Airfield Ground Lighting Cables 6mm XLPE PVC 5kv Primary Cable

Airfield Ground Lighting Cables 6mm XLPE PVC 5kv Primary Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Lighting Cables 6mm

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC

Model

5kv Primary Cable

Brand

OEM

Transport Package

Wooden Drum

Specification

2.5~400sqmm

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

500 Kilometer/Month

Product Description

Applications

These cables are used for interconnecting the transformers and the current regulator of airfield lighting systems in series circuits, suitable for fixed applications such as taxiways, runways, navigational aids, and obstruction lighting, can be installed in conduit and direct burial.

Standards

FAA L-824 Type C
ICEA S-96-659/NEWA WC71

Construction

Conductor: Stranded bare copper to ASTM B3 and ASTM B8.
Separator: Semi-conductive extruded layer or semi-conductive tape.
Insulation: XLPE.

Technical Data

Rated Voltage Uo/U (Um)	5kV
Maximum Conductor Temperature	90ºC
Short Circuit Temperature	250ºC
Operating Temperatures	-40ºC~+90ºC
Minimum Bending Radius	5×OD
Lead Free	Yes

Dimensions and Weight

CONSTRUCTION	NO. OF STRAND	NOMINAL INSULATION THICKNESS	NOMINAL OVERALL DIAMETER	NOMINAL WEIGHT
NO.× AWG	–	MM	INCHES	MM	INCHES	KG/KM	LBS/KFT
1×8	7/19	2.79	0.11	9.65	0.380	132	89
1×6	7/19	2.79	0.11	10.67	0.420	186	125
1×4	7/19	2.79	0.11	11.68	0.46	268	180

Packing shipping
