AAC 1350 All Aluminum Stranded Conductor Pluto 210mm2 AS 1531
AAC Conducto Pluto 210mm2 Applications
Bare conductor Cable all aluminum conductor (AAC) is made up of one or more strands of hard drawn 1350 aluminum alloy. These conductors are used in low, medium and high voltage overhead lines. AAC has seen extensive use in urban areas where spans are usually short but high conductivity us required.
AAC Conductor Pluto 210mm2 Construction
AAC Conductor Pluto 210mm2 can be used in low and medium voltage overhead lines.It is a concentric-lay-stranded conductor consisting of aluminum 1350-H19 wires. It available in both single-layer and multi-layer constructions.
AAC Conductor Pluto 210mm2 strands 19 aluminums. The individual wire diameter are all same 3.75mm. The overall diameter for AAC Conductor Pluto 210mm2 is 18.8 mm. The conductor cross section is 210mm2 . After the cabling, the total linear mass is 576 kg/km. Through the test, the calculated breaking load should be 31.9 kN. At the 20ºC, calculate D.C. resistance should be 0.137Ω/km.
AAC Conductor Pluto 210mm2 Standrad
Standard sizes to AS 1531
AAC Conductor Pluto 210mm2 Parameter
| Code: | Pluto |
| Stranding: | 19 |
| Cross Section Area: | 210 |
| Diameter Individual Wire Aluminum (mm): | 3.75 |
| Diameter Complete Conductor(O.D.) (mm): | 18.8 |
| Weight Per 1000meters Total (kgs): | 576 |
| Minimum Breaking Load (KN): | 31.9 |
| Resistance DC 20°C Per 1000Meters: | 0.137 |
| Resistance DC 75°C Per 1000meters: | 0.166 |
Packing & Shipping
Packing
Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.
Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Shipping Port:
Tianjin, Qingdao, or other ports as per your requireents.
Sea freight:
FOB/C&F/CIF quotation are all available.
*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency.
Any problem and inquiry pls contact with Tina
We are China AAC 1350 All Aluminum Stranded Conductor Pluto 210mm2 as 1531 manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
