600V AWG Copper Conductor PVC Insulated Thw Tw Electric Wire

600V 14 12 10 8 6 AWG copper conductor PVC insulated  THW TW electric wire

THW Applications

The copper conductors type THW are used for power and lighting circuits in industrial, commercial and residential facilities where it is required of more security, just as it is specified in the National Electrical Code. This type of conductor can be used in dry and wet places; its maximum temperature of operation is of 75 ºC and its voltage of service for all the applications it is 600 V.



THW Specifications

The copper conductors type THW, meets the following specifications and standards:

· ASTM B-3: Copper Annealed or Soft Wires.

· ASTM B-8: Copper Stranded Conductors in Concentric Layers, Hard, Semi-hard or Soft.

· UL – 83: Wires and Cables Insulated with Thermoplastic Material.

· NEMA WC-5: Wires and Cables Insulated with Thermoplastic Material (ICEA S-61-402) for Transmission and Distribution of Electric Power.



THW Construction

The conductors type THW can be solid or stranded and they are built with soft temper copper, they are also insulated with an uniform layer of Chloride of Polyvinyl (PVC) thermoplastic material resistant to the moisture and the heat. They can be supplied in varied colors according to their size and with different packaging.



THW Detail of the Cable

Copper Conductors type THW

CONDUCTOR MANUFACTURED UNDER STANDARDS:

NEMA WC-5 • ICEA S-61-402 • ASTM B3, B8 • UL STANDARD 83 • INEN

PACKAGING:

A: Roll of 100 m

B: Reel of 1500 m.

C: Reel of 1000 m.

D: Reel of 500 m.

E: Multiple Reels of 1000 m.

Z – Length to the client’s requirement.

AVAILABLE COLORS:

Cables (Sizes 20 to 10 AWG): Black, White, Sky Blue, Blue, Red, Purple, Yellow and Green.

Cables (Sizes 8 to 2 AWG): Black, White, Blue and Red.

Cables (Sizes 1 to 1000 MCM): Black. HIGHER SIZES (FROM 750 MCM TO 1.000 MCM), UNDER REQUIREMENT
