3X70/35mm2 N2xse (FL) 2yr2y 6/10 (12) Kv Oil Resistant Cable

3X70/35mm2 N2xse (FL) 2yr2y 6/10 (12) Kv Oil Resistant Cable image

Get Latest Price Request a quote

Product Details

Model NO.

3x70/35mm2 6/10(12)kV cable

Current

AC Cable

Insulation Material

XLPE

Sheath Material

Flame Retardant PVC

Material Shape

Round Wire

Wire Core Material

Bare Copper Wire

Certification

ISO, CCC

Model

3X70/35mm2 6/10(12)Kv Cable

Brand

Hongda

Temperature for Permanently Laid Cables

- 30c

Standard

Acc. IEC 60332-1 60502-2

Market

European

Transport Package

Steel & Wooden Drum

Specification

3x70/35mm2 6/10(12)kV cable

Trademark

Hongda

Origin

China

HS Code

8544601200

Production Capacity

500km/Month

Product Description

3×70/35mm2 N2XSE(FL)2YR2Y 6/10(12)kV Oil resistant cable

Application
XLPE insulated 300 sq mm Power Cables functions well for electricity transmission and distribution lines for its excellent electrical and physical properties, including the advantage of simplicity in construction, lightness in weight; convenience in application besides its excellent electrical, thermal, mechanical and anti-chemical corrosion properties. Laying indoors, in tunnel, fixed on the bracket, pipe and buried in the soil, the cable cannot bear external mechanical forces.

Standard

IEC60502,IEC 60228,IEC60332, BS 5467, BS 6622, IS 1554, IS 7098 and ICEA S-66-524 etc.
Hongda Cable can also design and produce for special application requirement.

Product Range

Rated voltage: 6/10kV
No. of Cores: single core, 3 core
The ambient temperature for installation: ≥0ºC
Max. conductor temperature in normal operation: 90ºC
Max. operating temperature of conductor when cable short-circuited (5s maximum duration): 250ºC

Construction

Conductor: Plain annealed stranded copper conductor (aluminum) to IEC60228 class 2
Conductor Screen: Extruded semi-conductive compound
Insulation: XLPE (cross-linked polyethylene)
Insulation Screen: Extruded semi-conductive compound
Metallic Screen: Copper tape
Inner Sheath: Extruded layer of PVC (type ST2)
Armour: Double of aluminium tape
Outer Sheath: PVC (type ST2) to IEC 60502

Main Techncial Data

Packing & Shipping
We provide you with the best product packaging design services, thereby allowing you to save more shipping charges.

FAQ

1. Q: Are you the factory or the trading company?
    A: We are the factory.
2. Q: How long is your guarantee Period?
    A: We usually offer 1 year guarantee for our general products.
3. Q: How can I get the samples?
    A: We can make the sample order. And usually you will charge for it.
    But the samples fee will be return to you when you make the bulk order.
4. Q: Where is your factory? How can we visit your factory?
    A: Our factory located in Jiaozuo city, Henan Province and our office is in Zhengzhou city. You could reach here by train and by air. We can pick you up in the airport and the railway station.
5. Q: What is your MOQ?
    A: It`s base on the cable type or size. Please contact Ms. Melon. She will offer you the details.

Factory

Established in 2004, Henan Hongda Cable Co., Ltd, is dedicated into manufacturing various types of electric power wire and cable. Today, Henan Hongda has grown into an integrated system solution provider in electric power distribution industry, extending the business from power cable and electric wire manufacture to electric power distribution system design, and electric distribution system construction and installation.
Today, Henan Hongda has grown into an integrated system solution provider in electric power distribution industry, extending the business from power cable and electric wire manufacture to electric power distribution system design, and electric distribution system construction and installation.

Our Service

1. Design wire and cable according to your real application
2. Optimized reel size for freight cost saving
3. Customized package to feature your brand
4. Short lead time to meet your urgent demand
5. Diversified delivery terms for your options
6. Quick response (24 hours on line)
7. Professional knowledge for clear answer to your any question
8. Comprehensive technical documents to support your tender bidding
9. One-year limited warranty for our wire and cable
10. Cable sample available
11. Specify the cable only according to the location
12. OEM is available
13. Abundant cables and wires for your option

Contact Us

Ms.Anna
************************************************************************************************

Henan Hongda Cable Co., Ltd http://zzhongdacable.en.
Changping Road 3,Zhandian NewDistrict,Wuzhi County,Jiaozuo,Henan Province, China
Office Add: Room2108,Yaxing Times Square,Zhengzhou,Henan,China. P.C. 450000
************************************************************************************************

We are China 3X70/35mm2 N2xse (FL) 2yr2y 6/10 (12) Kv Oil Resistant Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
