Amoured Cable Rovmv-K 0, 6/1kv CPR Power and Control Cable

Amoured Cable Rovmv-K 0, 6/1kv CPR Power and Control Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Amoured Cable ROVMV-K

Current

DC & AC

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC, CE, SGS

Model

Amoured Cable Rovmv-K

Brand

Hongda Cable

Standard

IEC 60502, IEC 60332

Rated Voltage

0.6/1 Kv

Armour

Swa (Awa for Single Core)

Conductor

Class 5 Copper Conductors to En60228

Transport Package

Drum or as Customer Require

Specification

1.5mm2 to 185mm2

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

800km/Month

Product Description

Amoured Cable ROVMV-K 0,6/1kV CPR power and control cable

ROVMV-K Power Cable

ROVMV-K flexible, armoured power cable suitable for use in hazardous areas such as petrochemical plants due to its excellent mechanical protection and crush resistance.

Applications

ROVMV-K cable Armoured and shielded power and control cable for use in fixed installations, protected or not. Suitable for indoor and outdoor installations, on airborne supports, in pipes or buried. Thanks to its wire armour and the special PVC outer sheath, especially recommended where high mechanical or rodent protection is required and in contact with hydrocarbons and/or mineral oils.

Cable Construction

Conductors: Class 5 copper conductors to EN60228
Insulation: XLPE
Assembly Insulated conductors laid-up together in concentric layers
Overall screen Polyester Tape + Aluminium/polyester tape + flexible tinned copper drain wire Overlapp: 25% Coverage: 100%
Bedding: PVC
Armour: SWA
Sheath/Jacket: PVC
Colour: Black
Voltage: 0.6/1kV
Operating temperature: Maximum +90°C, minimum -15°C
Standard: IEC 60332 Tests on electric and optical fibre cables under fire conditions
IEC 60502: Power cables with extruded insulation and their accessories for rated voltages from 1kV to 30kV

Colour Code

1 Core	natural
2 Cores	blue & brown
3 Cores	brown, black and gray
3 Cores ground	blue, brown & green/yellow
4 Cores	brown, black, gray, blue
4 Cores ground	brown, black, gray & green/yellow
5 Cores	brown, black, gray, blue, yellow & green
Above 5 Cores	Black Cores with White numerals

Other colours can be manufactured upon request.

Constructive Data

NxS (mm2)	Ø (mm)	Weight (kg/km)	R at 20°C (Ohm/Km)
2×1.5	12.3	302	13.3
3G1.5	12.8	328	13.3
3G1.5 Gray	12.8	328	13.3
3G1.5 Blue	12.8	328	13.3
4G1.5	13.5	362	13.3
4G1.5 Blue	13.5	362	13.3
5G1.5	14.4	405	13.3
7G1.5	15.2	462	13.3
7G1.5 Blue	15.2	462	13.3
12G1.5	18.7	658	13.3
14G1.5	19.1	700	13.3
3G2.5	13.8	391	7.98
4G2.5	14.7	430	7.98
4G4	16	542	4.95
4G6	17.6	668	3.3
4G10	20.3	913	1.91
4G16	24.1	1539	1.21
4G50	37	3632	0.386
4G185	62.6	19336	0.106

Packing & Shipping:

Packing
Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.

Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Shipping Port:
Shanghai, Qingdao, Tianjin or other ports as per your requirements.

Sea freight:
FOB/C&F/CIF/DAP quotation are all available.

Whilst HONGDA CABLE plc endeavours to ensure the information on the website, specification sheets and all other technical information is accurate, the information is for guidance only and it is subject to change without notice or liability. HONGDA Cable Plc is not responsible for the consequences of any inadequacies, inaccuracies or other deficiencies contained therein. When selecting cable accessories, please note that the actual cable dimensions may vary due to manufacturing tolerances.
