | 0.0358 | 907 |
| – | 1600 | 810.71 | 61/4.11 | 37.04 | 2238 | 134.1 | 0.0358 | 910 |
| – | 1700 | 861.42 | 61/4.23 | 38.15 | 2378 | 142.6 | 0.0335 | 942 |
| – | 1800 | 912.06 | 61/3.57 | 39.28 | 2521 | 153.9 | 0.0316 | 975 |
