Cable Unarmored Tray Tc (XHHW-2) Tc-Er VFD XLPE/PVC Multi-Conductor 600V

Cable Unarmored Tray Tc (XHHW-2) Tc-Er VFD XLPE/PVC Multi-Conductor 600V image

Get Latest Price Request a quote

Product Details

Model NO.

Cable Unarmored Tray TC(XHHW-2) TC-ER

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC, CE

Model

VFD Tray Cable

Brand

OEM

Transport Package

Wooden Drum

Specification

2.5~400sqmm

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

500 Kilometer/Month

Product Description

VOLTAGE

600 V

PRODUCT CONSTRUCTION

Conductor:
- 3 conductor, 14 AWG through 750 KCMIL in compliance with Class B strand ASTM B8, ASTM B3 or ASTM B33 with options available
Insulation:
- Cross-linked Polyethylene (Type XHHW-2). 90°C DRY/WET
Ground:
- Tri-sectional symmetrical grounds in contact with shield, in compliance with Class B strand ASTM B8, ASTM B3 or ASTM B33, options available
Metallic Shield:
- Helically applied copper tape, 100% coverage*
Jacket:
- Polyvinyl Chloride (PVC), Sunlight Resistant in all colors

CERTIFICATION/COMPLIANCES

UL 1277, Tray Cable (TC-ER)
UL 44 Type XHHW-2
IEEE 1202/FT4, UL 1685
ICEA T-29-520
SUN RES in all colors
DIR BUR
-40°C Cold Bend
OIL RES I**

Stranded Bare (ASTM B8) Annealed Copper Conductors
XLPE (XHHW-2 Rated) Insulated Conductors
Tri-sectional Grounding Conductors
Polypropylene Fillers
Dual Helically Applied Bare/Tinned Copper Tape Shield
FR PVC Outer Protective Jacket

CONDUCTOR COUNT	CONDUCTOR SIZE	BARE GROUNDING CONDUCTOR	NOMINAL OVERALL DIAMETER OF CABLE	CABLE WEIGHT	AMPACITY 30°C AMBIENT	MAX. PULLING TENSION(PULLING EYE)	MIN. BEND RADIUS (PULL)
	AWG	AWG	IN	LBS/1000FT	AMPS	LB	IN
3C+ 3G	14	3 X 18	0.40	130	25	99	7.21
3C+ 3G	12	3 X 16	0.44	172	30	157	7.91
3C+ 3G	10	3 X 14	0.50	255	40	249	9.02
3C+ 3G	8	3 X 14	0.66	386	55	396	11.85
3C+ 3G	6	3 X 12	0.74	539	75	630	13.29
3C+ 3G	4	3 X 12	0.84	710	95	1002	15.11
3C+ 3G	2	3 X 10	1.00	1060	130	1593	18.08
3C+ 3G	1	3 X 10	1.13	1299	145	2009	20.37
3C+ 3G	1/0	3 X 10	1.22	1549	170	2534	21.92
3C+ 3G	2/0	3 X 10	1.31	1843	195	3194	23.59
3C+ 3G	3/0	3 X 8	1.42	2267	225	4027	25.56
3C+ 3G	4/0	3 X 8	1.54	2752	260	5078	27.73
3C+ 3G	250	3 X 8	1.74	3259	290	6000	31.37
3C+ 3G	350	3 X 6	1.96	4491	350	8400	35.37
3C+ 3G	500	3 X 6	2.24	5975	430	12000	40.33

Packing shipping

Any problem and inquiry pls contact with Tina

We are China Cable Unarmored Tray Tc (XHHW-2) Tc-Er VFD XLPE/PVC Multi-Conductor 600V manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
