Aluminium Conductor XLPE Insulated Black PVC Cable AS/NZS 5000.1

Aluminium Conductor XLPE Insulated Black PVC Cable AS/NZS 5000.1 image

Get Latest Price Request a quote

Product Details

Model NO.

AS/NZS 5000.1 cable

Application

Overhead, Underground

Conductor Material

Aluminum

Sheath Material

PVC

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

Flame Retardant

Certification

ISO9001, CCC

Brand

Hongda

Voltage Rating

600/1000V

Neutral Screen

None

Insulation Colour

Red, White, Blue

Sheath Colour

Black

Transport Package

Steel & Wooden Drum or Customer Requirement

Specification

AS/NZS 5000.1

Trademark

Hongda, accept OEM

Origin

China

HS Code

8544492100

Production Capacity

30km/Days

Product Description

Single Core Aluminum Cable

Description

Al conductor, XLPE insulated, Black PVC sheath. 0.6/1 kV. Made to AS/NZS 5000.1.

Application

Industrial and commercial applications
Some domestic applications
For use in various situations to supply the main power from the point of supply (either single or three phase application) to buildings, equipment, e.g. switch board to main control cabinet, main between floors and buildings, cable cabinet to motor, etc. Historically used in Power Authority work.

Conforms to AS/NZS 5000.1.

ELECTRICAL CHARACTERISTICS
CONSTRUCTION CHARACTERISTICS
Conductor material	Aluminum
Type of conductor	Circular compacted stranded
Insulation	XLPE
Outer sheath	PVC
Rated Voltage Uo/U (Um)	0.6/ 1 (1.2) kV
USAGE CHARACTERISTICS
Max. conductor temperature in service	90°C

Available Sizes:

CONSTRUCTION

Conductor cross-section (mm2)	Nominal overall diameter (mm)	Approximate weight (kg/m)	Max. DC resistance of the conductor at 20°C (Ohm/km)
70	15	0.32	0.443
95	16.9	0.42	0.320
120	18.5	0.51	0.253
150	20.6	0.62	0.206
185	22.8	0.76	0.164
240	25.5	0.97	0.125
300	27.9	1.19	0.100
400	31.3	1.5	0.0778
500	35	1.87	0.0601
630	39.4	2.38	0.0469
800	44.7	3.01	0.0367

PACKAGE AND SHIPPING:
Steel wooden drum (fumigation)
Cable length in each drum: 500m/1000m or as per actual cable length requirements.
Drum size: As per cable length and container size

Shipping:
Port: Tianjin, Qingdao, Shanghai or other ports as per your requirements.

Sea freight:
FOB/C&F/CIF/DAP quotation are all available.
