AS 1531 All Aluminium Conductor AAC Aerial Conductors (Bare) Centipede
Description
STANDARDS
National : AS 1531
DESCRIPTION
AAC – All Aluminium Conductor
AAC aerial conductor is made of aluminium 1350. It is designed for short & medium spans with a high conductivity.
| CONSTRUCTION CHARACTERISTICS | |
|---|---|
| Conductor material | Aluminum |
| DIMENSIONAL CHARACTERISTICS | |
| Conductor cross-section | 415mm² |
| Stranding (No./mm) | 37/3.78 |
| Nominal overall diameter | 26.3mm |
| Approximate weight | 1.12kg/m |
| MECHANICAL CHARACTERISTICS | |
| Minimum breaking load | 63.3kN |
Products and specifications
| Name ref. | Conductor cross-section (mm2) |
Stranding (No./mm) |
Nominal overall diameter (mm) |
Approximate weight (kg/m) |
Minimum breaking load (kN) |
| Namu | 24.5 | 7/2.11 | 6.33 | 0.07 | 4.07 |
| Poko | 30.6 | 7/2.36 | 7.08 | 0.08 | 5.09 |
| Ladybird | 42.8 | 7/2.79 | 8.37 | 0.12 | 6.92 |
| Kutu | 49.5 | 7/3.00 | 9.0 | 0.14 | 7.98 |
| Fly | 63.6 | 7/3.40 | 10.2 | 0.17 | 9.98 |
| Rango | 73.6 | 7/3.66 | 11.0 | 0.2 | 11.2 |
| Grasshopper | 84.1 | 7/3.91 | 11.7 | 0.23 | 12.8 |
| Wasp | 106 | 7/4.39 | 13.2 | 0.29 | 16.1 |
| Beetle | 106 | 19/2.67 | 13.4 | 0.29 | 17.2 |
| Weke | 122 | 7/4.72 | 14.2 | 0.34 | 18.6 |
| Bee | 132 | 7/4.90 | 14.7 | 0.36 | 20.1 |
| Cricket | 158 | 7/5.36 | 16.1 | 0.43 | 24 |
| Weta | 167 | 19/3.35 | 16.8 | 0.46 | 26.2 |
| Mata | 222 | 19/3.86 | 19.3 | 0.61 | 33.8 |
| Cockroach | 266 | 19/4.22 | 21.1 | 0.73 | 40.4 |
| Butterfly | 323 | 19/4.65 | 23.3 | 0.89 | 49.1 |
| Centipede | 415 | 37/3.78 | 26.3 | 1.12 | 63.3 |
| Cicada | 628 | 37/4.65 | 32.6 | 1.73 | 95.6 |
ELECTRICAL PERFORMANCE DATA
|
Name ref. |
Calculated DC |
Reactance at 50Hz with |
Current Rating |
Current Rating |
|
Namu |
1.17 |
0.321 |
85 |
164 |
|
Poko |
0.936 |
0.314 |
98 |
189 |
|
Ladybird |
0.670 |
0.303 |
121 |
232 |
|
Kutu |
0.579 |
0.299 |
132 |
253 |
|
Fly |
0.451 |
0.291 |
155 |
295 |
|
Rango |
0.389 |
0.286 |
170 |
323 |
|
Grasshopper |
0.342 |
0.282 |
184 |
350 |
|
Wasp |
0.271 |
0.275 |
213 |
403 |
|
Beetle |
0.271 |
0.271 |
213 |
404 |
|
Weke |
0.234 |
0.270 |
233 |
441 |
|
Bee |
0.217 |
0.268 |
244 |
461 |
|
Cricket |
0.181 |
0.262 |
275 |
515 |
|
Weta |
0.172 |
0.257 |
286 |
533 |
|
Mata |
0.130 |
0.248 |
345 |
632 |
|
Cockroach |
0.108 |
0.242 |
390 |
707 |
|
Butterfly |
0.0895 |
0.236 |
443 |
792 |
|
Centipede |
0.0695 |
0.227 |
525 |
923 |
|
Cicada |
0.0460 |
0.214 |
689 |
1178 |
Current ratings are based in an ambient temperature of 30°C, a maximum conductor temperature of 75°C, rural weathered, summer noon and intensity of solar radiation 1000 W/m².
