300/500V Nhmh-O / Nhmh-J E30 3X2.5 XLPE Insulation Halogen-Free Cable

300/500V Nhmh-O / Nhmh-J E30 3X2.5 XLPE Insulation Halogen-Free Cable image

Get Latest Price Request a quote

Product Details

Model NO.

NHMH-O / NHMH-J

Application

Overhead, Heating, Underground

Conductor Material

Copper

Sheath Material

Flame Resistance

Insulation Material

XLPE

Material Shape

Round Wire

Range of Application

LSOH

Certification

ISO9001, CCC

Brand

OEM

Voltage

300/500V

Transport Package

500/1000m Per Drum

Specification

1.5mm2 to 300mm2

Trademark

Hongda Cable

Origin

China, Henan

HS Code

8544492100

Production Capacity

2000km/Per Months

Product Description

300/500V NHMH-O / NHMH-J E30 3×2.5 XLPE Insulation Halogen-free Cable

Cable structure

1. Conductor
Class 1 solid, copper conductor

2. Insulation
XLPE (Cross-Linked Polyethylene) Type 2XI1 according to HD 604

3. Filler
Halogen-free compound

4. Sheath
Halogen-free thermoplastic polymer compound Type HM2 according to VDE 0207

Application

These cables are intended for fixed installation in dry and moist rooms as well as in masonry and concrete, in and under plaster; not for underground installation. For installations where fire, smoke emission and toxic fumes create a potential risk to life and equipment.

Characteristics

Voltage Rating (Uo/U)
300/500V

Temperature Rating
-5°C to +70°C

Minimum Bending Radius
Fixed: 4 x overall diameter

Core Identification
2 core: Blue Brown
3 core: Blue Brown Green/Yellow
4 core: Brown Black Grey Green/Yellow
5 core: Brown Black Grey Blue Green/Yellow
7 core and above: number coded

Sheath Colour
Grey

Size, Weight & Electrical Specification

No. of cores	Nominal Cross Sectional Area	Nominal Overall Diameter	Nominal Weight
	mm2	mm	kg/km
1	1.5	5.2	92
1	2.5	5.6	110
1	4	7.1	135
1	6	7.4	160
1	10	7.8	215
1	16	8.8	295
2	1.5	8.2	110
2	2.5	9	130
2	4	9.8	175
3	1.5	8.6	130
3	2.5	9.5	163
3	4	10.7	235
3	6	12.3	320
3	10	14.8	480
3	16	19.7	850
4	1.5	9.2	151
4	2.5	10.2	200
4	4	12.2	300
4	6	13.2	395
4	10	15.8	595
4	16	20	935
5	1.5	9.8	175
5	2.5	10.7	238
5	4	13.2	350
5	6	14.8	480
5	10	17.4	710
5	16	22	1140
7	1.5	10.2	210
7	2.5	12.2	300
