600V SPD-Fhnct SPD (Y) -2pnct K-Pnct K-Pnct-Sb Crane Basket System Spreader Cable

600V SPD-Fhnct SPD (Y) -2pnct K-Pnct K-Pnct-Sb Crane Basket System Spreader Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Basket System Spreader Cable

Insulation Material

Epr

Sheath Material

Chloroprene Rubber

Material Shape

Flat

Wire Core Material

Copper /Tinned Annealed Copper

Certification

ISO, CCC, CE, VDE

Brand

Huadong

Product Name

Basket System Spreader Cable

Rated Voltage

600V

Type

SPD-Fhnct SPD(Y)-2pnct K-Pnct K-Pnct-Sb

Temperature

-40 to 80 Centigrade

Warranty

100% Qualified

Sample

Available

Color

Black or Others

Price

Get Within 12 Hours

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

600V SPD-FHNCT SPD(Y)-2PNCT K-PNCT K-PNCT-SB Basket System Spreader Cable

Conductor : Copper /Tinned annealed copper

Insulation : EPR/ETFE/EP compound

Outer sheath : Chloroprene rubber
Rated Voltage : AC 600V
Rated Temperature : 80 degrees C
Test Voltage: 3000V /1 minute
Feature : Stable collecting performance into the basket, and high lateral pressure resistance,
High flexibility, weather resistance, and sealing performance;
Application : Suitable for gravity collector basket system of the container crane at harbors
(for Quayside cranes,RTG Crane etc).For civil engineering measurements

Product Parameters:

600V SPD-FHNCT
No. of Cores	Conductor			Insulation Thickness (mm)	Sheath Thickness (mm)	Approx. Overall Dia(mm)	Approx. Mass (kg/km)	Max. Conductor Resistance (20 degrees C) (Ω/km)
No. of Cores	Size (mm2)	Construction (No./mm)	Outer Dia(mm)	Insulation Thickness (mm)	Sheath Thickness (mm)	Approx. Overall Dia(mm)	Approx. Mass (kg/km)	Max. Conductor Resistance (20 degrees C) (Ω/km)
30	3.5	45/0.32	2.5	0.4	6	42	2710	5.54
36	3.5	45/0.32	2.5	0.4	7	46	3090	5.54
42	3.5	45/0.32	2.5	0.4	7	50	3820	5.54
600V SPD (Y)-2PNCT
30	3.5	3/0.32TST + 45/0.32TA	2.6	0.8	3.3	37	2130	5.54
36	3.5	3/0.32TST + 45/0.32TA	2.6	0.8	3.5	40	2520	5.54
42	3.5	3/0.32TST + 45/0.32TA	2.6	0.8	3.7	43	2930	5.54
K-PNCT-SB
4	0.3	12/0.18	0.7	0.5	1.2	6.8	65	66.3
4	0.5	20/0.18	1	0.5	1.3	7.7	85	39.8

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 2005, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 66,000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.

We are China 600V SPD-Fhnct SPD (Y) -2pnct K-Pnct K-Pnct-Sb Crane Basket System Spreader Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
