Product Details
Product Description
Construction
Phase Conductor: Aluminium
Neutral Non-messenger Conductor: Aluminium
Neutral Messenger Conductor: Aluminium Alloy
Street Lighting Conductor: Aluminium
Insulation: XLPE or PE or PVC(weathering resistance)
Standard:NF C33-209, BS 7870-5, GB/T 12527, IEC 60502
Application
It is extensively used in overhead electric power transmission and distribution lines, especially in rebuilding
of urban and forest region electrified wire netting. This cable improves safety and reliance of electrified wire
netting.
Operating Characteristics
Rated Voltage: Up to and including 0.6/1(1.2)kV 11kv 33kv
Max. Operating Temperature of Conductor: 90oC(XLPE), 70oC(PE), 70oC(PVC)
Max. Short-circuit Temperature of Conductor: 250oC(XLPE), 130oC(PE), 160oC(PVC)
Min. Ambient Temperature under Installation: -20oC
Technical Characteristics Based on Standard NF C 33-209
| Designation | Conductor | Average thickness of insulation (XLPE) |
Insulated conductor |
||||||
| Conductor type | Nominal area | Number of wires | Max. D.C. resistance at 20oC |
Diameter of conductor |
Min. breaking load |
Overall diameter |
|||
| Min. | Max. | Min. | Max. | ||||||
| mm2 | No. | Ω/km | mm | mm | kN | mm | mm | mm | |
| Phase or neutral non- messenger or street lighting | 16 | 7 | 1.91 | 4.6 | 5.1 | 1.9 | 1.2 | 7.0 | 7.8 |
| 25 | 7 | 1.20 | 5.8 | 6.3 | 3.0 | 1.4 | 8.6 | 9.4 | |
| 35 | 7 | 0.868 | 6.8 | 7.3 | – | 1.6 | 10.0 | 10.9 | |
| 50 | 7 | 0.641 | 7.9 | 8.4 | – | 1.6 | 11.1 | 12.0 | |
| 70 | 12 | 0.443 | 9.7 | 10.2 | – | 1.8 | 13.3 | 14.2 | |
| 95 | 19 | 0.320 | 11.0 | 12.0 | – | 1.8 | 14.6 | 15.7 | |
| 120 | 19 | 0.253 | 12.0 | 13.1 | – | 1.8 | 15.6 | 16.7 | |
| 150 | 19 | 0.206 | 13.9 | 15.0 | – | 1.7 | 17.3 | 18.6 | |
| Neutral messenger | 54.6 | 7 | 0.63 | 9.2 | 9.6 | 16.6 | 1.6 | 12.3 | 13.0 |
| 70 | 7 | 0.50 | 10.0 | 10.2 | 20.5 | 1.5 | 12.9 | 13.6 | |
| 95 | 19 | 0.343 | 12.2 | 12.9 | 27.5 | 1.6 | 15.3 | 16.3 | |
Packing shipping
Any problem and inquiry pls contact with Tina
We are China Cable 11kv XLPE Overhead Aluminium Conductor ABC Aerial Bunched Power Cable Price manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
