BS 6724 LSZH Sheath 0.6/1kv LV Power Swa Armored Cable

BS 6724 LSZH Sheath 0.6/1kv LV Power Swa Armored Cable image

Get Latest Price Request a quote

Product Details

Model NO.

SWA cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, SGS

Model

Armor Cable

Brand

Hongda

Armoured

Steel Wire or Steel Tape

Transport Package

Steel & Wooden Drum

Specification

1.5mm2 to 400mm2

Trademark

Hongda Cable

Origin

China

HS Code

8544492100

Production Capacity

300km/Month

Product Description

BS 6724 SWA Armoured LSZH Sheath 0.6/1kV LV Power Armour Cable

1. Overview

Low Voltage Power Cables, Aluminum and Copper conductors of voltage range:0.6/1.0 kV.

2. Cable Types

Copper Conductor Cables

Aluminium Conductor Cables

Thermoplastic/ PVC Insulated Cables

Thermoset/XLPE Insulated Cables

Armoured/ Non – Armoured Cables

Single core cables up to and including 1000 mm2

2 core cables up to and including 95 mm2

3, 4 core & 4 core with reduced neutral cables up to and including 500 mm2

3. Applicable Standards

IEC 60502 (Part 1)”PVC/ XLPE insulated cables” single core /multi-core BS 5467 for XLPE insulated Armoured cables

BS 7889 for XLPE insulated single core unarmoured cables

4. Cables Include:

4.1 BS 6724 SWA LSZH 0.6/1kV Cable

4.1.1 Cable construction

Conductor	Class 2 stranded copper conductor according to BS EN 60228
Insulation	XLPE (Cross-Linked Polyethylene)
Bedding	LSZH (Low Smoke Zero Halogen) Type LTS1 according to BS 7655
Armour	SWA (Steel Wire Armour)
Sheath	LSZH (Low Smoke Zero Halogen) Type LTS1 according to BS 7655

4.1.2 Electrical Characteristics

Dimensions – BS6724 XLPE/LSZH/SWA/LSZH (Copper)

No. of Cores	Nominal Cross Sectional Area	Nominal Thickness of Insulation	Nominal Overall Diameter mm		Nominal Weight
No. of Cores	mm²	mm	Under Armour	Overall	kg/km
2	1.5	0.6	7.3	12.1	302
2	2.5	0.7	8.5	13.6	346
2	4	0.7	9.4	14.7	410
2	6	0.7	10.5	15.9	499
2	10	0.7	12.3	18	648
2	16	0.7	14.3	20.4	978
2	25	0.9	14.7	20.4	1290
2	35	0.9	16.8	23.3	1500
2	50	1	19	25.8	1890
2	70	1.1	22	29	2450
2	95	1.1	25.1	33.1	3300
2	120	1.2	27.9	36.1	4020
2	150	1.4	30.9	39.3	4750
3	1,5	0.6	7.8	12.6	330
3	2.5	0.7	9.2	14.1	390
3	4	0.7	10	15.3	464
3	6	0.7	11.2	16.6	568
3	10	0.7	13.1	19.5	866
3	16	0.7	15.3	21.6	1152
3	25	0.9	18.9	23.6	1800
3	35	0.9	21.3	25.7	2230
3	50	1	21.7	28.5	2490
3	70	1.1	25.2	32.2	3290
3	95	1.1	28.8	37	4440
3	120	1.2	32	40.4	5470
3	150	1.4	35.9	45.5	6930
3	185	1.6	40	49.8	8350
3	240	1.7	44.9	55.1	10400
3	300	1.8	49.8	60.2	12600
3	400	2	55.8	66.6	14600
4	1.5	0.6	8.5	13.3	365
4	2.5	0.7	9.9	15	438
4	4	0.7	11	16.4	532
4	6	0.7	12.3	18.7	764
4	10	0.7	14.5	21.1	1013
4	16	0.7	17	23.4	1360
4	25	0.9	21	26.1	2160
4	35	0.9	23.6	28.6	2690
4	50	1	25	32	3130
4	70	1.1	29.5	37.7	4500
4	95	1.1	33.3	41.7	5600
4	120	1.2	37.5	47.1	7400
4	150	1.4	41.6	51.4	8780
4	185	1.6	46.4	56.6	10630
4	240	1.7	52.6	63	13390
4	300	1.8	58	68.8	16290
4	400	2	65.4	78.1	19800
5	1.5	0.6	9.7	14.3	410
5	2.5	0.7	11.7	16.1	470
5	4	0.7	13	17.8	710
5	6	0.7	14.5	20	876
5	10	0.7	17.2	22.9	1165
5	16	0.7	20	26.6	1742
5	25	0.9	24.7	31.5	2323
5	35	0.9	27.8	34.8	2932
5	50	1	32.4	40.4	4192
7	1.5	0.6	10.2	15.2	470
7	2.5	0.7	12.3	17.1	600
7	4	0.7	13.6	19.1	881
12	1.5	0.6	13.7	19.4	780
12	2.5	0.7	16.3	22.4	1000
19	1.5	0.6	16.2	22.2	1000
19	2.5	0.7	19.9	26.6	1540
27	1.5	0.6	20	26.7	1500
27	2.5	0.7	24	30.7	1950
37	1.5	0.6	22.3	29	1800
37	2.5	0.7	26.9	33.8	2350

