300/500V Multi-Core, Yslcy, PVC Insulated, Braided Screen, PVC Sheathed Flexible Control Cable

300/500V Multi-Core, Yslcy, PVC Insulated, Braided Screen, PVC Sheathed Flexible Control Cable image

Get Latest Price Request a quote

Product Details

Model NO.

YSLCY cable

Application

Overhead, Heating, Underground

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

LSOH

Certification

ISO9001, CE, CCC

Brand

Hongda Cable

Operating Voltage

300/500 V

Test Voltage

2000 V

Operating Tª (Conductor)

Service: -40°c +70°c

Min. Bending Radius

Fixed Installation: 10xd

Applications

Industrial Processes and Machinery in Fixed Instal

Transport Package

Sold in Full Drums or Cut to Specification

Specification

0.5mm2 to 16mm2

Trademark

hongda cable

Origin

China

HS Code

8544492100

Production Capacity

500000m/Week

Product Description

300/500V Multi-Core, YSLCY, PVC Insulated, Braided Screen, PVC Sheathed Flexible Control Cable

Flexible shielded control and instrumentation cable designed for use in industrial processes and machinery in fixed installations. In environments where good electromagnetic protection is required. The cable is also resistant to the most common chemicals, oils and greases in the industrial sector.

Construction

1. Conductor

Flexible bare copper wires

Class V Acc. to UNE-EN 60228

2. Insulation

PVC

Identification:

-JZ: Black numbered + Yellow/Green

-OZ: Black numbered

3. Assembly

Insulated conductors laid-up together in concentric layers + Overall tape

4. Screen

Bare copper wire braid

Coverage: 70% aprox.

5. Outer sheath

PVC

Colour: Grey

Technical characteristics

1. Operating voltage

300/500 V

2. Test Voltage

2000 V

3. Operating Tª (conductor)

Service: -40°C +70°C

During Installation: -5°C Minimum

4. Min. bending radius

Fixed installation: 10xD

Standards / Properties

1. Flame Retardant

IEC 60332-1

2. CPR Classification (Euroclass)

Eca (According UNE-EN 50575)

3. Oil resistant

EN 60811-2-1

Multi-Core, YSLCY, PVC Insulated, Braided Screen, PVC Sheathed Flexible Control Cable
Dimensions

No. of Cores x Cross Section	Approx. Outer Diameter	Approx. Cable Weight	Conductor resistance at 20ºC
mm2	mm	kg/km	ohm/km
2×0,5	5,2	35	39
3×0,5	5,5	45	39
4×0,5	6,2	60	39
5×0,5	6,6	70	39
7×0,5	7,9	100	39
12×0,5	9,4	135	39
18×0,5	10,9	190	39
25×0,5	13,2	255	39
2×0,75	5,5	50	26
3×0,75	6,1	60	26
4×0,75	6,5	70	26
5×0,75	7,2	85	26
7×0,75	8,3	120	26
12×0,75	10,0	175	26
18×0,75	11,7	240	26
25×0,75	14,5	340	26
2×1,0	6,0	60	19.5
3×1,0	6,4	75	19.5
4×1,0	7,4	90	19.5
5×1,0	7,7	120	19.5
7×1,0	8,9	160	19.5
12×1,0	11,0	265	19.5
18×1,0	13,0	330	19.5
25×1,0	15,8	405	19.5
2×1,5	7,1	85	13.3
3×1,5	7,6	100	13.3
4×1,5	8,2	120	13.3
5×1,5	9,1	150	13.3
7×1,5	10,5	205	13.3
12×1,5	12,8	300	13.3
18×1,5	15,5	435	13.3
25×1,5	18,2	570	13.3
2×2,5	8,1	110	7.98
3×2,5	8,8	140	7.98
4×2,5	9,5	175	7.98
5×2,5	10,7	210	7.98
7×2,5	11,7	285	7.98
12×2,5	15,8	450	7.98
18×2,5	19,2	720	7.98
25×2,5	22,2	900	7.98
3G4	10,8	255	4.95
4G4	11,8	305	4.95
3G6	13,3	310	3.3
4G6	13,8	435	3.3
3G10	15,8	480	1.91
4G10	17,8	660	1.91
3G16	20,1	825	1.21
4G16	22,1	1025	1.21

*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

We are looking forward to your inquiry and nice cooperation. Contact with Vivian Yuan to get price and more information.

We are China 300/500V Multi-Core, Yslcy, PVC Insulated, Braided Screen, PVC Sheathed Flexible Control Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
