00V 4 Core 25mm 240mm Copper Cable Price Per Meter
These cables are used for electricity supply in low voltage installation system, they are suitable for installation in indoors and outdoors, in cable ducts, underground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage.
GB/12706-2008, IEC60502-1, IEC 60228, IEC60332, BS 6346, AS/NZS 5000.1 etc.
3 Product Properties
3.2 The ambient temperature for installation: ≥0ºC
3.3 Maximum conductor temperature in normal operation:≤70ºC
3.4 Max operating temperature of con. When cable short-circuited(5s maximum duration): 160ºC
3.5 Permissible minimum bending radius:
Single unarmoured cable: (20D±5%)mm
Multi-core unarmoured cable:(15D±5%)mm
Single armoured cable: (15D±5%)mm
Multi-core armoured cable:(12D±5%)mm
Note : D=over cable diameter
4 Product Type
| Chinese Type(General Type) | Designation | Application | |
| Cu | Al | ||
| VV (CU/PVC/PVC) | VLV (AL/PVC/PVC) | Cu conductor(Al conductor)PVC insulated PVC sheathed power cable | Laying indoors, in tunnel, fixed on the bracket, pipe and buried in the soil, the cable cannot bear external mechanical forces. |
| VY (CU/PVC/PE) | VLY (AL/PVC/PE) | Cu conductor(Al conductor)PVC insulated PE sheathed power cable | |
| VV22 (CU/PVC/STA/PVC) | VLV22 (AL/PVC/STA/PVC) | Cu conductor(Al conductor)PVC insulated double of steel-tape armored PVC sheathed power cable | For laying indoors, in tunnel, cable trench, or direct in ground, able to bear external mechanical forces, but unable to bear large pulling force. |
| VV23 (CU/PVC/STA/PE) | VLV23 (AL/PVC/STA/PE) | Cu conductor(Al conductor)PVC insulated double of steel-tape armored PE sheathed power cable | |
| VV62 (CU/PVC/ATA/PVC) | VLV62 (AL/PVC/STA/PVC) | Cu conductor(Al conductor)PVC insulated double of aluminium-tape armored PVC sheathed power cable | |
| VV63 (CU/PVC/STA/PE) | VLV63 (AL/PVC/STA/PE) | Cu conductor(Al conductor)PVC insulated double of aluminium-tape armored PE sheathed power cable | |
| VV32 (CU/PVC/SWA/PVC) | VLV32 (AL/PVC/SWA/PVC) | Cu conductor(Al conductor)PVC insulated steel-wire armored PVC sheathed power cable | For laying indoors, in tunnel, cable trench, well or direct in ground, able to bear external mechanical forces and certain pulling force. |
| VV33 (CU/PVC/SWA/PE) | VLV33 (AL/PVC/SWA/PE) | Cu conductor(Al conductor)PVC insulated steel-wire armored PE sheathed power cable | |
| VV72 (CU/PVC/AWA/PVC) | VLV72 (AL/PVC/AWA/PVC) | Cu conductor(Al conductor)PVC insulated aluminium-wire armored PVC sheathed power cable | |
| VV73 (CU/PVC/AWA/PE) | VLV73 (AL/PVC/AWA/PE) | Cu conductor(Al conductor)PVC insulated aluminium-wire armored PE sheathed power cable | |
5 Construction
Conductor shaped:RE=circular solid,CC=compacted circular stranded,SM=sector shaped stranded
Conductor: Plain circular ,compacted or shaped stranded copper or aluminium conductor ,conform to IEC60228 CLass 1 or Class 2
Insulation: PVC Compound Insulation
Colour identification :
1 Core: Red or Black
2 Cores: Red, Black
3 Cores: Red, Yellow, Blue
4 Cores: Red, Yellow, Blue, Black
5 Cores: Red, Yellow, Blue, Black, Green
Above 5 Cores: Black Cores with White numerals
The above identifying can be changed as order
Bedding /Inner Sheath :PVC Compound
Armour: Aluminium wire(AWA) or aluminium alloy wire(AWA), Galvanized steel wire(SWA) or steel tape(STA) ect.
Outer Sheath:PVC or PE Compound
Note: The armored material of single core cable should be non-magnetic or magnetic reduced structure. Generallly, single core armored cable (which uses steel or steel wire armored cable) only applies to DC occasions.
6 Product Parameters
| Type | Nominal section area mm2 |
Conductor diameter mm |
Nominal thickness of insulation mm |
Nominal sheath thickness mm |
Approx. overall diameter mm |
Approx.weight of cable kg/km |
Maximum DC resistance of the conductor Ω/km |
||
| Cu | Al | 20ºC Cu | 20ºC Al | ||||||
| VV | 4×1.5 RE 4×2.5 RE 4×4 RE 4×6 RE 4×10 CC |
1.38 1.78 2.24 2.76 3.8 |
0.8 0.8 1.0 1.0 1.0 |
1.8 1.8 1.8 1.8 1.8 |
11.4 12.4 14.5 15.7 18.2 |
177.0 226.9 320.2 424.1 607.6 |
– 164.7 220.7 274.9 358.9 |
12.1 7.41 4.61 3.08 1.83 |
– 12.1 7.41 4.61 3.08 |
| 4×16 CC 4×25 CC 4×35 CC 4×50 SM 4×70 SM |
4.8 6.0 7.0 8.0 9.5 |
1.0 1.2 1.2 1.4 1.4 |
1.8 1.8 1.8 1.9 2.1 |
20.6 24.5 26.9 28.0 31.6 |
861.0 1287.4 1687.4 2295.4 3095.1 |
463.1 665.6 816.9 1051.8 1354.1 |
1.15 0.727 0.524 0.387 0.268 |
1.91 1.20 0.868 0.641 0.443 |
|
| 4×95 SM 4×120 SM 4×150 SM 4×185 SM 4×240 SM |
11.0 12.4 13.8 15.4 17.5 |
1.6 1.6 1.8 2.0 2.2 |
2.2 2.3 2.5 2.7 2.9 |
35.9 38.5 42.8 48.4 53.5 |
4146.0 5125.7 6379.9 7849.2 10084.0 |
1783.2 2141.1 2649.2 3248.0 4114.8 |
0.193 0.153 0.124 0.0991 0.0754 |
0.320 0.253 0.206 0.164 0.125 |
|
| 4×300 SM | 19.6 | 2.4 | 3.1 | 59.2 | 12526.3 | 5064.8 | 0.0601 | 0.100 | |