Class 2 Stranded Conductors for Single Core and Multi-Core Cables

Nominal Cross Sectional Area	Minimum No. Of Wires In Conductor						Maximum Resistance of Conductor At 20ºC
mm²	Circular		Circular Compacted		Shaped		Annealed Copper Conductor
mm²	Cu	Al	Cu	Al	Cu	Al	Plain Wires ohms/km
1.5	7	–	6	–	–	–	12.1
2.5	7	–	6	–	–	–	7.41
4	7	–	6	–	–	–	4.61
6	7	–	6	–	–	–	3.08
10	7	7	6	6	–	–	1.83
16	7	7	6	6	–	–	1.15
25	7	7	6	6	6	6	0.727
35	7	7	6	6	6	6	0.524
50	19	19	6	6	6	6	0.387
70	19	19	12	12	12	12	0.268
95	19	19	15	15	15	15	0.193
120	37	37	18	15	18	15	0.153
150	37	37	18	15	18	15	0.124
185	37	37	30	30	30	30	0.0991
240	37	37	34	30	34	30	0.0754

4.2 BS 5467 SWA PVC 0.6/1kV Cable

4.2.1 Cable Construction:

Conductor	Class 2 stranded copper conductor according to BS EN 60228
Insulation	XLPE (Cross-Linked Polyethylene)
Bedding	PVC (Polyvinyl Chloride)
Armour	SWA (Steel Wire Armour)
Sheath	PVC (Polyvinyl Chloride)

4.2.2 Electrical Characteristics

Dimensions – BS5467 XLPE/PVC/AWA/PVC (Copper)

