Aluminio Cable 2AWG Triplex Service Drop Aluminum Insulated Cable 6AWG

Aluminio Cable 2AWG Triplex Service Drop Aluminum Insulated Cable 6AWG image

Get Latest Price Request a quote

Product Details

Model NO.

Triplex Cable

Current

DC & AC

Insulation Material

XLPE

Sheath Material

Crosslinking

Material Shape

Round Wire

Wire Core Material

Aluminum Conductor

Certification

ISO, CCC, CE

Model

Aluminum Cable

Brand

Hongda

Rated Voltage

0.6/1kv

Transport Package

Wooden Drum or as Customer Requirement

Specification

8AWG to 4/0

Trademark

Hongda Cable

Origin

China

HS Code

8544492100

Production Capacity

2000km/Month

Product Description

Cable Triplex 2 awg Service Drop Aluminum Insulated Cable 6 AWG 2+1

We produce the ABC Electric Cable used for overhead line(duplex, triplex, quadruplex) in IEC standard, ASTM, ANSI/ICEA S-76-474, NFC 33-209 standard.

Applications

To supply 120 volt aerial service for temporary service at construction sites,outdoor or street lighting . For service at 600 volts or lower at a conductor temperature of 75 maximum.

Construction

Phase Conductor construction:The phase conductor is aluminum alloy 1350-H19 hard-drawn, compressed concentric-lay-stranded.

Neutral Conductor Construction

Cable assemblies are available with the following neutral conductors:

Aluminum conductors, coated-steel reinforced (ACSR), concentric-lay-stranded

Aluminum alloy 1350-H19 hard-drawn, concentric-lay-stranded

Aluminum alloy 6201-T81, concentric-lay-stranded

Insulation Material

The standard insulation on the phase conductor is black low-density crosslinked polyethylene (XLPE)

Alternatively, black linear low-density polyethylene (LLDPE) insulation with a 75°C temperature rating is available upon request.

Data sheet

Triplex Service Drop-Aluminum Conductor

Code	Phase Conductor				Bare Neutral Messenger			Weight Per		Ampacity (Amps)
Name	Phase Conductor				Bare Neutral Messenger			1000 ft(lbs)		Ampacity (Amps)
	Size		Stranding	Insulation	Size	Stranding	Breaking	XLP	POLY	XLP	POLY
	AWG			thickness	AWG		strength
				(mls)			(lbs)
6201 ALLOY NEUTRAL-MESSENGER
Minex		6	solid	45	6	7	1,110	106.6	102.9	85	70
Hippa		6	7/w	45	6	7	1,110	113.2	105.7	85	70
Prawn		4	solid	45	4	7	1,760	158.4	154.1	115	90
Barnacles		4	7/w	45	4	7	1,760	168.3	158.2	115	90
Shrimp		2	7/w	45	2	7	2,800	253.7	239.7	150	120
Gammarus		1/0	7/w	60	1/0	7	4,460	411.7	386	205	160
Leda		1/0	19/w	60	1/0	7	4,460	402.7	386	205	160
Dungenese		2/0	7/w	60	2/0	7	5,390	506.8	476.3	235	185
Cyclops		2/0	19/w	60	2/0	7	5,390	495.3	476.3	235	185
Flustra		3/0	19/w	60	3/0	7	6,790	611.4	589.1	275	215
Lepas		4/0	19/w	60	4/0	7	8,560	757.1	730.5	315	245
6201 ALLOY REDUCED NEUTRAL-MESSENGER
Artemia		4	solid	45	6	7	1,110	141.4	137.1	115	90
Crab		4	7/w	45	6	7	1,110	151.3	141.2	115	90
Solaster		2	7/w	45	4	7	1,760	226.6	212.6	150	120
Sandcrab		1/0	7/w	60	2	7	2,800	368.8	343.1	205	160
Echinus		1/0	19/w	60	2	7	2,800	358.8	343.1	205	160
Crayfish		2/0	7/w	60	1	7	3,530	452.6	422.5	235	185
Sipho		2/0	19/w	60	1	7	3,530	441	422.5	235	185
Fulgar		3/0	19/w	60	1/0	7	4,460	543.4	521.1	275	215
Arca		4/0	19/w	60	2/0	7	5,390	671.2	644.6	315	245
AAC NEUTRAL-MESSENGER
Haiotis		6	solid	45	6	7	563	102.5	98.8	85	70
Patella		6	7/w	45	6	7	563	109.1	101.6	85	70
Fusus		4	solid	45	4	7	881	151.9	147.6	115	90
Oyster		4	7/w	45	4	7	881	161.8	151.7	115	90
Clam		2	7/w	45	2	7	1,350	243.2	229.2	150	120
Murex		1/0	7/w	60	1/0	7	1,990	395.1	369.4	205	160
Purpura		1/0	19/w	60	1/0	7	1,990	386.1	369.4	205	160
Nassa		2/0	7/w	60	2/0	7	2,510	485.8	455.3	235	185
Melita		3/0	19/w	60	3/0	19	3,310	585.2	562.9	275	215
Portunus		4/0	19/w	60	4/0	19	4,020	723.9	697.3	315	245
Nannynose		336.4	19/w	80	336	19	6,146	1160	1118	420	325
WITH FULL SIZE ACSR MESSENGER
Paludina		6	solid	45	6	‘6/1	1,190	114	113	85	70
Voluta		6	7/w	45	6	‘6/1	1,190	120	113	85	70
Whelk		4	solid	45	4	‘6/1	1,860	169	165	115	90
Periwinkle		4	7/w	45	4	‘6/1	1,860	176	172	115	90
Conch		2	7/w	45	2	‘6/1	2,850	267	261	150	120
Neritina		1/0	7/w	60	1/0	‘6/1	4,380	530	419	205	160
Cenia		1/0	19/w	60	1/0	‘6/1	4,380	426	416	205	160
Runcina		2/0	7/w	60	2/0	‘6/1	5,310	530	519	235	185
Triton		2/0	19/w	60	2/0	‘6/1	5,310	526	514	235	185
Cherrystone		3/0	7/w	60	3/0	‘6/1	6,620	656	643	250	200
Mursia		3/0	19/w	60	3/0	‘6/1	6,620	650	638	250	200
Razor		4/0	7/w	60	4/0	‘6/1	8,350	814	799	315	245
Zuzara		4/0	19/w	60	4/0	‘6/1	8,350	805	792	315	245
Limpet		336.4	19/w	80	336	‘6/1	8,680	1209	1167	420	325
WITH ACSR REDUCED SIZE MESSENGER
Scallop		4	Solid	45	6	‘6/1	1,190	148	144	115	90
Strombus		4	7/w	45	6	‘6/1	1,190	158	148	115	90
Cockle		2	7/ w	45	4	‘6/1	1,860	233	227	150	120
Janthina		1/0	7/ w	60	2	‘6/1	2,850	376	365	205	160
Ranella		1/0	19/ w	60	2	‘6/1	2,850	372	362	205	160

VIVIAN YUAN

We are China Aluminio Cable 2AWG Triplex Service Drop Aluminum Insulated Cable 6AWG manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
