Aerial Aluminum Conductor 120mm2

Aerial Aluminum Conductor 120mm2 image

Get Latest Price Request a quote

Product Details

Model NO.

Aluminum Conductor Cable 16mm2

Application

Overhead

Conductor Material

Aluminum

Sheath Material

Insulation Material

Material Shape

Round Wire

Range of Application

Overhead Electric Power Transmission

Certification

ISO9001, CCC

Brand

Hongda

Product Name

Aerial Cable

Standard

IEC, BS, AS/NZS, SABS

Color

as Your Require

Core Number

as Your Require

Rated Voltage

1kv-35kv

Rated Temperature

70c 90c 120c 200c

Armour

None Armour

Strand Number

7, 19, 37, 54, 61, 91

Transport Package

Wooden Drum/ Steel & Wooden Drum

Specification

35mm2-400mm2

Trademark

Hongda

Origin

Henan China

HS Code

8544492100

Production Capacity

3000km/Month

Product Description

Aluminum Conductor Conductor 16mm2

Bare Overhead Conductors

STANDARDS

National : ASTM B 399;ASTM B 399

DESCRIPTION

Bare all aluminum alloy conductors (AAAC) are concentric-lay-stranded consisting of aluminum alloy 6201 wires wrapped helically around a central wire. The aluminum is heat-treated to a T81 temper to provide superior strength.

Features and Benefits

AAAC conductors provide a higher strength to weight ratio than traditional AAC conductors, and better corrosion resistance than ACSR conductors.

Applications

Stranded bare AAAC may be used for overhead line installations where the higher strength or temperature ratings of ACSR, ACCR or other types of conductors is not required, but improved sag performance to AAC is desired.

Conductor material:aluminum / aluminum alloy

Description	International Type	Chinese Type
All aluminum conductor	AAC	JL
Aluminum conductor steel reinforced	ACSR	JL/G1A
All aluminum alloy conductor	AAAC	JLHA1 JLHA2
Aluminum conductor alloy reinforced	ACAR	JL/LHA1
Bare copper stranded conductor (Hard Drawn)	BCC	TJ
Anti-corrosive stranded conductor	Greased conductor	JL/G1AF

ALL ALUMINUM ALLOY CONDUCTORS (AAAC) PHYSICAL DATA

ALL ALUMINUM CONDUCTORS (AAC)

AAC conductor is also known as aluminium stranded conductor. It is manufactured from electrolytic ally refined aluminium, with a minimum purity of 99.7%. AAC is used mainly in urban areas where the spacing is short and the supports are close. All aluminium conductors are made up of one or more strands of aluminium wire depending on the end usage. AAC is also used extensively in coastal regions because it has a high degree of corrosion resistance.

Codeword	Size (kcmil)	No. of Wires	Resistance (ohm/kft)		Ampacity* (A)
Codeword	Size (kcmil)	No. of Wires	DC at 20°C	AC at 75°C	Ampacity* (A)
Alton	48.69	7	0.414	0.492	143
Ames	77.47	7	0.260	0.311	191
Azusa	123.3	7	0.164	0.195	256
Anaheim	155.4	7	0.130	0.155	296
Amherst	195.7	7	0.103	0.123	342
Alliance	246.9	7	0.0816	0.0973	395
* Based on 75°C conductor temperature, 25°C ambient temperature, in sun and wind at 2 ft/sec.

Code	Nominal cross-sectional area	Number of strands	Diameter		Approximate weight of cable	Nominal Breaking Load	Maximum DC Resistance at 20ºC	Current Rating
	Nominal cross-sectional area		Single wire	Conductor	Approximate weight of cable	Nominal Breaking Load	Maximum DC Resistance at 20ºC	Current Rating
	mm²		mm	mm	kg/km	kN	Ω/km	A
10	10	7	1.35	4.05	27.4	1.95	2.8633	62
16	16	7	1.71	5.12	43.8	3.04	1.7896	84
25	25	7	2.13	6.40	68.4	4.50	1.1453	110
40	40	7	2.70	8.09	109.4	6.80	0.7158	147
63	63	7	3.39	10.2	172.3	10.39	0.4545	195
100	100	19	2.59	12.9	274.8	17.00	0.2877	259
125	125	19	2.89	14.5	343.6	21.25	0.2302	297
160	160	19	3.27	16.4	439.8	26.40	0.1798	345
200	200	19	3.66	18.3	549.7	32.00	0.1439	396
250	250	19	4.09	20.5	687.1	40.00	0.1151	454
315	315	37	3.29	23.0	867.9	51.97	0.0916	522
400	400	37	3.71	26.0	1102.0	64.00	0.0721	603
450	450	37	3.94	27.5	1239.8	72.00	0.0641	647
600	600	37	4.15	29.0	1377.6	80.00	0.0577	688
560	560	37	4.39	30.7	1542.9	89.60	0.0515	736
630	630	61	3.63	32.6	1738.3	100.80	0.0458	789
710	710	61	3.85	34.6	1959.1	113.60	0.0407	845
800	800	61	4.09	36.8	2207.4	128.00	0.0361	905
900	900	61	4.33	39.0	2483.3	144.00	0.0321	967
1000	1000	61	4.57	41.1	2759.2	160.00	0.0289	1026
1120	1120	91	3.96	43.5	3093.5	179.20	0.0258	1091
1250	1250	91	4.18	46.0	3452.6	200.00	0.0231	1157
1400	1400	91	4.43	48.7	3866.9	224.00	0.0207	1226
1500	1500	91	4.58	50.4	4143.1	240.00	0.0193	1270

6. Factory

Henan Hongda Cable Co., Ltd. located in No. 3, Changping Road, ZhanDian District, Jiaozuo, Wuzhi. Our factroy established in March of 2004. Our owns registered capital of RMB Fifty-one million six hundred and eighty thousand. Hongda Cable
covers an area of 100,000 square meters, including 50,000 square meters of building area. We have more than 120 staff members and professional workers. our fixed assets of 90,000,000. We can provide more than 100 varieties, tens of thousands of specifications of wire and cable, with 10000 km annual production capacity
Henan Hongda Cable Co. Ltd. is the original Zhengzhou Hongda Cable Co. Ltd. established enterprise expansion. The company is committed to system R&D, design, manufacturing, marketing and service of cable products,We mainly aim at managing cross-linking XLPE insulated power cables, PVC insulated power cables, plastic insulated control cables, insulated overhead cables, and stranded aluminum and ACSR. At present, the cables’ biggest cross area is 800 square meters with a maximum electric power of 35KV. The company has more than 300 (sets) domestic and oversea-leading production and testing equipment

7. Packing and Transportation
We provide you with the best product packaging design services, thereby allowing you to save more shipping charges

8. Certificate

We are China Aerial Aluminum Conductor 120mm2 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
