AS/NZS 4961 Three Core Al XLPE PVC Neutral Screen Cable Underground 0.6/1 (1.2) Kv

AS/NZS 4961 Three Core Al XLPE PVC Neutral Screen Cable Underground 0.6/1 (1.2) Kv image

Get Latest Price Request a quote

Product Details

Model NO.

Neutral Screen Cable AS/NZS 4961

Application

Underground

Conductor Material

Aluminum

Sheath Material

PVC

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CCC

Transport Package

Wooden Drum

Specification

16mm

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

50 Kilometer/Month

Product Description

Description

Al conductors, XLPE insulation, Laid up, Cu neutral screen, Black PVC sheath. 0.6/1 kV. Made to AS/NZS 4961.

Application

Industrial, commerical and domestic applications.
For use in various situations to supply the main power from the point of supply to buildings, equipment shed, e.g. switch board to main control cabinet, main between floors and buildings, cable cabinet to motor, etc.

CONSTRUCTION CHARACTERISTICS
Type of conductor	Sector-shaped, stranded
Conductor material	Aluminum
Insulation	XLPE
Screen	Copper wire
Outer sheath	PVC
ELECTRICAL CHARACTERISTICS
Rated Voltage Uo/U (Um)	0.6/ 1 (1.2) kV
USAGE CHARACTERISTICS
Max. conductor temperature in service	90°C
SPECIFIC CHARACTERISTICS

CONSTRUCTION

Conductor		Nom.insulation thickness	Screen		Nom.sheath thickness	Approx. diameter of cable	Approx cable weight	DC Conductor Resistance @20ºC During Installation
Size	Nom.diameter	Nom.insulation thickness	Nom.diameter of wire	Calculated area	Nom.sheath thickness	Approx. diameter of cable	Approx cable weight	DC Conductor Resistance @20ºC During Installation
mm2	mm	mm	mm	mm2	mm	mm	kg/km	Ω/km
3Cx35	7.1	0.9	0.85	25	3.2	27.8	1070	0.868
3Cx50	6.9*12.1	1.0	0.85	28	3.2	28.6	1190	0.641
3Cx70	8.4*14.7	1.1	1.13	41	3.2	32.7	1560	0.443
3Cx95	10.0*17.5	1.1	1.13	58	3.2	36.2	2040	0.320
3Cx120	11.3*19.2	1.2	1.53	84	3.2	40.2	2620	0.253
3Cx150	12.6*21.4	1.4	1.53	93	3.2	43.7	3050	0.206
3Cx185	14.1*24.0	1.6	1.53	117	3.2	47.9	3720	0.164
3Cx240	16.3*26.9	1.7	2.03	148	3.2	53.9	4700	0.125
3Cx300	18.3*30.2	1.8	2.01	184	3.2	58.6	5650	0.100

Packing shipping
