2-2-2 Conch Aluminum Triplex Overhead Neutral-Supported Multiplex Conductor Service Drop Cable

Specification

2-2-2 Conch Aluminum Triplex Overhead

Allowable Ampacity for 2-2-2 Conch Aluminum Triplex Overhead XLP at 90°C: 150 Amps

Allowable Ampacity for 2-2-2 Conch Aluminum Triplex Overhead Poly at 75°C: 120 Amps

Applications:

Triplex aluminum wire has three conductors, with one of them being for neutral path, and two electrodes. The aluminum triplex cable is an electrical cable meant for power distributions from the utility lines to the consumer’s premises through the weather head. It has an operational voltage rating at 600 V and the maximum temperature rating of 75°C. A bare messenger wire of this electrical cable is bonded closely on the two insulated aluminum conductors, which are individually insulated with black cross-linked polyethylene for protection.

Also Known As:

2-2-2 conch triplex aluminum wire, 2-2-2 conch triplex overhead wire, 2-2-2 conch aluminum triplex, 2-2-2 conch triplex conductor, 2-2-2 conch overhead aluminum wire, 2-2-2 conch aluminium overhead cables, 2-2-2 conch overhead service drop conductors.

Standards:

ASTM B-230 Aluminum Wire 1350-H19 for Electrical Purposes.

ASTM B-231 Aluminum Conductors, Concentric-Lay-Stranded

ASTM B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR).

ASTM B-309 Concentric-Lay-Stranded 6201-T81 Aluminum Alloy Conductors.

ASTM B-498 Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR).

Triplex Service Drop cable meets or exceeds all applicable requirements of ANSI/ICEA body S-76-474.

Construction

Conductors:

Triplex aluminum wire has a concentric strand or compressed 1350-H19 series aluminum conductor.

Messenger:

Aluminum triplex cable has a bare ACSR messenger. Optional constructions include a messenger of AAC or 6201 alloy.

Insulation:

Triplex overhead aluminum wire has a black cross-linked polyethylene (XLP) insulation.

Specification Sheet
