600V X-90 3X185+3X25 Copper Taped Screened Variable Speed Drive VFD Cable

600V X-90 3X185+3X25 Copper Taped Screened Variable Speed Drive VFD Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Variable Speed Drive Cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC

Model

Bpyjvp

Brand

Hongda

Standard

as 5000.1

Transport Package

in Drum

Specification

2.5mm2 to 300mm2

Trademark

OEM

Origin

Henan

HS Code

8544492100

Production Capacity

5000 M Per Day

Product Description

600v X-90 3×185+3×25 Copper Taped Screened Variable Speed Drive VFD Cable

THREE CORE + THREE EARTH, VARIABLE SPEED DRIVE CABLES, 0.6KV X-90 XLPE
XLPE INSULATED PVC BEDDED, COPPER TAPED SCREENED PVC SHEATHED CABLE TO AS 5000.1

Application:

The cable is used as power supply cables or electrical connection of inverter control system at AC rated voltage 0.6/1KV or less
For use in Variable Speed Drive Motors.

CABLE DESIGN

Conductor	Plain Annealed Copper
Insulation	X-90 XLPE
Core Colour	Red, White + Blue with Green/Yellow
Sheath	5V-90 PVC Colour: Black

CHARACTERISTICS

Conductor				Cable
No. of Core	Nom. Area mm²	No. & Dia. of Wires No./mm	Nom. Dia. mm	Min. Nom. Ins. Thickness mm	Nom. Sheath Thickness mm	Overall Dia. Bedding	Nom. Overall Dia. mm	Approx. Mass Kg/100m
3C+1E	2.5	7/0.67	2.01	0.7	1.8	11	14.6	30
	E(2.5)	7/0.67	2.01
3C+3E	4	7/0.85	2.55	0.7	1.8	14	15.4	37.8
	E(1.5)	7/0.50	1.5
3C+3E	6	7/1.04	3.12	0.7	1.8	14	18	47.4
	E(1.5)	7/0.50	1.5
3C+3E	10	7/1.35	4.05	0.7	1.8	15	20	612
	E(1.5)	7/0.50	1.5
3C+3E	16	7/1.70	4.6	0.7	1.9	17	22	855
	E(2.5)	7/0.67	2.01
3C+3E	25	19/1.35**	6.75	0.9	1.9	21	25	133
	E(4.0)	7/0.85	2.55
3C+3E	35	19/1.53**	7.65	0.9	1.9	24	28	166.7
	E(6.0)	7/1.04	3.12
3C+3E	50	19/1.78**	8.1	1	1.9	24	29	211.6
	E(10)	7/1.35	4.05
3C+3E	70	19/2.14**	9.8	1.1	2.1	29	34	283.1
	E(10)	7/1.35	4.05
3C+3E	95	37/1.78**	11.4	1.1	2.1	32	37	384.9
	E(16)	7/1.70	4.6
3C+3E	120	37/2.03**	12.7	1.2	2.3	36	42	465.5
	E(16)	7/1.70	4.6
3C+3E	150	37/2.25**	14.5	1.4	2.5	41	46	605.5
	E(25)	19/1.35**	6.75
3C+3E	185	37/2.52**	16	1.6	2.7	45	51	719.7
	E(25)	19/1.35**	6.75
3C+3E	240	61/2.25**	18.27	1.7	2.9	51	57	933.9
	E(35)	19/1.53**	7.65
3C+3E	300	61/2.52**	20.3	1.8	3.1	55	62	1169.5
	E(50)	19/1.78**	8.1

Type and Name:

Type	name
BPVVP	PVC insulated and sheathed copper wire braided shield frequency converter power cable
BPVVP2	PVC insulated and sheathed copper tape wrapped shielding frequency converter power cable
BPVVPP2	PVC insulated and sheathed copper wire braided copper tape wrapped shield frequency converter power cable
BPVVP3	PVC insulated and sheathed aluminum polyester composite film wrapped and shielded frequency converter power cable
BPYJVP	XLPE insulated PVC sheathed copper wire braided shield frequency changer power cable
BPYJVP2	XLPE insulated PVC sheathed copper tape wrapped shield frequency changer power cable
BPYJVPP2	XLPE insulated PVC sheathed copper wire braided copper tape wrapped shield frequency changer power cable
BPYJVP3	XLPE insulated PVC sheathed aluminum polyester composite film wrapped and shielded frequency changer power cable
Note: Prefix ZR is added to the flame retardant type cable’s code
