600V Fire Resistance Heat Resistant Fire Resistant Flame Retardant Cable

600V Fire Resistance Heat Resistant Fire Resistant Flame Retardant Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Fire resistant cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC, SGS

Model

Fire Resistant Cable

Brand

Hongda

Standard

IEC 60332,1, IEC 60502-1, Ce, RoHS

Rated Voltage

0.6/1 Kv

Transport Package

Drum or as Customer Require

Specification

1.5mm2 to 400mm2

Trademark

Hongda

Origin

China

HS Code

8544492100

Production Capacity

800km/Month

Product Description

600V Fire resistance Heat Resistant Fire Resistant Flame Retardant Cable

600V Fire resistance Heat Resistant Fire Resistant Flame Retardant Cable – Applications

These cables are used for electricity supply in low voltage installation system, They are suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage.

Fire and flame-resistant cables play a vital role in building safety. Hongda is dedicated to developing low-smoke, zero toxicity cables as a means to assure the safety of people’s lives.

DESCRIPTION

Fire Resistant Cable
Size:1.5mm²~325mm²
Core:1C~50C
Conductor:Soft bare copper
Insulation :PE,XLPE
Jacket:PVC,LSZH
Rated Temperature:750ºC,840ºC,950ºC
Rated Voltage:600V
Fire Resistant Cable Application:Fire resistance cable may be built-in both structurally and by the correct choice and application of building materials.
In particular, the resistance-to-fire (of a cable) is the term used to describe how long a cable continues to operate in a fire. This may be of primary concern, for instance, in life safety of fire fighting installations.

Fire Resistant Cable

Colour Code

Colour Code (1)

1 Core	Red or Black
2 Cores	Red, Black
3 Cores	Red, Yellow, Blue
4 Cores	Red, Yellow, Blue, Black
5 Cores	Red, Yellow, Blue, Black, Green
Above 5 Cores	Black Cores with White numerals

Colour Code (2)

1 Core	Brown or Blue
2 Cores	Brown, Blue
3 Cores	Brown, Black, Grey
4 Cores	Blue, Brown, Black, Grey
5 Cores	Green/Yellow, Blue, Brown, Black, Grey
Above 5 Cores	Black Cores with White numerals

Other colours can be manufactured upon request.

Cable Design Parameters

While ordering, in addition to the part number the following details shall also be advised:

Conductor Type (Aluminium or Copper) and class of conductor (Cl. 1 or 2).

Sheath Type – PVC Type ST – 2 (FR or FRLS).

Size Cores x Sq. mm +Neutral (Sq. mm)	Nominal Thickness of Insulation (mm)	Minimum Thickness of Inner Sheath(mm)	Armouring with flat strip (A2XFY/ 2XFY)					Armouring with round wire (A2XWY/ 2XWY)
			Nominal Thickness of Arm.Strip (mm)	Minimum Thickness of OuterSheath (mm)	Approx.OverallDia. (mm)	Approx. Net Wt.of Cable (kg/km)		Nominal Diameter of Wire(mm)	Minimum Thickness of Outer Sheath (mm)	Approx. Overall Dia. (mm)	Approx. Net Wt.of Cable (kg/km)
			Nominal Thickness of Arm.Strip (mm)	Minimum Thickness of OuterSheath (mm)	Approx.OverallDia. (mm)	AL Cable A2XFY	CU Cable 2XFY	Nominal Diameter of Wire(mm)	Minimum Thickness of Outer Sheath (mm)	Approx. Overall Dia. (mm)	AL Cable A2XFY	CU Cable 2XWY
3×25+16	0.9/0.7	0.3	0.8	1.40	23	900	1400	1.6	1.40	25	1080	1685
3×35+16	0.9/0.7	0.3	0.8	1.40	25	1000	1800	1.6	1.40	27	1285	1980
3×50+25	1.0/0.9	0.3	0.8	1.40	28	1200	2300	1.6	1.56	30	1580	2685
3×70+35	1.1/0.9	0.4	0.8	1.56	32	1600	3200	2.0	1.56	35	2190	3690
3×95+50	1.1/1.0	0.4	0.8	1.56	35	2000	4100	2.0	1.56	38	2580	4585
3×120+70	1.2/1.1	0.4	0.8	1.72	39	2400	5100	2.0	1.72	42	3085	5680
3×150+70	1.4/1.1	0.5	0.8	1.72	43	2800	6000	2.0	1.88	46	3590	6790
3×185+95	1.6/1.1	0.5	0.8	1.88	47	3400	7400	2.5	2.04	51	4675	8615
3×240+120	1.7/1.2	0.6	0.8	2.04	53	4300	9500	2.5	2.20	56	5680	10485
3×300+150	1.8/1.4	0.6	0.8	2.20	57	5000	11500	2.5	2.36	60	6685	12990
3×400+185	2.0/1.6	0.7	0.8	2.52	66	6400	14500	3.2	2.68	71	8980	16980
3×500+240	2.2/1.7	0.7	0.8	2.68	74	7900	18000	3.2	2.84	79	10985	21485
3×630+300	2.4/1.8	0.7	0.8	3.00	82	9900	23000	4.0	3.00	88	14490	27985

Packing & Shipping:

Packing
Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.

Drum size:
As per cable length and container size
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Shipping Port:
Shanghai, Qingdao, Tianjin or other ports as per your requirements.

Sea freight:
FOB/C&F/CIF/DAP quotation are all available.
