600V Monopolar Cable 2/0AWG Double Insulated PVC Wire Cable

600V Monopolar Cable 2/0AWG Double Insulated PVC Wire Cable image

Get Latest Price Request a quote

Product Details

Model NO.

600v monopolar cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC

Model

Cu XLPE PVC

Brand

OEM

Product Name

Cu XLPE PVC 30mm Sq. 250mm Sq. XLPE Single Core Po

Number of Cores

Single Core

Transport Package

Wooden Drum

Specification

30mm sq. 250mm sq.

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

50 Kilometer/Month

Product Description

1.Brief Introduction :

CU/XLPE/PVC cable is Cu /AL conductor /XLPE insulated /PVC sheath Electric power cable for laying buildings,inducts , kin tunnels,direct in ground and under water,.

For laying indoors , in tunnels, in ducts. Able to bear extermal mechanical force but not large pulling forces. Single core cables are impermissible to be laid in magnetic ducts.

2.Operating characteristics:

Rated power-frequency voltage u0/u:0.6/1 KV

Max permissible continuous operating temperature of conductor 90

Max short-circuit temperature of the conductor shall not exceed (Max 5 seconds duration): cross-section of conductor 300 mm²

The anbient temperature under installations should not be below 0

The bending radius of single core cable should not be less than 20 times of the cable diameter ,the bending radius of multi-core cable should not be less than 15 times of the cable diameter

No. of Core	Nom. cross Section Area(mm2)	Single quantity of conductor	Insu. Thick (mm)	Sheath thick (mm)	Approx. dia. Of cable (mm)	D.C resistant((Ω/km) Cu Al
1	1.5~800	1~61	0.8~2.9	1.4~2.4	6.1~46.1	12.1~0.221	0~0.0367
2	1.5~400	1~61	0.8~2.6	1.8~2.8	10.5~56.0	119~8356	100~3320
3	1.5~400	1~61	0.8~2.6	1.8~3.0	10.9~60.6	142.0~12103.0	113.0~4869.0
4	2.5~400	1~61	0.8~2.6	1.8~3.2	12.7~70.0	232.0~16788	169~6708
5	2.5~400	1~61	0.8~2.6	1.8~3.6	13.6~87.0	272~21164	193~8564
3+1	4~400, 2.5~240	1~37 1~61	1.0~2.6 0.8~1.6	1.8~3.3	14.3~66.0	254~14562	211~5968
3+2	4~400, 2.5~240	1~61 1~37	1~2.6 0.8~1.6	1.8~3.3	15.2~78.2	345~18250	238~7666
4+1	4~400, 2.5~240	1~61 1~37	1~2.6 0.8~1.6	1.8~3.4	15.6~79.1	358~19928	251~8366

Packing shipping
