4AWG 6AWG Superflex Parallel Bonded Double Conductor Bulk Cable

4AWG 6AWG Superflex Parallel Bonded Double Conductor Bulk Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Superflex cable

Application

Overhead, Heating, Underground

Conductor Material

Copper

Sheath Material

CPE

Insulation Material

CPE

Material Shape

Flat Wire

Range of Application

Cold-Resistant

Certification

ISO9001, CE, CCC

Brand

Hongda Cable

Rated Voltage

600V

Test Voltage

2000V

Sheath Colour

Blue or Other Colors

Max Operating Temperature

70°c

Transport Package

Rolls

Specification

8awg 6awg 4awg 2awg 1/0awg 3/0awg

Trademark

hongda cable

Origin

Henan China

HS Code

8544492100

Production Capacity

100000meter/Week

Product Description

Superflex Parallel Bonded Double Conductor Bulk Cable

The cable superflex flexibility is achieved by combining finely stranded copper construction with a jacket that resists the abuses of oil, gasoline, salt water, acids, sunlight and chemicals. It is highly abrasion resistant and can be used in most 600 volt applications.

Construction:

• 100% COPPER conductors-Absolutely NO ALUMINUM

• Highly abrasion and chemical resistant TPE jacket

Applications

• Battery and jumper cables

• Wind and solar power systems

• Outboard motor leads

• Tow truck booster systems

• ATV and RV power cables

• UPS power supply systems

Size and Colors

• 8 AWG – 3/0 AWG

• Custom sizes, colors, and striping available on request.

Copper Stranding

• Flexible Class K fine stranded 100% copper for maximum conductivity

Superflex Parallel Bonded Double Conductor Bulk Cable Parameters:

Size	Class K Copper Strand Qty/AWG	Class K Copper Strand Style	Nominal Conductor Outside Diameter	Insulation Thickness	Minimum Finished Outeside diameter
18 AWG	16/30	Tinned	0.047″	0.030″	0.105″
16 AWG	26/30	Tinned	0.059″	0.030″	0.118″
14 AWG	41/30	Tinned	0.074″	0.030″	0.130″
12 AWG	65/30	Tinned	0.093″	0.030″	0.150″
10 AWG	105/30	Tinned	0.118″	0.030″	0.180″
8 AWG	168/30	Bare	0.150″	0.045″	0.240″
6 AWG	266/30	Bare	0.190″	0.060″	0.310″
4 AWG	420/30	Bare	0.240″	0.060″	0.360″
2 AWG	665/30	Bare	0.310″	0.060″	0.430″
1 AWG	836/30	Bare	0.335″	0.080″	0.495″
1/0 AWG	1064/30	Bare	0.390″	0.080″	0.550″
2/0 AWG	1330/30	Bare	0.435″	0.080″	0.600″
3/0 AWG	1672/30	Bare	0.490″	0.080″	0.650″
4/0 AWG	2109/30	Bare	0.530″	0.085″	0.710″
250 MCM	2451/30	Bare	0.685″	0.095″	0.875″
350 MCM	3458/30	Bare	0.820″	0.095″	1.010″
500 MCM	5054/30	Bare	0.995″	0.110″	1.220″

More information and inquiry please contact with Vivian Yuan.

We are China 4AWG 6AWG Superflex Parallel Bonded Double Conductor Bulk Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
