Product Details

Model NO.

ACYAbY / ACYAbY-F

Current

DC Cable

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Compacted Sector

Wire Core Material

Aluminum

Certification

ISO, CCC

Model

Cablu Ayaby

Brand

Hongda Cable

Insulation

PVC Insulated

Sheath

PVC (Polyvinyl Chloride), Fire Resistant

Transport Package

500m Per Drum

Specification

1.5 - 300 sq. mm

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

20 Kilometers Per Day

Product Description

ACYAbY / ACYAbY-F – Low voltage power cable armoured with steel tape

1. Cable construction

Conductor: aluminum (class 1 or 2), monowire (re), multiwire (rm).

Insulation: PVC

Inner sheath: Extruded PVC, black or grey.

Armour: double steel tape.

Outer sheath: PVC, black or grey.

ACYAbY / ACYAbY-F low voltage power cable 0.6/1 kV – Technical data and tests

Conductor type :	monowire (re), multiwire (rm)
Rated voltage Uo/U :	0.6/1 kV
Test voltage :	3.5 kV AC or 8.4 kV DC,5 min
Min. temperature of cable :	installation : -5º C operation : -30º C
Max. allowed operating temperature :	70º C
Max. short-circuit temperature :	160º C
Min. bending radius :	12 x cable diameter with more than 1 conductors 15 x cable diameter with 1 conductor
Max. tensile strain during installation :	max 50 N/mm²
Color coding :	1 conductor-blue or yellow-green; 2 conductors – blue,brown; – yellow-green,black for sect > 10 mm²; 3 conductors – brown,black,grey; – yellow-green, blue,brown; 4 conductors – blue, brown, black,grey; – yellow-green, brown,black,grey; 5 conductors – blue, brown, black, grey, black; – yellow-green, blue, brown, black,grey; More than 5 conductors: – numbered black conductors; – yellow-green and numbered conductors.
Standards: Cable : IEC 60502-1. Conductors : IEC 60228. Insulation : IEC 60502-1. Flame retardancy: ACYAbY : EN 50265-2-1 (IEC 60332-1) – burning on a single vertical cable. ACYAbY-F : EN 50266-2-4 (IEC 60332-3-25 Cat. C) – burning on a bundle of cables.

ACYAbY / ACYAbY-F low voltage power cable 0.6/1 kV – Applications

This cable is used to transmit the power supply to power stations.

It must be protected against: corosive chemicals, chemical solvents and solar radiation.

This cable can be installed underground, in air, inside or outside and has a high resistance to mechanical shocks. This is a flame retardant cable.

ACYAbY / ACYAbY-F low voltage power cable 0.6/1 kV – Other standards

British : AL/PVC/STA/PVC.

German : NAYBY.

Russian : АВБбШв.

Turkish : YAVZ4V-R.

Central Europe : PP 41-A.

2. Construction data of power cables / CYABY-F

Numar de conductoare x sectiunea nominala	Diametru exterior (aproximativ)	Greutate neta (aproximativ)	Rezistenta electrica maxima la 20º C	Sarcina admisibila in aer la 30º C	Sarcina admisibila in pamant la 20º C
Nr. x mm2	mm	Kg/Km	Ω/Km	A	A
2×4 re	15	340	7,41	30	42
2×6 re	16	400	4,61	38	52
2×10 re	17	470	3,08	52	69
2×16 re	19	580	1,91	70	90
3×4 re	16	370	7,41	27	36
3×6 re	17	430	4,61	34	45
3×10 re	18	515	3,08	47	60
3×16 re	20	640	1,91	63	78
3×25 re	24	860	1,20	82	100
3×35 sm	25	840	0,868	100	120
3×50 sm	28	1070	0,641	125	145
3×70 sm	32	1350	0,443	155	175
3×95 sm	37	2060	0,32	190	215
3×120 sm	40	2430	0,253	220	245
3×150 sm	43	2790	0,206	250	275
3×185 sm	48	3415	0,164	285	310
3×240 sm	55	4310	0,125	340	360
3×25+16 re+re	25	930	1,20 / 1,91	82	100
3×35+16 sm+re	27	950	0,868 / 1,91	100	120
3×50+25 sm+sm	31	1235	0,641 / 1,20	125	145
3×70+35 sm+sm	35	1580	0,443 / 0,868	155	175
3×95+50 sm+sm	40	2020	0,320 / 0,641	190	215
3×120+70 sm+sm	46	2900	0,253 / 0,443	220	245
3×150+70 sm+sm	48	3240	0,206 /0,443	250	275
3×185+95 sm+sm	54	4050	0,164 / 0,320	285	310
3×240+120 sm+sm	61	5010	0,125 / 0,253	340	360
4×4 re	17	420	7,41	27	36
4×6 re	18	490	4,61	34	45
4×10 re	20	580	3,08	47	60
4×16 re	22	735	1,91	63	78
4×25 rm	27	1060	1,20	82	100
4×35 sm	27	1035	0,868	100	120
4×50 sm	31	1330	0,641	125	145
4×70 sm	35	1690	0,443	155	175
4×95 sm	41	2550	0,320	190	215
4×120 sm	45	3020	0,253	220	245
4×150 sm	47	3480	0,206	250	275
4×185 sm	53	4280	0,164	285	310
4×240 sm	61	5450	0,125	340	360
5×4 re	18	480	7,41	27	36
5×6 re	19	560	4,61	34	45
5×10 re	21	670	3,08	47	60
5×16 rm	25	890	1,91	63	78
5×25 rm	29	1250	1,20	82	100
5×35 rm	32	1515	0,868	100	120
