450/750V Single Core Non-Sheathed PVC Insulated Cables Cu/PVC

450/750V Single Core Non-Sheathed PVC Insulated Cables Cu/PVC image

Get Latest Price Request a quote

Product Details

Model NO.

CU/PVC Cables

Application

Overhead, Heating, Underground, in Conduit, in Cable Trunking

Conductor Material

Red Copper Wire

Sheath Material

Bare

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

in Dry Rooms, Instruments, Switches and Distributi

Certification

ISO9001, CCC, SGS

Brand

Hongda

Central Conductor

Fine Solid Copper

Insulation

Polyvinyl Chloride (PVC)

Transport Package

a: Roll of 100 M B: Reel of 1500 M.

Specification

0.5mm2 to 10mm2

Trademark

Hongda or as customer require

Origin

China

HS Code

8544492900

Production Capacity

40km/Day

Product Description

450/750V Single Core Non-Sheathed PVC Insulated Cables CU/PVC

Operating Temperature: -15°C to 70°C

Final Short Circuit

160°C for cable < 300mm2

140°C for cable >300mm2

Test Voltage: 2.5kV For 5 minutes

PVC Insulated Cables CU/PVC

Application and Description
These insulated wires are determined for the installation to the inside of apparatus as well as for the protective laying to the lightings, in dry rooms, in production facilities, switch and distributor boards, in tubes, under and surface mounting of plasters.
These insulated wires are suitable for laying tubes, under and surface mounting of plasters and also in closed installation conduits. These are not allowed to install for direct laying in cable trays, channels or tanks.
These types are permitted for the inner wiring of equipment, distributor and switchboards and also for protective laying to the lightings with a nominal voltage up to 1000 V alternating current or up to 750 V direct current against ground.

Standard and Approval

SS358-3, BS6004, IEC60227-3

Cable Construction

Voltage rating	450/750V
Construction	Plain annealed copper, PVC insulated cable
Insulation Colour	Brown, Black, Grey, Blue, Green/Yellow or as per order

PVC Insulated Cables Specification:

Nominal Cross Sectional area (mm2)	Conductor		Thickness of insulation (mm)	Overall Diameter		Cable weight (approx.) Kg/Km	Standard length (m)
Nominal Cross Sectional area (mm2)	Number of wire (min)	Diameter Approx. (mm)	Thickness of insulation (mm)	Lower Limit (mm)	Upper Limit (mm)	Cable weight (approx.) Kg/Km	Standard length (m)
1.5	1	1.38	0.7	2.6	3.2	22	100/C
1.5	7	1.50	0.7	2.7	3.3	24	100/C
2.5	1	1.78	0.8	3.2	3.9	32	100/C
2.5	7	2.01	0.8	3.3	4.0	35	100/C
4	1	2.25	0.8	3.6	4.4	49	100/C
4	7	2.55	0.8	3.8	4.6	50	100/C
6	1	2.76	0.8	4.1	5.0	75	100/C
6	7	3.12	0.8	4.3	5.2	80	100/C
10	1	3.57	1.0	5.3	6.4	120	100/C
10	7	4.05	1.0	5.6	6.7	130	100/C
16	7	5.10	1.0	6.4	7.8	180	100/C
25	7	6.42	1.2	8.1	9.7	280	100/C
35	19	4.59	1.2	9.0	10.9	380	100/C
50	19	8.90	1.4	10.6	12.8	500	500/D
70	19	10.7	1.4	12.1	14.6	700	500/D
95	19	12.6	1.6	14.1	17.1	1000	500/D
120	37	14.21	1.6	15.6	18.8	1200	500/D
150	37	15.75	1.8	17.3	20.9	1500	500/D
185	37	17.64	2	19.3	23.3	1900	500/D
240	61	20.25	2.2	22.0	26.6	2500	500/D
300	61	22.68	2.4	24.5	29.6	3100	500/D
400	61	25.65	2.6	27.5	33.2	3900	500/D
500	61	28.80	2.8	31.2	37.6	4920	500/D
630	127	32.76	2.8	35.2	41.7	6260	500/D

Tolerance of pulley is ±5%

PVC H05V-U / H07V-U Nya Cable PACKAGING:

A: Roll of 100 m

B: Reel of 1500 m.

C: Reel of 1000 m.

D: Reel of 500 m.

E: Multiple Reels of 1000 m.

Z – Length to the client’s requirement.

PVC H05V-U / H07V-U Nya Cable AVAILABLE COLORS:

Cables (Sizes 0.5mm2 to 6mm2): Black, White, Sky Blue, Blue, Red, Purple, Yellow and Green.

Cables (Sizes 10mm2 to 25mm2): Black, White, Blue and Red.

Cables (Sizes 25mm2 to 240mm2): Black. HIGHER SIZES (FROM 750 MCM TO 1.000 MCM), UNDER REQUIREMENT.

Please contact us for technical support with the right cable selection for your power distribution projects and to discuss your maintenance or project specific requirements. We provide tailored solutions for this cable range which include storage, cutting to length, and 2 days collection as standard.

Any problem and inquiry pls contact with Vivian Yuan.

We are China 450/750V Single Core Non-Sheathed PVC Insulated Cables Cu/PVC manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
