600V Copper Type 8 AWG PVC Insulated Copper Tw Thw Electric Cable Wire

600V Copper Type 8 AWG PVC Insulated Copper Tw Thw Electric Cable Wire image

Get Latest Price Request a quote

Product Details

Model NO.

TW wire

Application

Housing Use

Conductor Material

Copper

Sheath Material

No Sheath

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Housing Use

Certification

ISO9001, CCC

Brand

Hongda

Voltage

600V

Standard

IEC UL

Cable Type

Transport Package

Roll and Pallet

Specification

4AWG

Trademark

HONGDA

Origin

Henan/China

HS Code

8544492100

Production Capacity

10km/Day

Product Description

600V copper type 8 AWG PVC insulated copper TW THW electric cable wire

THW/TW Cable & THW/TW Wires

Construction Element:

1.Solid or stranded bare copper conductor

2.PVC insulation

Maximum Conductor Temperatur

TYPE	OIL	WET	DRY
TW	60°c	60°c	60°c
*THW*	75°c	75°c	75°c
*MTW*	60°c	60°c	90°c

AWG TW WIRE SPECIFICATION

SIZE AWG MCM	CROSS SECTION AL mm2	STRANDING number of wire x diametre mm	INSULATION THICKNESS mm	EXTERNAL DIAMETER mm	TOTAL WEIGHT KG/KM
20	0.52	1×0.813	0.76	2.33	9.81
18	0.82	1×1.02	0.76	2.54	13.16
16	1.31	1×1.29	0.76	2.81	18.1
14	2.08	1×1.63	0.76	3.15	26.1
12	3.31	1×2.05	0.76	3.57	38.3
10	5.26	1×2.59	0.76	4.11	57.4
8	8.34	1×3.26	1.14	5.54	95.2
14	2.08	7×0.62	0.76	3.38	27.8
12	3.31	7×0.78	0.76	3.86	40.1
10	5.26	7×0.98	0.76	4.46	59.9
8	8.37	7×1.23	1.14	5.97	105.2
6	13.3	7×1.55	1.52	7.69	170.4
4	21.15	7×1.96	1.52	8.92	255.5
2	33.62	7×2.47	1.52	10.45	388.9
1	42.36	7×2.78	2.03	12.4	482.9
1/0	53.49	19×1.89	2.03	13.51	621
2/0	67.43	19×2.12	2.03	14.66	778
3/0	85.01	19×2.39	2.03	16.01	934
4/0	107.2	19×2.68	2.03	17.46	1159
250	127	37×2.09	2.41	19.45	1368
300	152	37×2.29	2.41	20.85	1623
350	177	37×2.47	2.41	22.11	1876
400	203	37×2.64	2.41	23.3	2128
500	253	37×2.95	2.41	25.47	2631
600	304	37×3.23	2.79	28.19	3174
650	329	37×3.37	2.79	29.17	3345
700	355	37×3.49	2.79	30.01	3609

company information:

Hongda cable Co., Ltd. is one of the most professional cable & wire producer under modern enterprise system in China, which was founded in 1988, integrating scientific research, development, production and sales. Henan Hongda Cable Co., is the original Zhengzhou Hongda Cable Co., The company mainly produces 1-35 kV power cable, TW, THW, THHW, THHN electrical wire, ABC cable, Overhead Cable, AAC, AAAC, ACSR, ACAR bare conductor, Concentric Cable, etc

Our advantages
1.  With more than 17 years manufacturing experience, our products are strictly in accordance with ISO, SGS, CCC ;
2.  Good cost-control system, with highly-competitive prices;
3.  Strong and Professional R&D team to meet your specific needs;
4.  Fast delivery&reliable products are always the reason why you choose us.
Custom Merchandise: we can make cable as your need include the color ,size and so on.we also offer OEM

packing list:

More information and other cable inquiry, pls contact us as follows:

HENEN HONGDA CABLE CO., LTD.
Office: 21/F, Yaxing Times Square, Songshan Road, Erqi Zone, Zhengzhou 450000, China
Factory: Huijin Rd & Changping Rd, East Development Zone, Zhandian, Jiaozuo 454950, China.
Tel: +86 371 6097 5619 | Fax: +86 371 6097 5616

Mobile: +86 137834516132

We are China 600V Copper Type 8 AWG PVC Insulated Copper Tw Thw Electric Cable Wire manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
