Cable Pre Assemble Torsade Aluminum Prc 1kv 335+154.6+116mm2 350+154.6+116mm2 370+154.6+1*16mm2

Cable Pre Assemble Torsade Aluminum Prc 1kv 3*35+1*54.6+1*16mm2 3*50+1*54.6+1*16mm2 3*70+1*54.6+1*16mm2 image

Get Latest Price Request a quote

Product Details

Model NO.

PRC Cable 3X70+54.60+16 mm2

Current

AC Cable

Insulation Material

XLPE

Sheath Material

No Sheath

Material Shape

Round Wire

Wire Core Material

Aluminum

Certification

ISO, CCC

Model

ABC Cable

Brand

OEM

Transport Package

Wooden Drum

Specification

PRC Cable 3X70+54.6+16 mm2

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

500 Kilometer/Month

Product Description

1. Applications

To supply 120-volt aerial service for temporary service at construction sites, outdoor or street lighting. For service at 600 volts or lower at a conductor temperature of 75 maximum.

2. Construction

A concentric strand or aluminum conductor, cross-linked polyethylene insulation, concentric strand AAAC 6201 supporting or self-supporting.

3. Standards

NFC33-209.
3. Parameter

Aerial Bundle Cable 370+154.6+1*16mm2
Phase conductor
cross section area	mm2	70
nmber of wires	No	12
Insulation thickness	mm	1.8
D.C. Resistance at 20ºC	Ω/km	0.443
Messager conductor
cross section area	mm2	54.6
nmber of wires	No	7
Insulation thickness	mm	1.6
D.C. Resistance at 20ºC	Ω/km	0.63
Minium Breaking Strength	daN	1660
Public lighting conductor
cross section area	mm2	16
nmber of wires	No	7
Insulation thickness	mm	1.2
D.C. Resistance at 20ºC	Ω/km	1.91
Cable Overall Diameter	mm	38
Cable Weight	kg/km	1042

Henan Hongda Cable Co., Ltd. located in No. 3, Changping Road, ZhanDian District, Jiaozuo, Wuzhi. Our factroy established in March of 2004. Our owns registered capital of RMB Fifty-one million six hundred and eighty thousand. Hongda Cable covers an area of 100,000 square meters, including 50,000 square meters of building area. We have more than 120 staff members and professional workers. our fixed assets of 90,000,000. We can provide more than 100 varieties, tens of thousands of specifications of wire and cable, with 10000 km annual production capacity

Henan Hongda Cable Co. Ltd. is the original Zhengzhou Hongda Cable Co. Ltd. established enterprise expansion. The company is committed to system R&D, design, manufacturing, marketing and service of cable products,We mainly aim at managing cross-linking XLPE insulated power cables, PVC insulated power cables, plastic insulated control cables, insulated overhead cables, and stranded aluminum and ACSR. At present, the cables’ biggest cross area is 800 square meters with a maximum electric power of 35KV. The company has more than 300 (sets) domestic and oversea-leading production and testing equipment

Our factory has advanced equipment of 20 sets production lines and 25 sets testing machinas, The production capacity is more than 12 million kilometers. We have skillful staff over 20-year experience,before starting working, every worker need to be trained professionally. Therefore, we can promise the product will be 100% quantified.

In our factory, every roll wire need to be test strictly, We wil test resistance, insulation thickness, the tension, stretch and so on. Before packing, every cable need to be test quantified, and we can make promise the 100% quantified.

Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas
Welcome your inquiry to Tina

We are China Cable Pre Assemble Torsade Aluminum Prc 1kv 3*35+1*54.6+1*16mm2 3*50+1*54.6+1*16mm2 3*70+1*54.6+1*16mm2 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
