Bare Alloy Aluminium Conductor Aasxsn Aasxs 12/20 Kv Ccx-Al3 Cable

Bare Alloy Aluminium Conductor Aasxsn Aasxs 12/20 Kv Ccx-Al3 Cable image

Get Latest Price Request a quote

Product Details

Model NO.

AAsXSn

Current

AC Cable

Insulation Material

XLPE

Sheath Material

Crosslinking

Material Shape

Round Wire

Wire Core Material

Aluminium Conductor

Certification

ISO, CCC, CE

Model

Al/XLPE

Brand

Hongda Cable

Voltage Rating

20kv, 35kv

Transport Package

Steel & Wooden Drum

Specification

35sqmm-240sqmm

Trademark

Hongda Cable

Origin

Made in China

HS Code

8544601200

Production Capacity

1000km/Month

Product Description

Bare alloy aluminium conductor AAsXSn AAsXS 12/20 kV CCX-AL3 Cable

Application:

Suitable for AC high-voltage overhead power lines. Provide protection against contact with other life covered overhead conductors and with gorunded parts. Since these cables are unscreened they are not touch proff and shall be treated as bare conductors in respect to electric shock.

Cable Design:

1: Bare alloy aluminium conductor (AlMgSi), round stranded compressed (RM). Longitudinally watertight by dry filling.

2: Core insulation (XLPE, Black, UV resistant)

Strandard: EN 50397-1

Rated voltage: 20 – 35kV

Temperature range:

Laying temperature: min.-20ºC

Operation temperature: -60ºC to +50ºC

Conductor temperature: max. +50ºC

Short-circuit temperature: max. +130ºC/5s

Bending radius (min.): 18 x Φ of cable

Cable SIZES

Number and normal cross-section of cores (mm2)	Calculated cable diameter (mm)	Calculated weight 1km of cable (kg)	Cores’ electrical resistance, in keeping with IEC 60228, no more (ohm/km)
AAsXSn, AAsXS 20 kV
1×35	12	170	0.986
1×50	13	210	0.720
1×70	15	280	0.493
1×95	16	360	0.363
1×120	18	440	0.288
1×150	19	530	0.236
1×185	21	730	0.188
1×240	24	950	0.145
AAsXSn, AAsXS 35 kV
1×35	14	210	0.986
1×50	16	270	0.720
1×70	17	340	0.493
1×95	19	420	0.363
1×120	20	520	0.288
1×150	22	620	0.236
1×185	24	810	0.188
1×240	26	1050	0.145

Please contact us for technical support with the right cable selection for your power distribution projects and to discuss your maintenance or project specific requirements. We provide tailored solutions for this cable range which include storage, cutting to length, and 2 days collection as standard.
