Cable Wire AAAC (All Aluminium Alloy Conductors)

Cable Wire AAAC (All Aluminium Alloy Conductors) image

Get Latest Price Request a quote

Product Details

Model NO.

aaac

Current

DC & AC

Insulation Material

Bare

Sheath Material

Material Shape

Round Wire

Wire Core Material

Aluminium Alloy / AAAC

Certification

ISO, CCC, SGS

Model

AAAC Conductor

Brand

Hongda

Material

All Aluminum Alloy

Transport Package

Drum or as Customer Require

Specification

6AWG to 3500MCM

Trademark

Hongda Cable

Origin

China

HS Code

76149000

Production Capacity

200km/Day

Product Description

AAAC ( All Aluminium Alloy Conductors )

Concentric lay stranded Aluminium Alloy Conductors (AAAC) are made out of high strength Aluminium-Magnesium-Silicon Alloy. Midal manufactures and supply AAAC with different variants of electrical grade alloy type 6101 and 6201. one or more strands of hard drawn 1350 aluminium alloy.

These conductors are designed to get better strength to weight ratio and offer improved electrical properties, excellent sag-tension characteristics, and superior corrosion resistance when compared with ACSR. As compared to a conventional ACSR conductor, the lighter weight, comparable strength & current carrying capacity, lower electrical losses and superior corrosion resistance have given AAAC a wide acceptance in the distribution and medium & high voltage transmission lines..

Midal can manufacture & supply AAAC on Non returnable wooden/steel reels or Returnable steel reels.

Features

high strength to weight ratio
better sag characteristics
improved electrical properties
excellent resistance to corrosion

Specifications

AAAC manufactured by Midal meets or exceeds the requirements of all international standards like ASTM, AS, BS, CSA, DIN, IEC, NFC, SS -etc

AAAC – Aluminum Alloy Conductors BS EN 50183

Area.	No. of Wires	Diameter		Weight	Rated Strength	D.C. Resistance at 20ºC	Standard Length
Area.	No. of Wires	Wire	Cond	Weight	Rated Strength	D.C. Resistance at 20ºC	Standard Length
mm2		mm	mm	kg/km	kN	ohm/km	m±5%
15.9	7	1.7	5.1	43.3	4.69	2.0701	3000
24.2	7	2.1	6.3	66.2	7.15	1.3566	3000
34.4	7	2.5	7.5	93.8	10.14	0.9572	3000
49.5	7	3	9	135.1	14.6	0.6647	3000
48.3	19	1.8	9	132.7	14.26	0.6841	3000
65.8	19	2.1	10.5	180.7	19.41	0.5026	2000
93.3	19	2.5	12.5	256	27.51	0.3546	2000
117	19	2.8	14	321.2	34.51	0.2827	2000
147.1	37	2.25	15.8	405.3	43.4	0.2256	2000
181.6	37	2.5	17.5	500.3	53.58	0.1827	2000
242.5	61	2.25	20.3	670.3	71.55	0.1373	2000
299.4	61	2.5	22.5	827.5	88.33	0.1112	2000
400.1	61	2.89	26	1105.9	118.04	0.0832	2000
499.8	61	3.23	29.1	1381.4	147.45	0.0666	2000
626.2	91	2.96	32.6	1737.7	184.73	0.0534	2000
802.1	91	3.35	36.9	2225.8	236.62	0.0417	2000
999.7	91	3.74	41.1	2774.3	294.91	0.0334	2000

All Aluminum Alloy Conductors (AAAC) BS EN 50183

Designation	Area	Stranding		Overall Dia.	Nominal Breaking Load	D.C. Resistance at 20ºC	Standard Weight	Standard Length
	mm2	No	mm	mm	kN	ohm/km	kg/km	m±5%
ASTER 22	22	7	2	6	7.15	1.4989	60	4000
ASTER 34.4	34.4	7	2.5	7.5	11.17	0.9593	93.8	3000
ASTER 54.6	54.6	7	3.15	9.45	17.73	0.6042	148.9	3000
ASTER 75.5	75.5	19	2.25	11.3	24.55	0.4388	207.4	3000
ASTER 117	117	19	2.8	14	38.02	0.2833	321.2	2000
ASTER 148	148.1	19	3.15	15.8	48.12	0.2239	406.5	2000
ASTER 181.6	181.6	37	2.5	17.5	59.03	0.1831	500.3	2000
ASTER 228	227.8	37	2.8	19.6	74.04	0.146	627.6	2000
ASTER 288	288.3	37	3.15	22.1	93.71	0.1154	794.3	2000
ASTER 366	366.2	37	3.55	24.9	115.36	0.0908	1008.9	2000
ASTER 570	570.2	61	3.45	31.1	185.33	0.0585	1576	2000
ASTER 851	850.7	91	3.45	38	276.47	0.0394	2360.7	2000
ASTER 1144	1143.5	91	4	44	360.22	0.0293	3173.4	2000
ASTER 1600	1595.9	127	4	52	502.72	0.021	4427.5	2000

AAAC – All Aluminum Alloy Conductors ASTM B 399

Area		Stranding	Approx. Dia.	Weight	Nominal Breaking Load	D.C. Resistance at 20ºC	Standard Length
Nominal	Actual	Stranding	Approx. Dia.	Weight	Nominal Breaking Load	D.C. Resistance at 20ºC	Standard Length
AWG or MCM	mm2	mm	mm	kg/km	kN	ohm/km	m±5%
6	13.3	7/1.554	4.67	37	4.22	2.5199	3500
4	21.15	1/1.961	5.89	58	6.71	1.5824	3000
2	33.63	7/2.474	7.42	93	10.68	0.9942	2500
1/0	53.48	7/3.119	9.36	148	16.97	0.6256	2000
2/0	67.42	7/3.503	10.51	186	20.52	0.4959	3500
3/0	85.03	7/3.932	11.8	234	25.86	0.3936	3000
4/0	107.23	7/4.417	13.26	296	32.63	0.3119	2000
250	126.66	19/2.913	14.57	349	38.93	0.2642	2000
300	152.1	19/63.193	15.97	419	46.77	0.2199	3000
350	177.35	19/3.447	17.24	489	52.25	0.1887	3000
400	202.71	19/3.686	18.43	559	59.74	0.165	2500
450	228	19/3.909	19.55	629	67.19	0.1467	2000
500	253.35	19/4.120	20.6	698	74.64	0.1321	2000
550	278.6	37/3.096	21.67	768	83.8	0.1202	2000
600	303.8	37/3.233	22.63	838	91.38	0.1102	2000
650	329.25	37/3.366	23.56	908	97.94	0.1016	2000
700	354.55	37/3.493	24.45	978	102.2	0.0944	3500
750	380.2	37/3.617	25.32	1049	109.6	0.088	3000
800	405.15	37/3.734	26.14	1117	116.8	0.0826	3000
900	456.16	37/3.962	27.73	1258	131.5	0.0733	3000
1000	506.71	37/4.176	26.23	1300	146.1	0.066	2500
