4X35mm 4X50mm 4X70mm 4X95mm 0.6 1kv XLPE Cable

4X35mm 4X50mm 4X70mm 4X95mm 0.6 1kv XLPE Cable image

Get Latest Price Request a quote

Product Details

Model NO.

0.6 1kv xlpe cable

Current

AC Cable

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Certification

ISO, CCC

Model

U1000 R2V RO2V Ar2V Rvfv

Brand

OEM

Transport Package

Wooden Drum

Specification

1.5-500mm2

Trademark

OEM

Origin

China(Mainland)

HS Code

8544492100

Production Capacity

500 Kilometer/Month

Product Description

Application and Description

These cables for energy distribution are suitable for all types of low voltage industrial-type connection, in urban grids, building installations, etc.

Particularly suited in cases of high operating temperature and when high resistance to solar radiation and atmospheric agents is required. Good resistance to low temperature and chemical agents.

Can be used without additional mechanical protection in the open air, fixed to walls or in raceways, inside walkways, and in empty in Cable Constructions in general. Can be laid underground with mechanical protection constructed from slabs, tiles, or bricks.

They are not recommend to lay this cable in ground flooded for more than two months per year. With appropriate mechanical protection it can be use in areas subject to risk of explosion, but in this case the permitted current load is reduced by 15%. It can be used in ambient temperature down to -25°C.

Standard and Approval

NF C 32-321
EN 60332-1/NF C 32-070

Cable Construction

Flexible electrolytic annealed copper strands

Strands to IEC 60228 class 2 , make-up with fine wires (Φ max. 0.4mm)with flexibility level equivalent to class 5

XLPE insulation according to NF C 32-321

Color codes to NF C32-321

Not fibrous and not hygroscopic filler

Flexible black PVC outer jacket

Technical Characteristics

Working Voltage	600/1000 volts
Test voltage	1200 volts
Minimum bending radius	6 x O
Operation temperature range	-15°C to 60°C
Short-circuit temperature	250°C
Flame retardant	NF C 32-070 C2
Insulation resistance	20 MΩ x km

Cable Parameter

AWG	Cross Section	Insulation thickness	Minimum Sheath thickness	Maximum Overall diameter	Approx Cable weight
	mm²	mm	mm	mm	kg/km
16	1×1.5	0.7	1.09	6.6	45
14	1×2.5	0.7	1.09	7	55
12	1×4	0.7	1.09	7.6	75
10	1×6	0.7	1.09	8.2	100
8	1×10	0.7	1.09	9.2	140
6	1×16	0.7	1.09	10.5	205
4	1×25	0.9	1.09	12.5	315
2	1×35	0.9	1.09	13.5	400
1	1×50	1	1.09	15	530
2/0	1×70	1.1	1.09	17	725
3/0	1×95	1.1	1.18	19	985
4/0	1×120	1.2	1.18	21	1260
300MCM	1×150	1.4	1.26	23	1520
500MCM	1×185	1.6	1.26	25.5	1940
750MCM	1×240	1.7	1.35	28.5	2310
	1×300	1.8	1.43	31	3200
16	2×1.5	0.7	1.43	10.5	115
14	2×2.5	0.7	1.43	11.5	145
12	2×4	0.7	1.43	13	195
10	2×6	0.7	1.43	14	265
8	2×10	0.7	1.43	16	390
6	2×16	0.7	1.43	18.5	560
4	2×25	0.9	1.43	22	850
2	2×35	0.9	1.43	24.5	1080
16	3×1.5	0.7	1.43	11	130
14	3×2.5	0.7	1.43	12.5	170
12	3×4	0.7	1.43	13.5	230
10	3×6	0.7	1.43	15	325
8	3×10	0.7	1.43	17	485
6	3×16	0.7	1.43	19.5	705
4	3×25	0.9	1.43	23.5	1080
2	3×35	0.9	1.43	26	1390
1	3×50	1	1.43	29	1840
2/0	3×70	1.1	1.52	34	2540
3/0	3×95	1.1	1.6	38.5	3430
4/0	3×120	1.2	1.69	42.5	4440
300MCM	3×150	1.4	1.86	47.5	5380
500MCM	3×185	1.6	1.94	53	6920
750MCM	3×240	1.7	2.11	59.5	8420
–	3×300	1.8	2.28	66	11300
16	4×1.5	0.7	1.8	11.3	180
14	4×2.5	0.7	1.8	12.2	220
12	4×4	0.7	1.8	13.3	300
10	4×6	0.7	1.8	15	420
8	4×10	0.7	1.8	17.25	630
6	4×16	0.7	1.8	18.8	900
4	4×25	0.9	1.8	23	1350
2	4×35	0.9	1.8	25.1	1750
1	4×50	1	1.9	29.1	2350
2/0	4×70	1.1	2	33.9	3400
3/0	4×95	1.1	2.1	38.4	4500
4/0	4×120	1.2	2.3	42.4	5700
300MCM	4×150	1.4	2.4	47.2	7050
500MCM	4×185	1.6	2.6	52.65	8700
750MCM	4×240	1.7	2.8	59	11400
–	4×300	1.8	3	64.8	14200
1	3×50+35	1	1.8	28.8	2200
2/0	3×70+50	1.1	2	33.4	3100
3/0	3×95+50	1.1	2.1	37	3950
4/0	3×120+70	1.2	2.2	41.3	5050
300MCM	3×150+70	1.4	2.3	45.1	6100
500MCM	3×185+70	1.6	2.5	50	7400
750MCM	3×240+95	1.7	2.7	55.8	9700
16	5×1.5	0.7	1.8	12.1	205
14	5×2.5	0.7	1.8	13.1	260
12	5×4	0.7	1.8	14	350
10	5×6	0.7	1.8	16.3	500
8	5×10	0.7	1.8	18.5	760
6	5×16	0.7	1.8	20.6	1100
4	5×25	0.9	1.8	25.4	1600
16	7×1.5	0.7	1.8	12.3	260
14	7×2.5	0.7	1.8	13.2	330
12	7×4	0.7	1.8	15.4	450
16	8×1.5	0.7	1.8	13.9	290
14	8×2.5	0.7	1.8	14.9	380
12	8×4	0.7	1.8	16.5	520
16	10×1.5	0.7	1.8	15.8	350
14	10×2.5	0.7	1.8	17	450
12	10×4	0.7	1.8	19	630
16	12×1.5	0.7	1.8	15.5	390
14	12×2.5	0.7	1.8	16.8	510
12	12×4	0.7	1.8	19.6	700
16	14×1.5	0.7	1.8	17	440
14	14×2.5	0.7	1.8	18.3	580
12	14×4	0.7	1.8	20.5	800
16	19×1.5	0.7	1.8	17.9	550
14	19×2.5	0.7	1.8	19.4	740
12	19×4	0.7	1.8	22.6	1050
16	24×1.5	0.7	1.8	20.7	670
14	24×2.5	0.7	1.8	23.2	900
16	30×1.5	0.7	1.8	22.6	800
14	30×2.5	0.7	1.8	24.5	1100
16	37×1.5	0.7	1.8	23.5	950
14	37×2.5	0.7	1.8	26.3	1300
