300/500V 4X16+1X2, 5+8X1, 5+2X (2X1StD) mm2 Flexible Low Voltage Lift Rubber Power Cable

300/500V 4X16+1X2, 5+8X1, 5+2X (2X1StD) mm2 Flexible Low Voltage Lift Rubber Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Lift cable

Current

DC & AC

Insulation Material

PVC

Sheath Material

PUR

Material Shape

Round

Wire Core Material

Copper

Certification

ISO, CCC, CE, VDE

Model

Fg7or

Brand

Huadong

Product Name

Flexible Rubber Lift Cable

Rated Voltage

300/500V

Temperature

-40 to 80 Centigrade

Standard

DIN VDE 0298, Part 4

Transport Package

by Wooden Drum or Others

Specification

by meters

Trademark

huadong

Origin

China

HS Code

8544492100

Production Capacity

15 Million Km

Product Description

300/500V 4×16+1×2,5+8×1,5+2x(2x1StD) mm2 Flexible Low Voltage Lift Rubber Power Cable
ApplicationFlexible low voltage lift cable for Construction lift cables are used on lifts for the transport of persons and material. The
cables are subject to extreme usage conditions, such as heat, cold, moisture,oil and chemicals.

Cable Construction:

Conductor:	Bare copper , very finely stranded, class 5
Insulation:	UV resistant, weather resistant PVC
Screen:	Aluminium/polyester tape with tinned copper drainage wire shield
/	PVC with galvanized steel wire rope filler
Inner sheath	PVC
Outer sheath	PUR

Characteristics
Electrical parameters
Rated voltage (Uo/U) 300/500 V
AC test voltage 2kV/5Min.
Current carrying capacity According to DIN VDE 0298, Part 4

Thermal parameters
Ambient temperature Fully flexible operation -25°C to +80°C Fixed installation -40°C to +80°C
Maximum permissible operating temperature of the conductor 90°C

Chemical parameters
Resistance to oil DIN EN 60811-404; DIN VDE 0473-811-404, paragraph 10
Weather resistance Unrestricted use outdoors and indoors, resistant to ozone, UV and moisture

Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.

1.what is our payment term?
Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time?
The lead time usually is 10 – 30 working days.

3.what is the package of the cable?
The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirement.

4.Could we provide the free sample for customer?
Sure, we provide the free sample for customer to checking.

Please feel free to leave your requirement, We will reply you in 12 hours.

We are China 300/500V 4X16+1X2, 5+8X1, 5+2X (2X1StD) mm2 Flexible Low Voltage Lift Rubber Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
