3 Core 3*2.5mm Ce Certificate Flexible Rvv Wire Cooper Conductor Fire Resistance PVC Insulation

3 Core 3*2.5mm Ce Certificate Flexible Rvv Wire Cooper Conductor Fire Resistance PVC Insulation image

Get Latest Price Request a quote

Product Details

Model NO.

3 core 3*2.5mm CE certificate flexible RVV wire C

Application

Heating

Conductor Material

Copper

Sheath Material

PVC

Insulation Material

PVC

Material Shape

Round Wire

Range of Application

Construction

Certification

ISO9001, CE, CCC, RoHS

Brand

Hongda

Voltage

300/500V

Core

3/4/5 Core

Key Word

3 Core 3*2.5mm Ce Certificate Flexible Rvv Wire C

Product Name

3 Core 3*2.5mm Ce Certificate Flexible Rvv Wire C

Transport Package

Wooden Box

Specification

3 core 3*2.5mm CE certificate flexible RVV wire C

Trademark

HONGDA CABLE

Origin

Henan China

HS Code

8544492100

Production Capacity

500000meter/Week

Product Description

3 core 3*2.5mm CE certificate flexible RVV wire Cooper conductor fire resistance pvc insulation

Conductor:Stranded bare copper or tinned copper
Insulation:PVC
Jacket Material:PVC

Features & Conformity:

Features : Super fine conductor, flexible for small bending angle . Durable for certain external mechanical forces

Conformity Approval :ISO SGS CCC BV CE

Technical Parameter:

Rated Voltage: 300/500V, 450/750V

Min. bending Radius:

Fixed Installation: 5×D(Cable OD) : Movable Installation: 8×D(Cable OD)

Temperature Range:Fixed Installation: -20 to +70ºC ;Movable Installation: -5 to +70ºC

Product Code	Nominal cross-sectional area of conductor	Class of conductor	Thickness of insulation	Thickness of outer sheath	Mean overall diameter
	Nominal cross-sectional area of conductor	Class of conductor	Thickness of insulation	Thickness of outer sheath	Lower limit	Upper limit
	mm2		mm	mm	mm	mm
RVV-2C1.5	2X1.5	5	0.7	0.8	6.8	8.6
RVV-2C2.5	2X2.5	5	0.8	1.0	8.4	10.6
RVV-3C1.5	3X1.5	5	0.7	0.9	7.4	9.4
RVV-3C2.5	3X2.5	5	0.8	1.0	9.2	11.4
RVV-4C1.5	4X1.5	5	0.7	1.0	8.4	10.5
RVV-4C2.5	4X2.5	5	0.8	1.1	10.1	12.5
RVV-5C1.5	5X1.5	5	0.7	1.1	9.3	11.6
RVV-5C2.5	5X2.5	5	0.8	1.2	11.2	13
