4mm 6mm 26mm 24mm Solar Cable Tinned Copper Core Xlpo Insulation

4mm 6mm 2*6mm 2*4mm Solar Cable Tinned Copper Core Xlpo Insulation image

Get Latest Price Request a quote

Product Details

Model NO.

4mm 6mm 2*6mm 2*4mm Solar Cable

Application

Solar System

Conductor Material

Tinned Copper Wire/Bare Copper Wire

Sheath Material

Xlpo

Insulation Material

Xlpo

Material Shape

Round Wire

Range of Application

Construction

Certification

ISO9001, CE, CCC, RoHS, VDE

Brand

Hongda

Standard

IEC

Product Name

Single Core Photovoltaic Cables

Key Word

UL TUV Certificate Solar Power Cable Double Core 4

Voltage

1500V

Transport Package

Wooden Box

Specification

4mm 6mm 2*6mm 2*4mm solar cable

Trademark

HONGDA CABLE

Origin

Henan China

HS Code

8544492100

Production Capacity

500000meter/Week

Product Description

4mm 6mm 2*6mm 2*4mm Solar Cable Tinned Copper Core Xlpo Insulation

Solar panels cable for Photovoltaic Project (IEC Standard )
Single Core Photovoltaic Cables
Type	Sectional area mm²	Conductor			Insulation		Jacket		Weight kg/km
Type	Sectional area mm²	No./Dia		Outer dia	Thickness	Dia	Thickness	Dia	Weight kg/km
PV1-F	1.5	30/0.25		1.60	0.75	3.10	0.80	4.70	37.4
PV1-F	2.5	49/0.25		2.10	0.75	3.60	0.80	5.20	49.5
PV1-F	4	52/0.3		2.60	0.75	4.10	0.80	5.70	64.6
PV1-F	6	78/0.3		3.20	0.75	4.70	0.80	6.30	85.6
PV1-F	10	84/0.4		4.70	0.75	6.20	0.80	7.80	142.1
PV1-F	16	126/0.4		5.80	0.75	7.30	0.80	8.90	197.7
PV1-F	25	196/0.4		7.60	0.75	9.10	0.80	10.70	290.1
PV1-F	35	276/0.4		9.10	1.20	11.50	1.40	14.30	455.9
PV1-F	50	396/0.4		11.30	1.40	14.10	1.40	16.90	633.6
PV1-F	70	360/0.5		12.80	1.40	15.60	1.40	18.40	841.0
PV1-F	95	475/0.5		15.00	1.60	18.20	1.60	21.40	1111.2
PV1-F	120	608/0.5		14.00	1.60	17.20	1.60	20.40	1330.0
PV1-F	150	756/0.5		19.00	1.80	22.60	1.80	26.20	1713.4
PV1-F	185	925/0.5		21.00	2.00	25.00	2.00	29.00	2097.2
PV1-F	240	1221/0.5		23.80	2.20	28.20	2.20	32.60	2729.6

Type AWG	Sectional area mm²	Conductor			Insulation		Jacket		Weight kg/km
Type AWG	Sectional area mm²	No./Dia		Outer dia	Thickness	Dia	Thickness	Dia	Weight kg/km
4	21.15	420	0.254	6.8	0.75	8.3	0.8	9.9	254.08
6	13.3	266	0.254	5.4	0.75	6.9	0.8	8.5	173.60
8	8.367	168	0.254	4.3	0.75	5.8	0.8	7.4	120.81
10	5.261	105	0.254	3.4	0.75	4.9	0.8	6.5	85.42
12	3.31	48	0.3	2.4	0.75	3.9	0.8	5.5	60.60
14	2.08	41	0.254	1.9	0.75	3.4	0.8	5	45.04

Two Cores Photovoltaic Cables
Type	Sectional area mm²	Conductor			Insulation		Jacket		Weight kg/km
Type	Sectional area mm²	No./Dia		Outer dia	Thickness	Dia	Thickness	Dia	Weight kg/km
PV1-F/Round	2*1.5	30/0.25		1.60	0.75	3.10	1.00	8.20	98.6
PV1-F/Round	2*2.5	49/0.25		2.10	0.75	3.60	1.00	9.20	131.2
PV1-F/Round	2*4	52/0.3		2.60	0.75	4.10	1.00	10.20	171.0
PV1-F/Round	2*6	78/0.3		3.20	0.75	4.70	1.00	11.40	225.8
PV1-F/Flat	2*1.5	30/0.25		1.60	0.75	3.10	0.80	4.7*9.5	76.2
PV1-F/Flat	2*2.5	49/0.25		2.10	0.75	3.60	0.80	5.2*10.5	100.4
PV1-F/Flat	2*4	52/0.3		2.60	0.75	4.10	0.80	5.7*11.5	130.7
PV1-F/Flat	2*6	78/0.3		3.20	0.75	4.70	0.80	6.3*12.7	172.7

Packaging Details:Wooden drums,steel wooden drums or as your requirement
Delivery Time:Normally within 30 days(detailly depend on the order quantity)
