3 phase 1.5mm 2.5mm CU/PVC/PVC H05VV-U for Housing Cable
SSA 1450, IEC 60227 ( IEC 10)
Wires and wiring cables are used to supply power for lighting and electric appliances and equipment in residences, offices, and similar environments.
SPECIFICATIONS
For internal wiring of equipment rated voltage up to 1000 V AC and up to 750 V DC to earth
| Nominal Cross Section | Number of Wires in Conductor | Diameter of Conductor Approx | Insulation Thickness | Sheath Thickness | Overall Diameter | Weight of Finished Cable Approx | Maximum DC Resistance at 20°C |
|---|---|---|---|---|---|---|---|
| mm² | mm | mm | mm | mm | Kg/Km | Ohm/Km | |
| 2×1.5 | 1 | 1.38 | 0.7 | 1.2 | 10.0 | 120 | 12.1 |
| 2×2.5 | 1 | 1.78 | 0.8 | 1.2 | 11.5 | 165 | 7.41 |
| 2×4 | 1 | 2.25 | 0.8 | 1.2 | 12.5 | 215 | 4.61 |
| 2×6 | 1 | 2.76 | 0.8 | 1.2 | 13.5 | 270 | 3.08 |
| 2×10 | 1 | 3.57 | 1.0 | 1.4 | 16.5 | 440 | 1.83 |
| 3×1.5 | 1 | 1.38 | 0.7 | 1.2 | 10.5 | 140 | 12.1 |
| 3×2.5 | 1 | 1.78 | 0.8 | 1.2 | 12.0 | 195 | 7.41 |
| 3×4 | 1 | 2.25 | 0.8 | 1.2 | 13.0 | 250 | 4.61 |
| 3×6 | 1 | 2.76 | 0.8 | 1.4 | 14.5 | 345 | 3.08 |
| 3×10 | 1 | 3.57 | 1.0 | 1.4 | 17.5 | 540 | 1.83 |
| 4×1.5 | 1 | 1.38 | 0.7 | 1.2 | 11.5 | 165 | 12.1 |
| 4×2.5 | 1 | 1.78 | 0.8 | 1.2 | 13.0 | 235 | 7.41 |
| 4×4 | 1 | 2.25 | 0.8 | 1.4 | 14.5 | 325 | 4.61 |
| 4×6 | 1 | 2.76 | 0.8 | 1.4 | 16.0 | 430 | 3.08 |
| 4×10 | 1 | 3.57 | 1.0 | 1.4 | 19.0 | 665 | 1.83 |
| 5×1.5 | 1 | 1.38 | 0.7 | 1.2 | 12.0 | 195 | 12.1 |
| 5×2.5 | 1 | 1.78 | 0.8 | 1.2 | 14.0 | 285 | 7.41 |
| 5×4 | 1 | 2.25 | 0.8 | 1.4 | 16.0 | 405 | 4.61 |
| 5×6 | 1 | 2.78 | 0.8 | 1.4 | 17.5 | 530 | 3.08 |
| 5×10 | 1 | 3.57 | 1.0 | 1.4 | 21.0 | 810 | 1.83 |
