Cable Electrique Xvb Fil Electrique 3G4 3G6 4G2.5 Copper Low Voltage Xvb Xvb-F2 1kv Cable

Cable Electrique Xvb Fil Electrique 3G4 3G6 4G2.5 Copper Low Voltage Xvb Xvb-F2 1kv Cable image

Get Latest Price Request a quote

Product Details

Model NO.

XVB cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE

Model

YJV

Brand

Hongda Cable

Standard

IEC 60502

Rated Voltage

600/1000 Volts

Suitable for

Direct Burial Without Extra Mechanical Protection

Flame Retardant

IEC 60332

Transport Package

Drum or as Customer Require

Specification

1.5mm2 to 400mm2

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

10km/Day

Product Description

cable electrique XVB fil electrique 3G4 3G6 4G2.5 Copper low voltage XVB XVB-F2 1kV Cable

APPLICATION

Installation cable with XLPE insulation, for domestic and industrial installations. Suited for indoor and outdoor use. This cable can be used in cable duct, cable tray, open air if protected from direct UV rays, embedded in concret or cement or walls, in industries and houses. Not suitable for installation in ground.

XVB

Power cable 0,6/1 kV with Cu conductors, XLPE insulated and PVC sheathed

XVB F2

Power cable 0,6/1 kV with Cu conductors, XLPE insulated and Fire-retardant PVC sheathed

CONSTRUCTION
Conductor:	Class 1 Solid copper Class 2 Stranded copper
Insulation	XLPE (Cross-Linked Polyethylene)
Filler	Filling compound or tape
Outer sheath	Fire-retardant PVC (Polyvinyl chloride)
Sheath Colour	Grey or Black

XVB F2 / XVB Cable – Technical data and tests
Standards	: IEC 60502
Nominal voltage U0/U	: 0,6/1 kV
Test voltage (50 Hz)	: 4 kV
Maximun voltage Um	: 1,2 kV
Maximun operating temperature	: +90° C
Maximun short circuit temperature	: +250° C
Min. operating temperature (without mechanical shocks)	: -25° C
Minimum installation and use temp.	: -10° C
Minimum bending radius per D cable diameter (in mm)	: 15 x D Single core : 12 x D multi core
Core colours	single core : black or yellow-green two cores : blue-brown three cores : brown-black-blue ; brown-black-gray (4 mmq) or Y/G-blue-brown) four cores : blue-brown-black-gray (or Y/G instead blue) five cores : blue-brown-black-gray-Y/G (or black instead Y/G)
Sheath colour	: black

Cable Parameter

Section	Resistance at 20°C	NOMINAL THICKNESS OF INSULATION	External Diameter	Weight
(mm2)	(Ohm/km)	(mm)	(mm)	(kg/km)
1×1,5	12,1	0.7	4,81	36
1×2,5	7,41	0.7	5,06	45
1×4	4,61	0.7	5,55	61
1×6	3,08	0.7	6,35	86
1×10	1,83	0.7	7,10	128
1×16	1,15	0.7	8,36	184
1×25	0,727	0.9	9,88	281
1×35	0,524	0.9	11,00	370
1×50	0,387	1	12,40	527
1×70	0,268	1.1	14,70	743
1×95	0,193	1.1	16,70	1008
1×120	0,153	1.2	18,10	1210
1×150	0,124	1.4	20,34	1513
1×185	0.0991	1.6	22,60	1836
1×240	0,0775	1.7	25,25	2466
1×300	0.0601	1.8	28,70	3000
1×400	0.047	2	32,60	3888
2×1,5	12,1	0.7	8,05	93
2×2,5	7,41	0.7	8,70	119
2×4	4,61	0.7	9,76	163
2×6	3,08	0.7	11,10	221
2×10	1,83	0.7	12,64	325
2×16	1,15	0.7	15,86	527
2×25	0,727	0.9	20,30	845
2×35	0,524	0.9	21,40	1039
3×1,5	12,1	0.7	8,52	110
3×2,5	7,41	0.7	9,22	144
3×4	4,61	0.7	10,23	199
3×6	3,08	0.7	11,75	274
3×10	1,83	0.7	13,47	416
3×16	1,15	0.7	16,88	666
3×25	0,727	0.9	20,21	1011
3×35	0,524	0.9	22,90	1334
4×1,5	12,1	0.7	9,25	132
4×2,5	7,41	0.7	10,04	175
4×4	4,61	0.7	11,17	245
4×6	3,08	0.7	12,94	345
4×10	1,83	0.7	14,83	522
4×16	1,15	0.7	18,50	835
4×25	0,727	0.9	22,55	1295
4×35	0,524	0.9	25,30	1698
5×1,5	12,1	0.7	10,07	160
5×2,5	7,41	0.7	11,01	214
5×4	4,61	0.7	12,20	298
5×6	3,08	0.7	14,21	421
5×10	1,83	0.7	16,36	643
5×16	1,15	0.7	20,25	1019
5×25	0,727	0.9	25,30	1617
5×35	0,524	0.9	28,00	2085