No. of Cores	Nominal Cross Sectional Area	Nominal Thickness of Insulation	Nominal Overall Diameter mm		Nominal Weight
No. of Cores	mm²	mm	Under Armour	Overall	kg/km
2	1.5	0.6	7.3	12.1	302
2	2.5	0.7	8.5	13.6	346
2	4	0.7	9.4	14.7	410
2	6	0.7	10.5	15.9	499
2	10	0.7	12.3	18	648
2	16	0.7	14.3	20.4	978
2	25	0.9	14.7	20.4	1290
2	35	0.9	16.8	23.3	1500
2	50	1	19	25.8	1890
2	70	1.1	22	29	2450
2	95	1.1	25.1	33.1	3300
2	120	1.2	27.9	36.1	4020
2	150	1.4	30.9	39.3	4750
3	1,5	0.6	7.8	12.6	330
3	2.5	0.7	9.2	14.1	390
3	4	0.7	10	15.3	464
3	6	0.7	11.2	16.6	568
3	10	0.7	13.1	19.5	866
3	16	0.7	15.3	21.6	1152
3	25	0.9	18.9	23.6	1800
3	35	0.9	21.3	25.7	2230
3	50	1	21.7	28.5	2490
3	70	1.1	25.2	32.2	3290
3	95	1.1	28.8	37	4440
3	120	1.2	32	40.4	5470
3	150	1.4	35.9	45.5	6930
3	185	1.6	40	49.8	8350
3	240	1.7	44.9	55.1	10400
3	300	1.8	49.8	60.2	12600
3	400	2	55.8	66.6	14600
4	1.5	0.6	8.5	13.3	365
4	2.5	0.7	9.9	15	438
4	4	0.7	11	16.4	532
4	6	0.7	12.3	18.7	764
4	10	0.7	14.5	21.1	1013
4	16	0.7	17	23.4	1360
4	25	0.9	21	26.1	2160
4	35	0.9	23.6	28.6	2690
4	50	1	25	32	3130
4	70	1.1	29.5	37.7	4500
4	95	1.1	33.3	41.7	5600
4	120	1.2	37.5	47.1	7400
4	150	1.4	41.6	51.4	8780
4	185	1.6	46.4	56.6	10630
4	240	1.7	52.6	63	13390
4	300	1.8	58	68.8	16290
4	400	2	65.4	78.1	19800
5	1.5	0.6	9.7	14.3	410
5	2.5	0.7	11.7	16.1	470
5	4	0.7	13	17.8	710
5	6	0.7	14.5	20	876
5	10	0.7	17.2	22.9	1165
5	16	0.7	20	26.6	1742
5	25	0.9	24.7	31.5	2323
5	35	0.9	27.8	34.8	2932
5	50	1	32.4	40.4	4192
7	1.5	0.6	10.2	15.2	470
7	2.5	0.7	12.3	17.1	600
7	4	0.7	13.6	19.1	881
12	1.5	0.6	13.7	19.4	780
12	2.5	0.7	16.3	22.4	1000
19	1.5	0.6	16.2	22.2	1000
19	2.5	0.7	19.9	26.6	1540
27	1.5	0.6	20	26.7	1500
27	2.5	0.7	24	30.7	1950
37	1.5	0.6	22.3	29	1800
37	2.5	0.7	26.9	33.8	2350

Class 2 Stranded Conductors for Single Core and Multi-Core Cables

Nominal Cross Sectional Area	Minimum No. Of Wires In Conductor						Maximum Resistance of Conductor At 20ºC
mm²	Circular		Circular Compacted		Shaped		Annealed Copper Conductor
mm²	Cu	Al	Cu	Al	Cu	Al	Plain Wires ohms/km
1.5	7	–	6	–	–	–	12.1
2.5	7	–	6	–	–	–	7.41
4	7	–	6	–	–	–	4.61
6	7	–	6	–	–	–	3.08
10	7	7	6	6	–	–	1.83
16	7	7	6	6	–	–	1.15
25	7	7	6	6	6	6	0.727
35	7	7	6	6	6	6	0.524
50	19	19	6	6	6	6	0.387
70	19	19	12	12	12	12	0.268
95	19	19	15	15	15	15	0.193
120	37	37	18	15	18	15	0.153
150	37	37	18	15	18	15	0.124
185	37	37	30	30	30	30	0.0991
240	37	37	34	30	34	30	0.0754
300	61	61	34	30	34	30	0.0601
400	61	61	53	53	53	53	0.047

Notes

1. Where a conductor operates at a temperature exceeding 70ºC it must be ascertained that the equipment connected to the conductor is suitable for the conductor operating temperature.

2. Where cables in this table are connected to equipment or accessories designed to operate at a temperature not exceeding 70ºC , the current ratings given in the equivalent table for 70ºC thermoplastic insulated cables must be used.

For more information, don’t hesitate to call us on +86-15838290725 or send inquiry to me.

We are China BS 6724 LSZH Sheath 0.6/1kv LV Power Swa Armored Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.

Get Latest Price Request a quote
